Fuse box diagram Chevrolet Silverado 2007

For Chevrolet Silverado (GMT900) second generation 2007 model year.

Chevrolet Silverado 1500, Chevrolet Silverado 2500, Chevrolet Silverado 3500, Hybrid.

Cigarette lighter fuse – (fuse box in passenger compartment)

AUX PWR Fuse/20A – Auxiliary Power Outlet, Auxiliary Power Outlet – Console, Auxiliary Power Outlet – Front – 2

AUX PWR2 Fuse/20A – Auxiliary Power Outlet, Auxiliary Power Outlet – Center Seat, Auxiliary Power Outlet – Console

Fuse box in engine compartment

fuse box diagram (2007 GAS)
fuse box diagram (2007 DIESEL)

Fuse box in passenger compartment

fuse box diagram (instrument panel fuse block 2007)
Instrument panel left junction block

Fuse box in engine compartment.

The underhood fuse block is located in the engine compartment, on the driver’s side of the vehicle. Lift the cover to access the fuse block. To remove fuses, hold the end of the fuse between your thumb and index finger and pull straight out.

fuse box diagram (2007 GAS).

Assignment of the fuses (2007 GAS).

No.	Device	Rating	Description
1	TRLR STOP RT Fuse	10A	Auxilliary Body Control Module (XBCM) (EXP), Trailer Wiring
2	ESC/ALC EXH Fuse	30A	Not Used
3	TRLR STOP LT Fuse	10A	Auxilliary Body Control Module (XBCM) (EXP), Trailer Wiring
4	ENG Fuse	15A	Central Sequential Fuel Injection (Central SFI) (LU3), Evaporative Emissions (EVAP) Canister Purge Solenoid Valve (except LU3), FAN LO Relay (HP2), Mass Air Flow (MAF)/Intake Air Temperature (IAT) Sensor (except LU3), Valve Lifter Oil Manifold (VLOM) Assembly (L96, LC9, LMG or LZ1)
5	ECM/THROT CONT Fuse	15A	Engine Control Module (ECM), Evaporative Emission (EVAP) Canister Purse Solenoid Valve (LU3), Mass Air Flow (MAF)/Intake Air Temperature (IAT) Sensor (LU3)
6	ITBC Fuse	15A	Integrated Trailer Brake Control Module (JL1)
7	FRT WASH Fuse	15A	Windshield Washer Fluid Pump
8	O2-B SNSR Fuse	10A	Heated Oxygen Sensor (HO2S) Bank 1 Sensor 2, Heated Oxygen Sensor (HO2S) Bank 2 Sensor 2
9	ABS 2 Fuse	25A	Electronic Brake Control Module (EBCM)
10	TRLR BCK/UP Fuse	10A	Backup Alarm (8S3), Trailer Wiring
11	LO HDLP-LT Fuse	20A	Headlamp – Left Low Beam
12	ECM-BATT Fuse	10A	Engine Control Module (ECM)
13	INJ-B Fuse	20A	Fuel Injector 2, Fuel Injector 4, Fuel Injector 6, Fuel Injector 8, Ignition Coil 2, Ignition Coil 4, Ignition Coil 6, Ignition Coil 8 (except LU3)
14	TCM-BATT Fuse	15A	Automatic Transmission (M99, MYC or MYD), Evaporative Emission (EVAP) Canister Vent Solenoid Valve, Transmission Control Module (TCM) (M30)
