Fuse box in passenger compartment.
Fuse box in engine compartment.
Relay box in engine compartment.
Fuse box in passenger compartment.
fuse box location.
The central fuse box is located behind the glove box. Open the glove box and empty the contents. Press the sides inwards and swivel the glove box downwards. To access the fuses, open the glove box, squeeze its walls and fold it down.
Assignment of the fuses.
| 1 | Door mirror retract relay – fold-in |
| 2 | Heated windscreen relay |
| 3 | Ignition auxiliary circuits relay |
| 4 | Headlamp low beam relay |
| 5 | Headlamp high beam relay |
| 6 | Fuel pump (FP) relay – petrol |
| 7 | Starter motor inhibitor switch relay |
| 8 | Engine coolant blower motor relay |
| 9 | Daytime running lamps relay |
| 10 | Battery saver relay |
| 11 | Engine control (EC) relay |
| 12 | Door mirror retract relay – unfold |
| F1 | Not used |
| F2 | Not used |
| F3 | (7,5A) Split charge relay H-08/02) |
| F4 | (10A) AC control module, wide open throttle (WOT) relay – AC |
| F5 | (20A) ABS control module |
| F6 | (30A) ABS control module |
| F7 | (7,5A) Transmission control module (TCM), transmission shift control module (^12/03) |
| F8 | (7,5A) Door mirrors |
| F9 | (10A) LH headlamp |
| F10 | (10A) RH headlamp |
| F11 | (15A) Fascia fuse box/relay plate (F9/F10) |
| F12 | (15A) Engine control module (ECM), engine coolant blower motor relay, evaporative emission (EVAP) canister purge valve, immobilizer transponder module, injectors, vehicle speed sensor (VSS), wide open throttle (WOT) relay (petrol) |
| F13 | (20A) Heated oxygen sensor (HO2S) – petrol |
| F14 | (30A) Starter motor relay |
| F15 | (20A) Fuel pump(FP) relay – petrol |
| F16 | (3A) Engine control (EC) relay |
| F17 | (15A) Headlamp switch |
| F18 | (15A) Audio unit, data link connector (DLC), DVD player |
| F19 | (15A) Daytime running lamps relay |
| F20 | (7,5A) Instrument panel, multifunction control module (^01/04) |
| F21 | Not used |
| F22 | (7,5A) LHside lamp, LH tail lamp, trailer control module |
| F23 | (7,5A) RH side lamp, RH tail lamp, trailer control module |
| F24 | (20A) Multifunction control module |
| F25 | (15A) Multifunction control module |
| F26 | (20A) Multifunction control module |
| F27 | (10A) Multifunction control module (^12/03) |
| F28 | (3A) Alternator |
| F29 | (15A) Cigarette lighter, front |
| F30 | (15A) Ignition switch |
| F31 | (20A) Trailer control module (^09/02) |
| F32 | (7,5A) Door mirrors |
| F33 | (7,5A) Audio unit, DVD player, hazard warning lamps switch, AC control module, instrument panel, licence platelamps, multifunction control module, multi switch assembly, transmission shift control module |
| F34 | (20A) Sunroof switch |
| F35 | (7,5A) Seat heaterswitches |
| F36 | (30A) Electric window switches |
| F37 | (3A) ABS control module |
| F38 | (7,5A) Heated windscreen relay, AC control module, multifunction control module, multi switch assembly |
| F39 | (7,5A) Airbag control module |
| F40 | (10A) Headlamp switch, indicator switch |
| F41 | (7,5A) Transmission control module (TCM), transmission shift control module – Durashift |
| F42 | (30A) Heated windscreen – LH side |
| F43 | (30A) Heated windscreen – RH side |
| F44 | (3A) Audio unit, DVD player, instrument panel |
| F45 | (15A) Brake pedal position (BPP) switch |
| F46 | (20A) Multifunction control module, windscreen wash/wipe switch, windscreen wiper motor |
| F47 | (10A) Multifunction control module, rear screen wiper motor |
| F48 | (7,5A) Reverse gear position switch – Durashift |
| F49 | (30A) Heater/AC blower motor |
| F50 | (20A) Headlamp switch |
| F51 | (15A) Battery saver relay |
| F52 | (10A) Headlamp – LH |
| F53 | (10A) Headlamp – RH |
| F54 | (7,5A) Trailer socket (09/02^) |
| F55 | Not used |
| F56 | (20A) Trailer control module (09/02^) |
Fuse box diagram (type 2) (pre 2004).
legend.
