For Dodge Caravan 1991, 1992, 1993 model year.
Dodge Caravan, Dodge Grand Caravan
MENU
Fuse box in passenger compartment
Buzzers, relays & timers location.
Fuse box in passenger compartment.
Fuse panel is located under the parking brake handle on the left side of the steering column.
fuse box diagram.
Assignment of the fuses.
Fuses | Amps | Circuits protected |
---|---|---|
1 | 20A | Hazard Flasher. |
2 | 10A | Heated Mirrors. |
3 | 20A | Body Lights, Cigar Lighter |
4 | 20A | Not Used (1991-92); Not Used (1991-92); Liftgate Switch (1993). |
5 | 20A | Windshield Wipers. |
6 | 10A 20A | 10 Amp (1992-93) Radio. 20 Amp (1991) Turn Signal Lights. |
7 | 20A 19A | 20 Amp (1992-93) Turn Signal Lights. 19 Amp (1991) Radio. |
8 | 20A | Not Used (1991); Back-Up Lights, Air Bag Module (1992-93). |
9 | 7.5A | Illumination Lights. |
10 | 2A | Not Used (1992-93) Left Taillights (1991); Not Used (1992-93). |
11 | 2A | Not Used (1992-93) Right Taillights (1991); Not Used (1992-93). |
12 | Not Used | |
13 | 20A | Rear Window Wiper/Washer. |
14 | 2A | Speed Control. |
15 | 10A | Gauges, Warning Lights, Air Bag Module. |
16 | Not Used | |
17 | 10A | Left Low Beam Headlight. |
18 | 10A | Right Low Beam Headlight. |
19 | 20A | Stoplights. |
20 | 20A | Rear A/C & Heater. |
21 | 20A | Foglights. |
22 | 20A | Parklights. |
23 | 20A | Battery, Air Bag Module. |
24 | 20A | Back-Up Lights (1991-93), Power Door Locks (1993). |
25 | Circuit Breaker Power Windows, Power Vent Windows. | |
26 | 30A | A/C Heater Blower Motor. |
27 | Circuit Breaker Power Door Locks (1991-92), Power Seat (1993). | |
28 | 20A | 1991-92) Not Used. (1993) Horn. |
Buzzers, relays & timers location.
Component | Location |
---|---|
ABS System | |
Pump Motor Relay | In engine bay, forward of left strut tower. See Fig. 1 . |
System Relays | On left front inner fender, above SBEC module. See Fig. 1 . |
Warning Light Relays | On left front inner fender, above SBEC module. See Fig. 1 . |
A/C Clutch Relay | In engine bay, on right inner fender. See Fig. 2 . |
A/C Relay (Rear) | Behind left end of instrument panel, on relay block. |
Auto. Shutdown Relay | |
2.5L | In engine bay, on left fender panel. See Fig. 3 . |
3.0L & 3.3L | In engine bay, on left fender panel. See Fig. 4 . |
Back-Up Light Relay (EATX) (3.0L & 3.3L) | On right side of engine bay firewall. See Fig. 4 . |
Combo. Flasher Relay (T/S-Hazard) | Behind left end of instrument panel, on relay block. |
Condenser Fan Relay | In engine bay, on right inner fender. |
Foglight Relay | Behind left end of instrument panel, on relay block. |
Fuel Pump Relay | |
2.5L | In engine bay, on left inner fender. See Fig. 3 . |
3.0L & 3.3L | In engine bay, on left inner fender. See Fig. 4 . |
Horn Relay | Behind left end of instrument panel, on relay block. |
Low Beam Relay | Behind left end of instrument panel, on relay block. |
Name Brand Speaker Relay | Behind left end of instrument panel, on relay block. |
Parking Light Relay | Behind left end of instrument panel, on relay block. |
Power Door Lock/Unlock Relays | Behind left end of instrument panel, on relay block. |
Radiator Fan Relay | |
2.5L | In engine bay, on left inner fender. See Fig. 3 . |
3.0L & 3.3L | In engine bay, on left inner fender. See Fig. 4 . |
Rear Window Defogger Timer | Part of rear window defogger switch. |
Safety Shutdown Relay (EATX) (3.0L & 3.3L) | In engine bay, on left inner fender. See Fig. 4 . |
Starter Relay | |
2.5L | In engine bay, on left inner fender. See Fig. 3 . |
3.0L & 3.3L | In engine bay, on left inner fender. See Fig. 4 . |
Van Conversion Relay | Behind left end of instrument panel, on relay block. |