15	VEH BCK/UP Fuse	10A	Backup Lamp – Left, Backup Lamp – Right
16	LO HDLP-RT Fuse	20A	Headlamp – Right Low Beam
17	A/C CMPRSR Fuse	10A	A/C Compressor Clutch
18	O2-A SNSR Fuse	10A	Heated Oxygen Sensor (HO2S) Bank 1 Sensor 1, Heated Oxygen Sensor (HO2S) Bank 2 Sensor 1
19	TRANS IGN 1 Fuse	15A	Transmission Control Module (TCM) (M30), 1-2 Shift Solenoid (SS) Valve, 2-3 Shift Solenoid (SS) Valve, 3-2 Shift Solenoid (SS) Valve (M30), Torque Converter Clutch (TCC) Solenoid Valve (M30), Torque Converter Clutch Pulse Width Modulation (TCC PWM) Solenoid Valve, Input Speed Sensor (ISS), Front Drive Axle Actuator, Automatic Transmission (MYC, MYD or M99), Drive Motor Generator Power inverter module (HP2)
20	FUEL PUMP Fuse	25A	Fuel Pump, Fuel Pump and Sender Assembly – Front
21	FSCM Fuse	25A	Fuel System Control Module (FSCM) (Gas except L96 or LU3)
22	HDLP WASH Fuse	20A	Not Used
23	REAR WASH Fuse	15A	Not Used
24	INJ-A Fuse	20A	Fuel Injector 1 (except LU3), Fuel Injector 3 (except LU3), Fuel Injector 5 (except Lu3), Fuel Injector 7 (except LU3), Ignition Coil 1 (except LU3), Ignition Coil 3 (except Lu3), Ignition Coil 5 (except LU3), Ignition Coil 7 (except LU3), Ignition Control Module (ICM) (LU3)
25	TRLR PRK Fuse	15A	Trailer Wiring
26	LT PRK Fuse	15A	Clearance Lamp (U01), Clearance Lamp – Left Front (R05), Clearance Lamp – Left Rear (R05), License Lamp – Left, Park/Turn Signal Lamp – Left Front Lower, Park/Turn Signal Lamp – Left Front Upper, Roof Marker Lamp – Left (U01), Roof Marker Lamp – Right (U01), Side Marker Lamp – Left Front (Z88), Side Marker Lamp – Left Rear (Z88), Tail/Stop and Turn Signal Lamp – Lower Left, Tail/Stop and Turn Signal Lamp – Upper Left
27	RT PRK Fuse	15A	Clearance Lamp – Right Front (R05), Clearance Lamp – Right Rear (R05), License Lamp – Right, Park/Turn Signal Lamp – Right Front Upper, Park/Turn Signal Lamp – Right Front Lower, Side Marker Lamp – Righ Front (Z88), Side Marker Lamp – Right Rear (Z88), Marker Lamp – Tailgate, Tail/Stop and Turn Signal
			Lamp – Lower Right, Tail/Stop and Turn Signal Lamp – Upper Right
28	FOG LAMP Fuse	15A	Fog Lamp – Left Front (T96), Fog Lamp – Right Front (T96)
29	HORN Fuse	15A	Horn – Left, Horn – Right (7Z1 or YE9)
30	HI HDLP-RT Fuse	10A	Headlamp – Right High Beam
31	DRL Fuse	15A	DRL 2 Fuse
32	HI HDLP-LT Fuse	10A	Headlamp – Left High Beam
33	DRL 2 Fuse	15A	LO HDLP – LT Fuse, LO HDLP – RT Fuse
34	S/ROOF Fuse	30A	Roof Beacon Relay (TRW), Sunroof Module (CF5)
