For Ford Galaxy (50) 1995, 1996, 1997, 1998, 1999, 2000 model year.
| Cigarette lighter fuse – fuse box in passenger compartment – Fuse F21/15A (1995-1997) Cigarette lighter fuse – fuse box in passenger compartment – Fuse F7/20A/25A (1998-2000) Cigarette lighter fuse – fuse box in passenger compartment – Fuse F12/15A (1998-2000) |
MENU
Fuse box in passenger compartment.
- fuse box diagram (1995-1997)
- fuse box diagram (1998-2000)
- upper relay panel in passenger compartment (1998-2000)
- lower relay panel in passenger compartment (1998-2000)
Fuse box in engine compartment (1995-1997)
Fuse box in passenger compartment.
fuse box location.
Assignment of the fuses.
| R1 | Auxiliary heating relay |
| R2 | Rear screen intermittent wiper relay |
| R3 | Engine control module relay |
| R4 | Ignition main circuits relay |
| R5 | – |
| R6 | Indicator/hazard warning lamps relay |
| R7 | Headlamp washer pump relay |
| R8 | Windscreen wash/wipe intermittent relay |
| R9 | Side lamps ‘on’ warning buzzer |
| R10 | Fog lamps relay |
| R11 | Horn relay |
| R12 | Fuel pump relay (petrol) |
| R13 | Headlamp high beam/low beam relay |
| R14 | Heated rear windscreen |
| R15 | Wiper system |
| R16 | Heated windscreen |
| R20 | Heated windscreen cut-off |
| R21 | Central locking |
| R23 | Daylight running system |
| P106 | HALL system |
| P107 | Power distribition 58B |
| P109 | Data comunication |
| P120 | Power distribition 15A |
| P121 | Power distribition 54 |
| P127 | Power distribition TK |
| F1 | (7,5A) Headlamp low beam – right, headlamp adjustment – left |
| F2 | (7,5A) Headlamp low beam – left, headlamp adjustment – right |
| F3 | (3A) Licence plate lamps |
| F4 | (20A) Rear screen wiper, heater blower motor-rear |
| F5 | (10A) Windscreen wiper motor, washer jet heaters |
| F6 | (25A) Heater blower motor, air conditioning control module |
| F7 | (5A) Side/tail lamps – right, side lamps on warning buzzer |
| F8 | (5A) Side/tail lamps – left, side lamps on warning buzzer |
| F9 | (20A) Heated rear window |
| F10 | (15A) Light switch, fog lamps-front, rear fog lamps |
| F11 | (7,5A) Headlamp high beam – left, headlamp high beam warning lamp |
| F12 | (7,5A) Headlamp high beam – right |
| F13 | (10A) Horns |
| F14 | (15A) Reversing lamps |
| F15 | (10A) Engine control module (2,8i), crankcase breather heater |
| F16 | (3A) Clock, interior lamp-front, instrument panel |
| F17 | (10A) Indicators |
| F18 | (10A) Inertia fuel shut off, fuel pump, oxygen sensor (2,8i), engine control module (2,0) |
| F19 | (30A) Engine coolant blower motor, air conditioning compressor clutch relay |
| F20 | (10A) Stop lamps |
| F21 | (15A) Interior lamps, clock, tailgate lamp, cigarette lighter, auto AC |
| F22 | (10A) Diagnostic system, Air conditioning |
| F23 | (10A) Engine coolant blower motor, air conditioning compressor clutch relay |
| F24 | (30A) Windscreen wiper motor |
| F25 | (60A) Glow plugs (diesel) |
| F26 | (10A) Oxygen sensor |
| F27 | (50A) Heated windscreen relay |
| F28 | (30A) ABS/traction control |
| F29 | (30A) ABS/traction control |
| F30 | (10A) Central locking, door edge lamps |
| F31 | (10A) Alarm system horn |
| F32 | (10A) Hazard flashers (alarm system) |
| F33 | (30A) Auxiliary heater blower |
| F34 | (25A) Engine coolant blower motor relay |
| F35 | (20A) Trialer socket |
| F36 | (10A) Telephone |
| F37 | (30A) Electric windows |
| F38 | (20A) Seat adjustment |
| F39 | (25A) Engine coolant blower motor relay |
legend.
