Fuse box diagram Ford Fiesta 1989-1996

For Fiesta (03) 1989, 1990, 1991, 1992, 1993, 1994 1995, 1996 model year.

Cigarette lighter fuse – fuse box in passenger compartment – Fuse F2/15A

Cigarette lighter fuse – fuse box in passenger compartment – Fuse F17/10A

Fuse box in passenger compartment.

fuse box diagram (1989-1992 LHD)
fuse box diagram (1989-1992 RHD)
fuse box diagram (1992-1996 LHD)
fuse box diagram (1992-1996 RHD)

Fuse box in passenger compartment.

fuse box location.

fuse box diagram (1989-1992 LHD).

legend.

Fuse 1
Electronic engine control system
Diagnostic system
3.0 A
Fuse 2
Interior light(s)
Cigarette lighter
Clock
Radio memory
15.0 A
Fuse 3
Central/double locking
Security system
Heated seats
Hazard warning lights
Direction indicators
20.0 A
Fuse 4
Heated rear windscreen
30.0 A
Fuse 5
Headlight washers
Air conditioning
Engine management (CFI) (30A also used)
10.0 A
Fuse 6
Heated rear windscreen
Heating and ventilation
Air conditioning
Radio
Sunroof
Headlight levelling
Fog lights
Number plate light(s)
Sidelights
Instrument lighting
10.0 A
Fuse 7
Headlight levelling
Fog lights
Number plate light(s)
Sidelights
Instrument lighting
10.0 A
Fuse 8
Headlights
10.0 A
Fuse 9
Headlights
10.0 A
Fuse 10
Headlights
15.0 A
Fuse 11
Headlights
15.0 A
Fuse 12
Heater blower
Reversing light(s)
20.0 A
Fuse 13
Heating and air conditioning
Engine management (CFI and 1.4 EFI)
30.0 A
Fuse 14
Front fog light(s)
Air conditioning
Heated seats (20A also used)
15.0 A
Fuse 15
Horn
15.0 A
Fuse 16
Wiper motor
Windscreen washer pump
(10A also used)
Automatic transmission
Starter system
20.0 A
Fuse 17
Headlights
Reversing lights
Cigarette lighter
Clock
Heated rear windscreen
Airbags
10.0 A
Fuse 18
Power windows
Electric seats
Sunroof
30.0 A
Fuse 19
Engine management
Security system
Air conditioning
20.0 A
Fuse 20
Engine management
10.0 A
Fuse 21
Direction indicators
Hazard warning lights
Security system
10.0 A
Fuse 22
Direction indicators
Hazard warning lights
Security system
10.0 A
Fuse 23
Airbag
Fog lights
10.0 A
Fuse 24
Security system
Central locking
Mirrors
Fog lights (20A also used)
10.0 A
Fuse 25
Fog lights
10.0 A
Fuse 26
Central locking
Security system
15.0 A
Fuse 27
Heated rear windscreen
30.0 A
Fuse 28
Heated rear windscreen
30.0 A
Relay R1
Heated rear windscreen
Relay R2
Front intermittent wash/wipe system
Relay R3
Fuel injection system or supply relay
Relay R4
Headlight washers
Relay R5
Ignition
Relay R6
Immobiliser or fuel pump
Relay R7
Main beam
Relay R8
ABS
Or
ESP control unit
Relay R9
Heated windscreen
Relay R10
Daylight running system
Relay R11
Not used
Relay R12
Not used
Relay R13
Automatic transmission
Horn, XR2i
Relay R14
Heated seats
Relay R15
Fog lights (XR2i)
Relay R16
Dipped beam
Relay R17
Daylight running system

fuse box diagram (1989-1992 RHD).

legend.

