For Mercedes W124 1986, 1987, 1988, 1989, 1990, 1991, 1992, 1993, 1994, 1995, 1996 model year.
Mercedes E-Class. E 200, 220, 230, 250, 260, 280, 300, 320, 400, 420, 500
Cigarette lighter fuse – Fuse box in engine compartment – Fuse F1/8A/16A) |
MENU
Fuse box in engine compartment.
Fuse box in engine compartment.
fuse box location.
Fuse box diagram.
Assignment of the fuses and relay (type 1).
| F1 | (16A) Cigarette lighter, heated rear window, central locking pump, rear screen wiper, electric windows, audio unit |
| F2 | (16A) Windscreen wipers, windscreen washers, high beam flash, electric windows, sunroof |
| F3 | (8A) Side lamps – right, tail lamps – right, lights on warning buzzer, licence plate lamp, switch illumination, instrument panel lamps, headlamp washers |
| F4 | (8A) Fog lamps – front, fog lamps – rear |
| F5 | (8A) Stop lamps, interior lamp – front, bulb failure warning module, cruise control, trailer control module |
| F6 | (8A) Indicators, horn, trip computer |
| F7 | (16A) Reverse lamps, engine coolant pump, engine coolant blower motor, heated washer jets, automatic transmission, air conditioning system |
| F8 | (8A) Side lamps – left, tail lamps – left |
| F9 | (8A) Diagnostic link, hazard lamps, clock, interior lamp – front, audio unit, vanity mirror lamp, electric windows, sunroof |
| F10 | (25A) Heated rear window |
| F11 | (8A) Intake manifold pre heater, transmission fluid blower motor |
| F12 | (25A) Heater blower motor |
| F13 | (8A) Low beam – left |
| F14 | (8A) Low beam – right |
| F15 | (8A) High beam – left |
| F16 | (8A) High beam – right, high beam warning lamp |
| F17 | (16A) Sunroof |
| F18 | (8A) Seat belt presenter, door mirror adjustment, alarm system, central locking signal control |
| F19 | (8A/16A) Interior lamps – rear, electric windows, sunroof, central locking |
| F20 | (16A) Air conditioning condenser blower motor |
| F21 | (25A) Seat adjustment – driver’s side, seat adjustment – passenger’s side, seat adjustment memory, steering wheel adjustment memory |
| F22 | (25A) Seat adjustment – driver’s side, seat adjustment – passenger’s side, steering wheel adjustment |
| F23 | (25A) Electric windows – front |
| F24 | (25A) Electric windows – rear |
| A | Electric windows, sunroof, seat adjustment relay |
| B | Air conditioning condenser blower motor relay I |
| C | Air conditioning condenser blower motor relay II |
| D | Headlamp wash/wipe relay |
| E | Oxygen sensor system relay |
| F | Seat heater fuse |
| G | Fuel cut off valve relay |
| K | Multifunction relay, indicator lamps, hazard lamps, heated rear window, wiper motor, alarm system |
Assignment of the fuses and relay (type 2).
1 – 8 Amp Glove Box Light & Radio, Cigarette Lighter & Rear Defogger, Rear Head Restraint System
2 – 16 Amp Wipers & Washers, Headlights, Power Windows & Seats
3 – 8 Amp Park, Tail, & Side Marker Lights, Warning System & Instrument Illumination, Headlight Wiper & Washer
4 – 8 Amp Foglights
5 – 8 Amp Courtesy Lights & Clock, Gauges & Warning Indicators, Cruise Control & Tachometer
6 – 8 Amp Horns, Hazard Lights & Warning System, Gauges & Warning Indicators, Clock & Tachometer
7 – 8 Amp Auxiliary Fan & Engine Overload Protection, Automatic Climate Control
8 – 8 Amp Auxiliary Fan & Engine Overload Protection, Automatic Climate Control, Back-Up Lights
9 – 8 Amp Gauges & Warning Indicators, Clock, Radio & Tachometer, Warning System, Courtesy Lights & Power Seats
10 – 25 Amp Turn Signal Lights & Rear Defogger, Wipers & Washers
11 – Blank
12 – 25 Amp Automatic Climate Control (Blower Control)
13 – 8 Amp Headlights (Left Low Beam)
14 – 8 Amp Headlights (Right Low Beam)
15 – 8 Amp Headlights (Left High Beam)
16 – 8 Amp Headlights (Right High Beam)
17 – 16 Amp Central Locking System & Heated Seats, Rear Head Restraint System & Sliding Roof
18 – 8 Amp Outside Heated Mirrors
19 – 8 Amp Automatic Antenna & Courtesy Lights
20 – 16 Amp Auxiliary Fan
21 – 25 Amp Power Seats, Seat Motors & Memory
22 – 25 Amp Power Seats & Telescopic Steering Column
23 – 16 Amp Power Windows (Left Front & Right Rear)
24 – 16 Amp Power Windows (Right Front & Left Rear)
RELAY IDENTIFICATION
A – Power Seats
B – High Speed Auxiliary Fan
C – Auxiliary Fan
D – Headlight Washer
E – Auxiliary Fuse Holder
F – Power Windows
G – Blank
H – Combination Relay
I – Power Seat Diode
K – Exterior Light Failure Monitor
1986-1993.
1994-1996.