35	DLIS Fuse	2A	Ignition Switch, Theft Deterrent Module (TDM)
36	FRT WPR Fuse	25A	WIPER CONTROL PCB Relay
37	SEO B2 Fuse	30A	Emergency Vehicle Roof Lamp Relay (5Y0)
38	EAP Fuse	15A	ELECTRONIC ADJUSTABLE PEDALS PCB Relay, PARK ENABLE PCB Relay
39	HVAC BATT Fuse	10A	HVAC Control Module
40	AIRBAG IGN Fuse	10A	Inflatable Restraint I/P Module Disable Switch (C99), Inflatable Restraint I/P Module Indicator, Inflatable Restraint Sensing and Diagnostic Module (SDM)
41	AMP Fuse	30A	Audio Amplifier (UQA)
42	RDO Fuse	15A	Chime Module (UL5), Digital Radio Receiver (U2K), Radio, Rear Seat Audio (RSA) Control (UK6)
43	MISC IGN Fuse	10A	Auxiliary Body Control Module (XBCm) (EXP), Serial Data Gateway (SDG) Module (HP2), Stop Lamp Switch, Trailer Brake Control Module (JL1), Transfer Case Shift Control Module (NQF or NQH)
44	L/GATE RELSE Fuse	15A	Not Used
45	AIRBAG BATT Fuse	15A	Inflatable Restraint Passenger Presence System (PPS) Module, Inflatable Restraint Sensing and Diagnostic Module (SDM), Inflatable Restraint Vehicle Rollover Sensor (ASF)
46	IPC Fuse	10A	Body Control Module (BCM), Instrument Panel Cluster (IPC)
47	EXP/PTO Fuse	15A	Auxiliary Body Control Module (XBCM) (EXP), Power Take Off
			Relay (PTO)
48	AUX HVAC-IGN Fuse	10A	Heated Steering Wheel Module Control (KA9), Inside Rearview Mirror (ISRVM), Instrument Panel Cluster (IPC)
49	CHMSL Fuse	15A	Center High Mounted Stop Lamp (CHMSL)
50	REAR DEFOG Fuse	30A	Rear Window Defogger Grid
51	HTD MIR Fuse	15A	Outside Rearview Mirror – Driver (DL8 or DPN without AN3 or DL3), Outside Rearview Mirror – Passenger (DL8 or DPN without AN3 or DL3)
52	SEO B1 Fuse	15A	Auxiliary Body Control Module (XBCm) (EXP), Security Indicator Lamp, Vehicle Inclination Sensor, Vehicle Shock Sensor
53	LTR Fuse	20A	Accessory Power Outlet – I/P 1, Data Link Connector (DLC)
54	SEO/ALC Fuse	10A	Not Used
55	HVAC-IGN Fuse	10A	Air Temperature Actuator (C67), Air Temperature Actuator – Left (CJ2), Air Temperature Actuator – Right (CJ2), Mode Actuator, Recirculation Actuator (C67 or CJ2)
56	ECM-IGN Fuse	15A	Electronic Brake Control Module (EBCM) (HP2), Engine Control Module (ECM), ), Fuel Pump Flow Control Module (Gas except L96 or LU3), Fuel Pump Relay – Secondary (L96 with N2N)
57	FAN-1 Fuse	40A	FAN LO Relay
58	ALC/COMP Fuse	40A	Not Used
59	HEAVY DUTY ABS Fuse	60A	Electronic Brake Control Module (EBCM)
60	FAN-2 Fuse	40A	FAN HI Relay
61	ABS-1 Fuse	40A	Electronic Brake Control Module (EBCM)
62	STRTR Fuse	40A	Starter
63	STUD-2 Fuse	30A	Blunt Cut Wire, Integrated Trailer Brake Control (JL1)