Fuse 1
Not used
Fuse 2
Exterior light(s)
7.5 A
Fuse 3
Exterior light(s)
7.5 A
Fuse 4
Engine management
Air conditioning
10.0 A
Fuse 5
ABS
ESP
20.0 A
Fuse 6
ABS
ESP
30.0 A
Fuse 7
Automatic transmission
Manual transmission
7.5 A
Fuse 8
Mirrors
7.5 A
Fuse 9
Exterior lights
Daylight running system
10.0 A
Fuse 10
Exterior lights
Daylight running system
10.0 A
Fuse 11
Daylight running system
15.0 A
Fuse 12
Engine cooling
Charging control
Engine control system
Additional heater
Air conditioning
Security alarm system
15.0 A
Fuse 13
Charging control
Engine control system
Additional heater
20.0 A
Fuse 14
Ignition system
30.0 A
Fuse 15
Engine management
Additional heater
Ignition
Air conditioning
20.0 A
Fuse 16
Engine control
Charging
3.0 A
Fuse 17
Exterior lights
Daylight running system
Instrument panel
15.0 A
Fuse 18
Audio system
Video system
Communication system
Navigation system
Telephone
15.0 A
Fuse 19
Daylight running system
15.0 A
Fuse 20
Multifunction control unit
Instrument panel
Interior lights
Clock
7.5 A
Fuse 21
Not used
Fuse 22
Exterior lights
Daylight running system
7.5 A
Fuse 23
Exterior lights
Daylight running system
7.5 A
Fuse 24
Security system
Multifunction control unit
20.0 A
Fuse 25
Exterior lights
Security system
Multifunction control unit
15.0 A
Fuse 26
Multifunction control unit
Windows
20.0 A
Fuse 27
Multifunction control unit
Horn
Interior light(s)
Instrument panel
10.0 A
Fuse 28
Alternator
3.0 A
Fuse 29
Cigarette lighter
Instrument panel
15.0 A
Fuse 30
Automatic transmission
15.0 A
Fuse 31
Exterior lights
20.0 A
Fuse 32
Mirrors
Windows
7.5 A
Fuse 33
Transmission
Air conditioning
Instrument lighting
Video system
Exterior lights
Navigation system
Telephone
7.5 A
Fuse 34
Sliding roof
20.0 A
Fuse 35
Seats
7.5 A
Fuse 36
Instrument lighting
Windows
30.0 A
Fuse 37
ABS
ESP
3.0 A
Fuse 38
ESP
Air conditioning
Instrument panel
Clock
Multifunction module
Warning system
Alternator
Exterior lights
Interior light(s)
Alarm system
Multifunction control unit
Windows
Instrument panel
Central locking
Front and rear wipers and washers
Supplemental restraint system (SRS)
7.5 A
Fuse 39
Airbag(s)
Seat belt pretensioner
7.5 A
Fuse 40
Instrument lighting
Instrument panel
Exterior lights
Daylight running system
10.0 A
Fuse 41
Transmission
7.5 A
Fuse 42
Windows
Heated windscreen
30.0 A
Fuse 43
Windows
Heated windscreen
30.0 A
Fuse 44
Instrument panel
Clock
Audio system
Video system
Navigation system
Telephone
3.0 A
Fuse 45
ABS
Supplemental restraint system (SRS)
Exterior lights
Transmission
Engine control
15.0 A
Fuse 46
Multifunction control unit
Wash/wipe system
20.0 A
Fuse 47
Multifunction control unit
Wash/wipe system
10.0 A
Fuse 48
Automatic transmission
Parking assistance
Exterior lights
Navigation system
7.5 A
Fuse 49
Heating and ventilation
Air conditioning
30.0 A
Fuse 50
Instrument panel
Exterior lights
20.0 A
Fuse 51
Instrument panel
15.0 A
Fuse 52
Exterior lights
Daylight running system
10.0 A
Fuse 53
Exterior lights
Daylight running system
10.0 A
Fuse 54
Exterior lights
7.5 A
Fuse 55
Not used
Fuse 56
Exterior lights
20.0 A
Relay R1
Main beam
Relay R2
Dipped beam
Relay R3
Daylight running system
Relay R4
Ignition
Relay R5
Cooling fan
Relay R6
Warning system
Relay R7
Heated windscreen
Relay R8
Immobiliser
Relay R9
Powertrain control unit (PCM)
Relay R10
No information is available
Relay R11
Fuel pump
Relay R12
Battery saver
Fuse box diagram (type 3 since 2005).
legend.