| F1 | (20A) Heated seats |
| F2 | (10A) Instrument panel, instrument illumination, electric windows, electric door mirrors |
| F3 | (5A) Anti-lock brake system (ABS), interior lamps, instrument illumination, cigarette lighter, clock, cruise control, heating/ventilation, auxiliary heater, air conditioning (AC), navigation system, sunroof |
| F4 | (10A) Engine management, alarm system |
| F5 | (15A) Parking aid, reversing lamp/s, automatic transmission (AT), four wheel drive system, navigation system, trailer socket |
| F6 | (10A) Horn |
| F7 | (20A/25A) Cigarette lighter, clock |
| F8 | (30A) Charging system, windscreen wash/wipe system, auxiliary heater, trailer socket |
| F9 | (30A) Anti-lock brake system (ABS) |
| F10 | (30A) Anti-lock brake system (ABS) |
| F11 | (20A) Headlamp washers |
| F12 | (15A) Cigarette lighter, clock, windscreen wash/wipe system, sunroof |
| F13 | (3A) Engine management |
| F14 | (10A/20A/25A) Engine management, cruise control, heating/ventilation, air conditioning (AC) |
| F15 | (30A) Engine management, air conditioning (AC) |
| F16 | (10A/30A) Engine management, air conditioning (AC) |
| F17 | (10A/30A) Engine management, automatic transmission (AT), heating/ventilation |
| F18 | (5A) Engine management, air conditioning (AC) |
| F19 | (5A) Data link connector (DLC), alarm system, instrument panel, air conditioning (AC), audio system, audio unit CD changer, telephone, navigation system, central locking, electric windows |
| F20 | (10A) Anti-lock brake system (ABS), automatic transmission (AT), engine management, stop lamps, instrument panel, cruise control, navigation system, trailer socket |
| F21 | (25A/30A) Air conditioning (AC), auxiliary heater |
| F22 | (25A/30A) Air conditioning (AC), auxiliary heater |
| F23 | (10A) Audio system, audio unit CD changer, navigation system |
| F24 | (25A) Heating/ventilation |
| F25 | (3A) Instrument panel, audio system, audiounit CD changer, navigation system, telephone |
| F26 | (30A) Automatic transmission (AT), starter motor relay – immobilizer, engine management, instrument panel |
| F27 | (25A) Engine management, heated windscreen, air conditioning (AC), auxiliary heater |
| F28 | (10A) Anti-lock brake system (ABS), air conditioning (AC), engine management, windscreen wash/wipe system, headlamp washers |
| F29 | (5A) Windscreen wash/wipe system, heated windscreen, heating/ventilation, air conditioning (AC), auxiliary heater |
| F30 | (3A) Tail lamps, licence plate lamps, trailer socket |
| F31 | (15A) Fog lamps, trailer socket |
| F32 | (3A/10A) Engine management, cruise control, air conditioning (AC) |
| F33 | (25A/30A) Charging system, windscreen wash/wipe system, auxiliary heater, trailer socket |
| F34 | (25A) Heating/ventilation, air conditioning (AC), auxiliary heater |
| F51 | (20A) Heated rear window |
| F52 | (20A) Indicators, hazard warning lamps, trailer socket, alarm system |
| F53 | (10A) Entrance lamps, interior lamps |
| F54 | (10A) Alarm system |
| F55 | (5A) Entrance lamps, instrument panel, alarm system, central locking, electric windows |
| F56 | (5A) RH side/tail lamps, trailer socket, daytime running lamps, instrument panel, trailer socket |
| F57 | (5A) LH side/tail lamps, trailer socket, daytime running lamps, instrument panel, trailer socket |
| F58 | (10A) Headlamp adjustment, daytime running lamps, LH headlamp, RH headlamp |
| F59 | (10A) LH headlamp – low beam, instrument panel, LH headlamp adjustment, daytime running lamps |
| F60 | (10A) RH headlamp – low beam, instrument panel, RH headlamp adjustment, daytime running lamps |
| F61 | (10A) LH headlamp – high beam, instrument panel |
| F62 | (10A) RH headlamp – high beam |
Upper relay panel in passenger compartment (1998-2000).