64	LBEC1 Fuse	60A	BCM Fuse, COOLED SEATS Fuse, CTSY Fuse, DDM Fuse, DIM Fuse, DSM Fuse, PWR MIR Fuse, REAR HVAC Fuse, RT STOP TRN Fuse, WSW PUMP Fuse
65	ELEC RUN BOARD Fuse	30A	Not Used
66	WSW/HTR Fuse	60A	Not Used
			Transfer Case Encoder Motor (NQH),
67	TREC Fuse	30A	Transfer Case Shift Control Module (NQF or NQH)
68	STUD-1 Fuse	40A	Trailer Wiring
69	MBEC1 Fuse	60A	DRIVER SEAT 2 Circuit Breaker, PASS SEAT 1 Circuit Breaker, PWR REAR WNDW Circuit Breaker, RT DOORS Circuit Breaker
70	HVAC BLWR Fuse	40A	Blower Motor Control Module
71	LGM Fuse	30A	Not Used
72	LBEC2 Fuse	60A	AUX PWR Fuse, AUX PWR 2 Fuse, INFO Fuse, IS LPS Fuse, LOCK/UNLCOK PCB Relay, LT DR Circuit Breaker, LT STOP TRN Fuse, OBS DET Fuse, PDM Fuse, REAR SEAT Fuse, REAR SEAT ENT Fuse, REAR WPR Fuse, STOP LAMPS Fuse
–	A/C CMPRSR Relay	–	A/C CMPRSR Fuse
–	FAN CNTRL Relay	–	Cooling Fan Control
–	FAN HI Relay	–	Cooling Fan – Right
–	FAN LO Relay	–	Cooling Fan – Left
–	FOG LAMP Relay	–	FOG LAMP Fuse
–	FUEL PMP Relay	–	FUEL PUMP Fuse
–	HDLP LO/HID Relay	–	DRL 2 Fuse, LO HDLP – LT Fuse, LO HDLP – RT Fuse
–	PRK LAMP Relay	–	LT PRK Fuse, RT PRK Fuse, TRLR PRK Fuse
–	PWR/TRN Relay	–	ECM/THROT CONT Fuse, ENG Fuse, FAN CNRTL PCB Relay, FAN HI PCB Relay, FAN LO PCB Relay, INJ-A Fuse, INJ-B Fuse, O2-A SNSR Fuse, O2-B SNSR Fuse
–	REAR DEFOG Relay	–	HTD MIR Fuse, REAR DEFOG Fuse
–	RUN/CRNK Relay	–	AIRBAG IGN Fuse, AUX HVAC- IGN Fuse, ECM-IGN Fuse, HVAC- IGN Fuse, MISC IGN Fuse, SEO/ALC Fuse, TRANS IGN 1 Fuse
–	STRTR Relay	–	STRTR Fuse
NOTE: Relays listed below are non-serviceable Printed Circuit Board (PCB) relays and are internal to the block.
–	BCK/UP LAMP PCB Relay	–	TRLR BCK/UP Fuse, VEH BCK/UP Fuse
–	CHMSL Relay	–	CHMSL Fuse
–	DRL PCB Relay	–	DRL Fuse
–	FRT WASH PCB Relay	–	FRT WASH Fuse
–	HI BEAM PCB Relay	–	HI HDLP – LT Fuse, HI HDLP – RT Fuse
–	HORN PCB Relay	–	HORN Fuse
–	L/GATE PCB Relay	–	L/GATE RELSE Fuse
–	LOCK PCB Relay	–	LCK 2 Fuse (YE9)
–	LOCK/UNLOCK PCB Relay	–	LCK 1 Fuse, LCK 2 Fuse, UNLCK 1 Fuse, UNLCK 2 Fuse (AU3 without YE9)
–	REAR WASH PCB Relay	–	REAR WASH Fuse
–	TRLR LT STOP/TURN PCB Relay	–	TRLR STOP LT Fuse
–	TRLR RT STOP/TURN PCB Relay	–	TRLR STOP RT Fuse
–	UNLOCK PCB Relay	–	DRV UNLCK Fuse, UNLCK 1 Fuse, UNLCK 2 Fuse
–	WIPER CONTROL PCB Relay	–	Windshield Wiper Motor
–	WIPER SPEED PCB Relay	–	Windshield Wiper Motor
NOTE: Items listed below are Wiper System diagnostic testing points
–	TP92	–	Wiper High Speed Test Point
–	TP95	–	Wiper Low Speed Test Point

