For Fiat Coupe (175) 1994, 1995, 1996, 1997, 1998, 1999, 2000, 2001, 2002 model year.
Cigarette lighter fuse – fuse box in passenger compartment – Fuse F13/20A |
Fuse box in passenger compartment.
fuse box location.
fuse box diagram.
Assignment of the fuses.
1 | Headlamp low beam relay |
2 | Ignition main circuits relay |
3 | Headlamp high beam relay |
4 | Rear screen intermittent wiper relay |
5 | Indicator relay |
6 | Horn relay |
7 | Heated rear window relay |
8 | Rear fog lamp relay |
9 | Side lamps relay |
F1 | (10A) Hazard warning, indicators, alarm |
F2 | (7,5A) Indicators |
F3 | (7,5A) Rear fog lamp, rear fog lamp warning lamp |
F4 | (10A) Instruments, windscreen washer pump, reversing lamps, airbag, immobiliser, switch illumination, cold start device (turbo) |
F5 | (10A) Headlamp low beam – left |
F6 | (10A) Headlamp low beam – right, headlamp washer system, headlamp adjuster units |
F7 | (20A) Windscreen wipers |
F8 | (20A) Heater blower motor, air conditioning |
F9 | (10A) Headlamp high beam – left, high beam warning lamp |
F10 | (10A) Headlamp high beam – right |
F11 | (7,5A) Interior lamp, luggage compartment lamp, central locking signal sensor |
F12 | (25A) Engine coolant blower motor |
F13 | (20A) Horn, cigarette lighter, stop lamps, audiounit |
F14 | (20A) Rear windscreen wiper motor, electric sunroof |
F15 | (20A) Heated rear window, heated rear window warning lamp, door mirror heaters |
F16 | (10A) Switch illumination, tail lamp – left right, licence plate lamp – left, side lamp – left, trailer tail lamp – right |
F17 | (10A) Instrument panel lamps, tail lamp – left, licence plate lamp – right, side lamp – right, trailer tail lamp – left |
Fuse box №2 in passenger compartment.
fuse box diagram.
legend.
1 | Windscreen wash/wipe intermittent relay |
2 | Central locking control module |
3 | Engine coolant blower motor relay |
4 | Indicator relay |
5 | Fog lamps relay |
6 | Headlamp washer pump delay relay |
7 | Electric windows control module |
F1 | (15A) Central locking |
F2 | (25A) Electric windows |
F3 | (10A)ABS |
F4 | (20A) Fog lamps |
F5 | (20A) Headlamp washer system |
Fuse box in engine compartment.
fuse box location.
fuse box №1 diagram.
legend.
1 | Engine coolant blower motor relay/air conditioning condenser blower motor relay – 1st speed |
2 | Air conditioning relay |
3 | Air conditioning compressor clutch relay |
4 | Engine coolant blower motor relay/air conditioning condenser blower motor relay – 2nd speed |
5 | Engine coolant blower motor relay/air conditioning condenser blower motor relay – 2nd speed delay unit |
F1 | (7,5A) Air conditioning system relay, air conditioning compressor clutch relay |
F2 | – |
fuse box №2 diagram.
1 | Windscreen wash/wipe intermittent relay |
2 | Rear screen wash/wipe relay |
3 | Heater blower relay |
4 | Heater blower relay |
fuse box №3 diagram.
F1 | (30A) Engine coolant blower motor |
F2 | (30A) Air conditioning |