legend.
| 1 | Door mirror control module |
| 10a | Horn relay |
| 10b | Heater blower relay – rear |
| 11a | Wide open throttle (WOT) relay (2,0/2,3) |
| 11b | Engine coolant blower motor relay, high speed (2,0) |
| 17a | Auxiliary heater relay |
| 17b | Auxiliary heater cut-off relay |
| 18a | Wide open throttle (WOT) relay (1,9 TDI – with AC) |
| 18b | Engine coolant blower motor relay, high speed (2,3 – with AC & AT) |
| 2 | Door mirror control module |
| 3 | AC relay (2,0/2,3) |
| 4 | Wide open throttle (WOT) relay (2,8 – with AC & AT ^08/98) |
| 5 | Engine coolant blower motor run-on relay (2,8) |
| 6 | Transmission system relay |
| 7 | Heater blower relay (^04/98) – auxiliary heater |
| 8 | Headlamp washer pump relay |
| 9 | Daytime running lamps relay |
| 12 | AC compressor clutch relay (2,8 ^10/98) |
| 13 | AC diode (2,8) |
| 14 | Starter motor relay – immobilizer |
| 15 | Auxiliary heater fan relay (^04/98) |
| 16 | Electric window circuit relay – rear quarter lights |
| 19 | Engine coolant blower motor relay, high speed (2,0 MT – with rear heating 09/98^) |
Lower relay panel in passenger compartment (1998-2000).
legend.
| R20 | Auxiliary heater fan relay (05/98^) |
| R21 | Windscreen wiper motor relay (^10/98) |
| R22 | Secondary air injection (AIR) pump relay (2,8) |
| R23 | Heated windscreen relay |
| R24 | Fuel pump relay (1,9TDI/2,0/2,3/2,8^05/99) |
| R25 | Engine coolant heater relay 2 (1,9 TDI) |
| R26 | Ignition main circuits relay |
| R27 | Engine control (EC) relay (2,0/2,3) |
| F70 | (30A) Engine management |
| F71 | (30A) Electric windows |
| F72 | (40A) Engine management, air conditioning (AC) |
| F73 | (30A/40A) Engine management, air conditioning (AC) |
| F74 | (60A) Engine management |
| F75 | (50A) Engine management |
Fuse box in engine compartment (1995-1997).
fuse box diagram (without AC).
legend.
| 1 | Engine coolant blower motor relay – AT |
| 2 | – |
| 3 | Engine coolant blower motor relay – high speed |
| 4 | – |
| 5 | Engine coolant blower motor relay – low speed |
| 6 | Reversing lamp relay (AT) |
| 7 | Secondary air injection (AIR) pump relay |
| 8 | – |
| F1 | (30A) Secondary air injection (AIR) pump |
| F2 | (40A) Engine coolant blower motor |
| F3 | (30A) Engine coolant blower motor |
Fuse box diagram engine compartment 1995-1997 (with AC).
legend.
| 1 | AC relay |
| 2 | – |
| 3 | Engine coolant blower motor relay – high speed |
| 4 | Wide open throttle (WOT) relay |
| 5 | Engine coolant blower motor relay – low speed |
| 6 | Reversing lamp relay (AT) |
| 7 | Secondary air injection (AIR) pump relay |
| 8 | – |
| F1 | (30A) Secondary air injection (AIR) pump |
| F2 | – |
| F3 | – |