Fuse box diagram (2007 DIESEL).

Assignment of the fuses (2007 DIESEL).

No.	Device	Rating	Description
1	ESC/ALC EXH Fuse	30A	Not Used
2	TRLR STOP LT Fuse	10A	Auxiliary Body Control Module (XBCM) (EXP), Trailer Wiring
3	ENG Fuse	15A	Mass Air Flow (MAF)/Intake Air Temperature (IAT) Sensor
4	TRLR STOP RT Fuse	10A	Auxiliary Body Control Module (XBCM) (EXP), Trailer Wiring
5	FRT WASH Fuse	15A	Windshield Washer Fluid Pump
6	FUEL HTR Fuse	15A	Not Used
7	TCM-BATT Fuse	15A	Transmission Control Module (TCM)
8	ABS 2 Fuse	25A	Electronic Brake Control Module (EBCM)
9	TRLR BCK/UP Fuse	10A	Backup Alarm (8S3), Trailer Wiring
10	LO HDLP-LT Fuse	20A	Headlamp – Left Low Beam
11	ECM-BATT Fuse	10A	Engine Control Module (ECM)
12	DSL ECM Fuse	30A	Engine Control Module (ECM)
13	TRANS IGN 1 Fuse	15A	Front Drive Axle Actuator (NQF or NQG), Glow Plug Control Module (GPCM), Transmission Control Module (TCM)
14	VEH BCK/UP Fuse	10A	Backup Lamp – Left, Backup Lamp – Right
15	LO HDLP-RT Fuse	20A	Headlamp – Right Low Beam
16	A/C CMPRSR Fuse	10A	A/C Compressor Clutch
17	ECM/THROT CONT Fuse	15A	Reductant Sensor Module
18	FUEL PUMP Fuse	25A	Fuel Pump, Fuel Pump and Sender Assembly – Front,
19	ITBC Fuse	15A	Integrated Trailer Brake Control Module (JL1)
20	HDLP WASH Fuse	20A	Not Used
21	REAR WASH Fuse	15A	Not Used
22	TRLR PRK Fuse	15A	Trailer Wiring
23	LT PRK Fuse	15A	Clearance Lamp (U01), Clearance Lamp – Left Front (R05), Clearance Lamp – Left Rear (R05), License Lamp – Left, Park/Turn Signal Lamp – Left Front Lower, Park/Turn Signal Lamp – Left Front Upper, Roof Marker Lamp – Left (U01), Roof Marker Lamp – Right (U01), Side Marker Lamp – Left Front (Z88), Side Marker Lamp – Left Rear (Z88), Tail/Stop and Turn Signal Lamp – Lower Left, Tail/Stop and Turn Signal Lamp – Upper Left
			Clearance Lamp – Right Front (R05),
24	RT PRK Fuse	15A	Clearance Lamp – Right Rear (R05), License Lamp – Right, Park/Turn Signal Lamp – Right Front Upper, Park/Turn Signal Lamp – Right Front Lower, Side Marker Lamp – Righ Front (Z88), Side Marker Lamp – Right Rear (Z88), Marker Lamp – Tailgate, Tail/Stop and Turn Signal Lamp – Lower Right, Tail/Stop and Turn Signal Lamp – Upper Right
25	FOG LAMP Fuse	15A	Fog Lamp – Left Front (T96), Fog Lamp – Right Front (T96)
26	HORN Fuse	15A	Horn – Left, Horn – Right (7Z1 or YE9)
27	HI HDLP-RT Fuse	10A	Headlamp – Right High Beam
28	DRL Fuse	15A	DRL 2 Fuse
29	HI HDLP-LT Fuse	10A	Headlamp – Left High Beam
30	DRL 2 Fuse	15A	LO HDLP – LT Fuse, LO HDLP – RT Fuse
31	S/ROOF Fuse	30A	Roof Beacon Relay (TRW), Sunroof Module (CF5)