Fuse 30
Air conditioning
10.0 A
Fuse 31
Starter motor relay
30.0 A
Fuse 32
Alarm horn
20.0 A
Fuse 33
Not used
Fuse 34
Radio
Instrument panel
3.0 A
Fuse 35
Not used
Fuse 36
ABS valves
20.0 A
Fuse 37
Fuel pump
20.0 A
Fuse 38
Hazard warning lights
15.0 A
Fuse 39
Heated seat(s)
7.5 A
Fuse 40
Brake lights
15.0 A
Fuse 41
ABS pump
30.0 A
Fuse 42
Powertrain control unit (PCM)
3.0 A
Fuse 43
Heated rear windscreen
20.0 A
Fuse 44
Front power windows
30.0 A
Fuse 45
Front wiper
20.0 A
Fuse 46
Transmission control unit
15.0 A
Fuse 47
Light switch
15.0 A
Fuse 48
Horn
Battery saver
15.0 A
Fuse 49
ABS
3.0 A
Fuse 50
Rear wiper
10.0 A
Fuse 51
Mirror(s)
7.5 A
Fuse 52
On-board supply
Radio
DVD player
15.0 A
Fuse 53
Alternator
3.0 A
Fuse 54
Generic electronic module (GEM)
7.5 A
Fuse 55
Reversing light
7.5 A
Fuse 56
Left dipped beam
10.0 A
Fuse 57
Daylight running system relay
15.0 A
Fuse 58
Cigarette lighter
15.0 A
Fuse 59
Airbag
7.5 A
Fuse 60
Heater blower
30.0 A
Fuse 61
Right dipped beam
10.0 A
Fuse 62
Instrument panel
7.5 A
Fuse 63
Ignition switch
15.0 A
Fuse 64
Transmission control unit
7.5 A
Fuse 65
Fog light
20.0 A
Fuse 66
Trailer towing module
Fuse 67
Daylight running system
15.0 A
Fuse 68
Not used
Fuse 69
Dimmer potentiometer
Automatic light unit
Light control
10.0 A
Fuse 70
Not used
Fuse 71
No information is available
Fuse 72
Trailer towing module
Fuse 73
Powertrain control unit (PCM)
15.0 A
Fuse 74
Left parking lights
7.5 A
Fuse 75
Heated mirror(s)
7.5 A
Fuse 76
Heater
Front left window
30.0 A
Fuse 77
Left main beam
10.0 A
Fuse 78
Oxygen sensor
Powertrain control unit (PCM)
20.0 A
Fuse 79
Right parking lights
7.5 A
Fuse 80
Number plate light(s)
7.5 A
Fuse 81
Heater
Front right window
30.0 A
Fuse 82
Right main beam
10.0 A
Relay 17
Automatic light unit
Relay 18
Fuel pump relay
Additional relay, fuel pump
Relay 19
No information is available
Relay 20
Heater
Front window
Relay 21
Starter relay
Relay 22
Powertrain control unit (PCM)
Relay 23
Ignition relay
Relay 24
Engine cooling fan
Relay 25
Not used
Relay 26
Dipped beam relay
Relay 27
Main beam relay
Relay 28
Daylight running system
Fuse box in engine compartment.
fuse box location.
To replace the fuses in the engine compartment, the battery must be removed.
Press the latch
remove the fuse box from the wall of the battery tray.
Then, use a screwdriver to pry out the latch and remove the fuse box cover.
Loosen the two fastening nuts.
And remove the fuse.
fuse box diagram.
legend.
| FA | (80A) Engine coolant heater relay 2 |
| FB | (60A) Engine coolant heater relay 1 – Diesel or Robotic gearbox |
| FC | (60A) Engine coolant heater relay 1, glow plug relay, Preheating (diesel) |
| FD | (40A) Engine coolant blower motor relay or air conditioning |
| FE | (60A) Headlamp high beam relay, headlamp low beam relay, fascia fuse box/relay plate (F24-F31) |
| FF | (60A) Ignition main circuits relay |
| FG | (60A) Engine control (EC) relay, fascia fuse box/relay plate (F14-F20) |
| FH | (60A) Heated windscreen relay, fascia fuse box/relay plate (F4-F8), ABS |
Relay box in engine compartment.
relay box location.
relay box diagram.
legend.
| № | Description |
|---|---|
| R1 | A/C compressor clutch (deactivation when the throttle is fully open) |
| R2 | Engine cooling fan (high speed) |
| R3 | Additional heater |
| R4 | Additional heater |
or
| R1 | Engine coolant heater relay 2 |
| R2 | Engine coolant heater relay 1 |
| R3 | Engine coolant blower motor relay – high speed |
| R4 | Wide open throttle (WOT) relay |
