For Land Rover Range Rover 1995, 1996, 1997, 1998, 1999, 2000, 2001, 2002 model year.
Range Rover (P38A).
Cigarette lighter fuse (front) – Fuse box in passenger compartment – Fuse F8/30A |
MENU
Fuse box in passenger compartment.
Fuse box in engine compartment.
Fuse box in passenger compartment.
fuse box location.
The right hand seat fuse box is located under the passenger’s seat.
IMPORTANT: The fuse panel is part of the Body Electrical Control Module (BECM). The BECM contains relays that are internal of the control module. These relays are not serviceable.
fuse box diagram.
Assignment of the fuses.
| Fuses | Amps | Circuits Protected |
|---|---|---|
| 1 | 10A | Instrument panel Clock Radio Centre console switches |
| 2 | 30A | Rear right window Heated seat(s) |
| 3 | 5A | Automatic transmission control unit, battery supply |
| 4 | 30A | Transfer box control unit, battery supply |
| 5 | Not used | |
| 6 | 10A | Rear-view mirror dip Sun visor illumination Automatic transmission control unit, ignition supply (-> 1999) Transfer box control unit, ignition supply |
| 7 | 10A | Airbag (-> 1999) Automatic transmission control unit, ignition supply (1999 ->) Transfer box control unit, ignition supply |
| 8 | 30A | Telephone Radio Cigarette lighter Heating, ventilation and air conditioning (HVAC) Antenna amplifier (-> 1999) |
| 9 | 20A | Front audio amplifier Front door lock actuators Front mirrors |
| 10 | 30A | Seat adjustment, right side |
| 11 | Not used | |
| 12 | 30A | Heated rear windscreen Rear left window |
| 13 | 20A | Transmission interlock solenoid Sunroof Key inhibit solenoid (-> 1999) |
| 14 | 30A | Central locking, rear doors Fuel filler flap release Trailer battery supply |
| 15 | 20A | Rear audio amplifier Luggage compartment light(s) Subwoofer Rear right interior light(s) RF remote receiver Central locking, tailgate Rear wiper motor |
| 16 | 30A | Not used |
| 17 | 10A | Brake light(s) Heating, ventilation and air conditioning (HVAC) ignition signal (-> 1999) Air suspension |
| 18 | 30A | Battery supply |
| 19 | Not used | |
| 20 | 30A | Seat adjustment, left side |
| 21 | Not used | |
| 22 | 30A | Relay, front left power window Relay, front right power window |
Fuse box in engine compartment.
Engine compartment fuse box located on passenger’s side of engine compartment.
legend (pre 1997).
| 1 | (60A) (Maxi fuse) Fuses 1, 2,3 and 4 |
| 2 | (30A) (Maxi fuse) Air suspension, starter relay |
| 3 | (40A) (Maxi fuse) ABS pump |
| 4 | (60A) (Maxifuse) Fuses 12, 13,14, 15,17 |
| 5 | (60A) (Maxi fuse) Fuses8,9,10, 20,22 |
| 6 | Heater blower relay I |
| 7 | Heater blower relay II |
| 8 | Windscreen wiper intermittent relay |
| 9 | Horn relay |
| 10 | – |
| 11 | Headlamp wash/wipe relay |
| 12 | Fuel pump relay |
| 13 | Air conditioning condenser blower motor relay I |
| 14 | Air conditioning condenser blower motor relay II |
| 15 | Ignition main circuits relay |
| 16 | Starter motor relay |
| 17 | ABS pump relay |
| 18 | Air conditioning relay |
| 19 | Engine control module relay |
| 20 | Suspension compressor relay |
| F23 | (10A) Airbag, instrument panel |
| F24 | (5A) Air suspension, ABS |
| F25 | (20A) Windscreen wipers |
| F26 | (20A) Engine control |
| F27 | (30A)ABS |
| F28 | (10A) – |
| F29 | (20A) – |
| F30 | (30A) Heated windscreen – right |
| F31 | (30A) Air conditioning condenser blower motor – left |
| F32 | (30A) Heated windscreen – left |
| F33 | (5A) Diagnostic link |
| F34 | (25A) Heater blower motor – left |
| F35 | (5A)- |
| F36 | (30A) Air conditioning condenser blower motor – right |
| F37 | (20A) Engine control module relay |
| F38 | (10A) Headlamp wash/wipe |
| F39 | (10A) Fuel pump |
| F40 | (30A) – |
| F41 | (20A) Horns |
| F42 | (10A) Heater/air conditioning system |
| F43 | (25A) Heater blower motor – right |
| F44 | (10A) Air suspension |
Fuse box diagram (since 1997).
fuse.
legend.
| Fuse number | Rating (AMPS) | Circuit protected |
|---|---|---|
| 23 | 10A | Airbag SRS |
| 24 | 5A | ABS |
| 25 | 20A | Front wiper system, headlight wash |
| 26 | 20A | Engine management system (EMS) |
| 27 | 10A | Air conditioning compressor |
| 28 | 30A | Ignition coils (EMS) |
| 29 | 10A | Air suspension ECU |
| 30 | 30A | Heated front screen |
| 31 | 30A | Air-conditioning |
| 32 | 30A | Heated front screen |
| 33 | 5A | Diagnostics |
| 34 | 30A | Heater blower |
| 35 | 10A | Air conditioning, air suspension |
| 36 | 30A | Air-conditioning |
| 37 | 30A | Engine management system (EMS) |
| 38 | 30A | ABS |
| 39 | 20A | Fuel pump |
| 40 | 40A | Starter motor, air suspension |
| 41 | 20A | Horn |
| 42 | 10A | Heating & ventilation, key inhibit solenoid |
| 43 | 30A | Heater blower |
| 44 | 30A | Engine management system (EMS) |
| Maxi 1 | 60A | – |
| Maxi 2 | 50A | Engine management system (EMS) |
| Maxi 3 | 40A | ABS pump |
| Maxi 4 | 60A | – |
| Maxi 5 | 60A | – |
relay (since 1997).
| Number | Description |
|---|---|
| 1 | Front Wiper |
| 2 | Ignition Coils |
| 3 | A/C Dual Pressure Sensor |
| 4 | Front Right Heated Screen |
| 5 | – |
| 6 | Front Left Heated Screen |
| 7 | Auxillary Power Circuit |
| 8 | Front Intermittent Wiper |
| 9 | – |
| 10 | Secondary Air Injection |
| 11 | Headlamp Wiper/Washer |
| 12 | Fuel Pump |
| 13 | A/C Cooling Fan No. 1 |
| 14 | A/C Cooling Fan No. 2 |
| 15 | Ignition |
| 16 | Starter |
| 17 | ABS |
| 18 | A/C Control |
| 19 | Engine Main Control |
| 20 | – |