32	DLIS Fuse	2A	Ignition Switch, Theft Deterrent Module (TDM)
33	WPR Fuse	25A	WIPER CONTROL PCB Relay
34	SEO B2 Fuse	30A	Emergency Vehicle Roof Lamp Relay (5Y0)
35	EAP Fuse	15A	ELECTRONIC ADJUSTABLE PEDALS PCB Relay, PARK ENABLE PCB Relay
36	HVAC BATT Fuse	10A	HVAC Control Module
37	AIRBAG IGN Fuse	10A	Inflatable Restraint I/P Module Disable Switch (C99), Inflatable Restraint I/P Module Indicator, Inflatable Restraint Sensing and Diagnostic Module (SDM)
38	AMP Fuse	30A	Audio Amplifier (UQA)
39	RDO Fuse	15A	Chime Module (UL5), Digital Radio Receiver (U2K), Radio, Rear Seat Audio (RSA) Control (UK6)
40	MISC IGN Fuse	10A	Auxiliary Body Control Module (XBCm) (EXP), Stop Lamp Switch, Trailer Brake Control Module (JL1), Transfer Case Shift Control Module (NQF or NQH)
41	L/GATE RELSE Fuse	15A	Not Used
42	AIRBAG BATT Fuse	15A	Inflatable Restraint Passenger Presence System (PPS) Module, Inflatable Restraint Sensing and Diagnostic Module (SDM), Inflatable
			Restraint Vehicle Rollover Sensor (ASF)
43	IPC Fuse	10A	Body Control Module (BCM), Instrument Panel Cluster (IPC)
44	EXP/PTO Fuse	15A	Auxiliary Body Control Module (XBCM) (EXP), Power Take Off Relay (PTO)
45	AUX HVAC-IGN Fuse	10A	Heated Steering Wheel Module Control (KA9), Inside Rearview Mirror (ISRVM), Instrument Panel Cluster (IPC)
46	CHMSL Fuse	15A	Center High Mounted Stop Lamp (CHMSL)
47	REAR DEFOG Fuse	30A	Rear Window Defogger Grid
48	HTD MIR Fuse	15A	Outside Rearview Mirror – Driver (DL8 or DPN without AN3 or DL3), Outside Rearview Mirror – Passenger (DL8 or DPN without AN3 or DL3)
49	SEO B1 Fuse	15A	Auxiliary Body Control Module (XBCm) (EXP), Power Take Off – (PTO) Module, Run Relay (TP2), Security Indicator Lamp, Vehicle Inclination Sensor, Vehicle Shock Sensor
50	LTR Fuse	20A	Accessory Power Outlet – I/P 1, Data Link Connector (DLC)
51	SEO/ALC Fuse	10A	Not Used
52	HVAC-IGN Fuse	10A	Air Temperature Actuator (C67), Air Temperature Actuator – Left (CJ2), Air Temperature Actuator – Right (CJ2), Mode Actuator, Recirculation Actuator (C67 or CJ2)
53	ECM-IGN Fuse	15A	Engine Control Module (ECM)
54	ALC/COMP Fuse	40A	Not Used
55	HEAVY DUTY ABS Fuse	60A	Electronic Brake Control Module (EBCM)
56	ABS-1 Fuse	40A	Electronic Brake Control Module (EBCM)
57	STRTR Fuse	40A	Starter
58	STUD-2 Fuse	30A	Blunt Cut Wire, Integrated Trailer Brake Control Relay (JL1)
59	LBEC1 Fuse	60A	BCM Fuse, COOLED SEATS Fuse, CTSY Fuse, DDM Fuse, DIM Fuse, DSM Fuse, PWR MIR Fuse, REAR HVAC Fuse, RT STOP TRN Fuse, WSW PUMP Fuse
60	ELEC RUN BOARD Fuse	30A	Not Used
61	WSW/HTR Fuse	60A	Not Used

62	TREC Fuse	30A	Transfer Case Encoder Motor (NQH), Transfer Case Shift Control Module (NQF or NQH)
63	STUD-1 Fuse	40A	Trailer Wiring
64	MBEC1 Fuse	60A	DRIVER SEAT 2 Circuit Breaker, PASS SEAT 1 Circuit Breaker, PWR REAR WNDW Circuit Breaker, RT DOORS Circuit Breaker
65	HVAC BLWR Fuse	40A	Blower Motor Control Module
66	LGM Fuse	30A	Not Used
67	LBEC2 Fuse	60A	AUX PWR Fuse, AUX PWR 2 Fuse, INFO Fuse, IS LPS Fuse, LOCK/UNLCOK PCB Relay, LT DR Circuit Breaker, LT STOP TRN Fuse, OBS DET Fuse, PDM Fuse, REAR SEAT Fuse, REAR SEAT ENT Fuse, REAR WPR Fuse, STOP LAMPS Fuse
68	FAN Fuse	10A	FAN RLY Relay
–	A/C CMPRSR Relay	–	A/C CMPRSR Fuse
–	FAN Relay	–	Engine Cooling Fan
–	FOG LAMP Relay	–	FOG LAMP Fuse
–	FUEL PMP Relay	–	FUEL PUMP Fuse
–	HDLP LO/HID Relay	–	DRL 2 Fuse, LO HDLP – LT Fuse, LO HDLP – RT Fuse
–	PRK LAMP Relay	–	LT PRK Fuse, RT PRK Fuse, TRLR PRK Fuse
–	PWR/TRN Relay	–	DSL ECM Fuse, ECM/THROT Fuse, ENG Fuse, FUEL HTR Fuse
–	REAR DEFOG Relay	–	HTD MIR Fuse, REAR DEFOG Fuse
–	RUN/CRNK Relay	–	AIRBAG IGN Fuse, AUX HVAC- IGN Fuse, HVAC-IGN Fuse, ECM- IGN Fuse, MISC IGN Fuse, SEO/ALC Fuse, TRANS IGN 1 Fuse
–	STRTR Relay	–	STRTR Fuse
NOTE: Relays listed below are non-serviceable Printed Circuit Board (PCB) relays and are internal to the block.
–	BCK/UP LAMP PCB Relay	–	TRLR BCK/UP Fuse, VEH BCK/UP Fuse
–	CHMSL PCB Relay	–	CHMSL Fuse
–	DRL PCB Relay	–	DRL Fuse
–	FRT WASH PCB Relay	–	FRT WASH Fuse
–	HI BEAM PCB Relay	–	HI HDLP-LT Fuse, HI HDLP-RT Fuse
–	HORN PCB Relay	–	HORN Fuse
–	L/GATE PCB Relay	–	L/GATE RELSE Fuse

–	LOCK PCB Relay	–	LCK 2 Fuse (YE9)
–	LOCK/UNLOCK PCB Relay	–	LCK 1 Fuse, LCK 2 Fuse, UNLCK 1 Fuse, UNLCK 2 Fuse (AU3 without YE9)
–	REAR WASH PCB Relay	–	REAR WASH Fuse
–	TRLR LT STOP/TRUN PCB Relay	–	TRLR STOP LT Fuse
–	TRLR RT STOP/TURN PCB Relay	–	TRLR STOP RT Fuse
–	UNLOCK PCB Relay	–	DRV UNLCK Fuse, UNLCK 1 Fuse, UNLCK 2 Fuse
–	WIPER CONTROL PCB Relay	–	Windshield Wiper Motor
–	WIPER SPEED PCB Relay	–	Windshield Wiper Motor
NOTE: Items listed below are Wiper System diagnostic testing points
–	TP92	–	Wiper High Speed Test Point
–	TP95	–	Wiper Low Speed Test Point

Fuse box in passenger compartment.

The instrument panel fuse block access door is located on the driver’s side edge of the instrument panel. Pull off the cover to access the fuse block.

fuse box diagram (instrument panel fuse block 2007).

Assignment of the fuses (2007).

Device	Rating	Description
AUX PWR Fuse	20A	Auxiliary Power Outlet – Bin (UQA), Auxiliary Power Outlet – Console (UQA), Auxiliary Power Outlet – Front – 2
AUX PWR2 Fuse	20A	Auxiliary Power Outlet – Bin (UQ3), Auxiliary Power Outlet – Center Seat (AZ3), Auxiliary Power Outlet – Console (UQ3)
STOP LAMPS Fuse	15A	Body Control Module (BCM)
BCM Fuse	10A	Body Control Module (BCM)
COOLED SEATS Fuse	30A	Not Used
CTSY Fuse	15A	Body Control Module (BCM)
DDM Fuse	15A	Driver Door Module (DDM)
DIM Fuse	15A	Body Control Module (BCM)
DRV UNLCK Fuse	15A	Door Latch Assembly – Driver (AU3 +YE9)
DSM Fuse	10A	Memory Seat Module (AN3), Remote Control Door Lock Recevier (RCDLR) (AP3/AP8)
IS LAMPS Fuse	15A	Body Control Module (BCM)
LCK1 Fuse	15A	Door Latch Assembly – Driver (AU3 -YE9), Door Latch Assembly – LR (Crew Cab), Door Latch Assembly – RR (Crew Cab)
LCK2 Fuse	15A	Door Latch Assembly – Passenger(AU3), Door Latch Assembly – Driver (AU3 +YE9)
LT DR Circuit Breaker	25A	Driver Door Switch (DDS) (AN3/DL3), Window Switch – LR (A31/YE9)
LT STOP TRN Fuse	15A	Body Control Module (BCM)
OBS DET Fuse	10A	Object Alarm Module (UD7)
PDM Fuse	15A	Garage Door Opener (GDO) (UG1), Passenger Door Module (PDM) (YE9/Y91), Roof Beacon Switch (5X7/5Y0/TRW)
PWR MIR Fuse	2A	Outside Rearview Mirror Switch (DL8/DPN +YE9 -AN3)
REAR HVAC Fuse	30A	Not Used
REAR SEAT Fuse	20A	Not Used
REAR WPR Fuse	25A	Not Used
RT STOP TRN Fuse	15A	Body Control Module (BCM)
SWC BKLT Fuse	2A	Steering Wheel Control Switch Assembly – Left, Steering Wheel Control Switch Assembly – Right
UNLCK1 Fuse	15A	Door Latch Assembly – Driver (AU3), Door Latch Assembly – LR (Crew Cab), Door Latch Assembly – RR (Crew Cab)
UNLCK2 Fuse	15A	Door Latch Assembly – Driver (Crew Cab), Door Latch Assembly – Passenger (AU3)
IMPORTANT: Relays listed below are non-serviceable Printed Circuit Board (PCB) relays and are internal to the block.
Lock PCB Relay (YE9)	–	Door Latch Assembly – Driver, Door Latch Assembly – Passenger, Door Latch Assembly – LR (Crew Cab), Door Latch Assembly – RR (Crew Cab)
Lock/Unlock PCB Relay (AU3 – YE9)	–	Door Latch Assembly – Driver, Door Latch Assembly – Passenger
		Door Latch Assembly – Driver, Door Latch Assembly –

Instrument panel left junction block.

Instrument panel left junction block is located on lower side of instrument panel to left of steering column.

Fuse box diagram.

Label.

Assignment of the fuses.

Device	Rating	Description
DRIVER SEAT 2 Circuit Breaker	25A	Memory Seat Module (AN3), Seat Adjuster Switch – Driver (AG1 Except AN3)
PASS SEAT 1 Circuit Breaker	25A	Seat Adjuster Switch – Passenger, Seat Lumbar Switch – Passenger (AN3)
PWR REAR WNDW Circuit Breaker	25A	Not Used
RT DOORS Circuit Breaker	25A	Passenger Door Module (PDM), Window Switch – RR

Cookie	Duration	Description
cookielawinfo-checkbox-analytics	11 months	This cookie is set by GDPR Cookie Consent plugin. The cookie is used to store the user consent for the cookies in the category "Analytics".
cookielawinfo-checkbox-functional	11 months	The cookie is set by GDPR cookie consent to record the user consent for the cookies in the category "Functional".
cookielawinfo-checkbox-necessary	11 months	This cookie is set by GDPR Cookie Consent plugin. The cookies is used to store the user consent for the cookies in the category "Necessary".
cookielawinfo-checkbox-others	11 months	This cookie is set by GDPR Cookie Consent plugin. The cookie is used to store the user consent for the cookies in the category "Other.
cookielawinfo-checkbox-performance	11 months	This cookie is set by GDPR Cookie Consent plugin. The cookie is used to store the user consent for the cookies in the category "Performance".
viewed_cookie_policy	11 months	The cookie is set by the GDPR Cookie Consent plugin and is used to store whether or not user has consented to the use of cookies. It does not store any personal data.