Fuse 1
Electronic engine control system
Diagnostic system
3.0 A
Fuse 2
Interior light(s)
Cigarette lighter
Clock
Radio memory
15.0 A
Fuse 3
Central/double locking
Security system
Heated seats
Hazard warning lights
Direction indicators
20.0 A
Fuse 4
Heated rear windscreen
30.0 A
Fuse 5
Headlights
Headlight washers
Air conditioning
Engine management (CFI) (30A also used)
10.0 A
Fuse 6
Headlights
Heated rear windscreen
Heating and ventilation
Air conditioning
Radio
Sunroof
Headlight levelling
Fog lights
Number plate light(s)
Sidelights
Instrument lighting
10.0 A
Fuse 7
Headlight levelling
Fog lights
Number plate light(s)
Sidelights
Instrument lighting
10.0 A
Fuse 8
Headlights
10.0 A
Fuse 9
Headlights
10.0 A
Fuse 10
Headlights
15.0 A
Fuse 11
Headlights
15.0 A
Fuse 12
Heater blower
Reversing light(s)
20.0 A
Fuse 13
Heating and air conditioning
Engine management (CFI and 1.4 EFI)
30.0 A
Fuse 14
Front fog light(s)
Air conditioning
Heated seats (20A also used)
15.0 A
Fuse 15
Horn
15.0 A
Fuse 16
Wiper motor
Windscreen washer pump
(10A also used)
Automatic transmission
Starter system
20.0 A
Fuse 17
Reversing lights
Cigarette lighter
Clock
Heated rear windscreen
Airbags
10.0 A
Fuse 18
Power windows
Electric seats
Sunroof
30.0 A
Fuse 19
Engine management
Security system
Air conditioning
20.0 A
Fuse 20
Engine management
10.0 A
Fuse 21
Direction indicators
Hazard warning lights
Security system
10.0 A
Fuse 22
Direction indicators
Hazard warning lights
Security system
10.0 A
Fuse 23
Airbag
10.0 A
Fuse 24
Security system
Central locking
Mirrors (20A also used)
10.0 A
Fuse 25
Not used
10.0 A
Fuse 26
Central locking
Security system
15.0 A
Fuse 27
Heated rear windscreen
30.0 A
Fuse 28
Heated rear windscreen
30.0 A
Relay R1
Heated rear windscreen
Relay R2
Front intermittent wash/wipe system
Relay R3
Fuel injection system or supply relay
Relay R4
Headlight washers
Relay R5
Ignition
Relay R6
Immobiliser or fuel pump
Relay R7
Main beam
Relay R8
Reduced dipped beam
Relay R9
Not used
Relay R10
Daylight running system
Relay R11
Heated windscreen
Relay R12
ABS
Or
ESP control unit
Relay R13
Automatic transmission
Horn, XR2i
Relay R14
Heated seats
Relay R15
Fog lights (XR2i)
Relay R16
Dipped beam
Relay R17
Reduced dipped beam

fuse box diagram (1992-1996 LHD).

legend.

Fuse 1
Electronic engine control system
Diagnostic system
3.0 A
Fuse 2
Interior light(s)
Cigarette lighter
Clock
Radio memory
15.0 A
Fuse 3
Central/double locking
Security system
Heated seats
Hazard warning lights
Direction indicators
20.0 A
Fuse 4
Heated rear windscreen
30.0 A
Fuse 5
Headlight washers
Air conditioning
Engine management (CFI) (30A also used)
10.0 A
Fuse 6
Heated rear windscreen
Heating and ventilation
Air conditioning
Radio
Sunroof
Headlight levelling
Fog lights
Number plate light(s)
Sidelights
Instrument lighting
10.0 A
Fuse 7
Headlight levelling
Fog lights
Number plate light(s)
Sidelights
Instrument lighting
10.0 A
Fuse 8
Headlights
10.0 A
Fuse 9
Headlights
10.0 A
Fuse 10
Headlights
15.0 A
Fuse 11
Headlights
15.0 A
Fuse 12
Heater blower
Reversing light(s)
20.0 A
Fuse 13
Heating and air conditioning
Engine management (CFI and 1.4 EFI)
30.0 A
Fuse 14
Front fog light(s)
Air conditioning
Heated seats (20A also used)
15.0 A
Fuse 15
Horn
15.0 A
Fuse 16
Wiper motor
Windscreen washer pump
(10A also used)
Automatic transmission
Starter system
20.0 A
Fuse 17
Headlights
Reversing lights
Cigarette lighter
Clock
Heated rear windscreen
Airbags
10.0 A
Fuse 18
Power windows
Electric seats
Sunroof
30.0 A
Fuse 19
Engine management
Security system
Air conditioning
20.0 A
Fuse 20
Engine management
10.0 A
Fuse 21
Direction indicators
Hazard warning lights
Security system
10.0 A
Fuse 22
Direction indicators
Hazard warning lights
Security system
10.0 A
Fuse 23
Airbag
Fog lights
10.0 A
Fuse 24
Security system
Central locking
Mirrors
Fog lights (20A also used)
10.0 A
Fuse 25
Central locking
15.0 A
Fuse 26
Heated rear windscreen
30.0 A
Fuse 27
Heated rear windscreen
30.0 A
Fuse 28
Heated rear windscreen
30.0 A
Fuse 29
Security system
Airbag
Central locking
10.0 A
Fuse 30
Security system
Central locking
Mirrors
20.0 A
Relay R1
Heated rear windscreen
Relay R2
Front intermittent wash/wipe system
Relay R3
Fuel injection system or supply relay
Relay R4
Air conditioning (-> 01/1994)
Headlight washers (from 01/1994)
Relay R5
Ignition
Relay R6
Immobiliser
Relay R7
Main beam
Relay R8
ABS
Or
ESP control unit
Relay R9
Heated windscreen
Relay R10
Daylight running system
Relay R11
Front fog lights
Relay R12
Security system flasher relay
Relay R13
Automatic transmission
Horn, XR2i (-> 01/1994)
Relay R14
Fuel pump
Relay R15
Fog lights (XR2i)
Relay R16
Dipped beam
Relay R17
Daylight running system
Relay R18
Heated seats (Norway, Sweden, Finland, Denmark)
Air conditioning

fuse box diagram (1992-1996 RHD).

legend.

Fuse 1
Electronic engine control system
Diagnostic system
3.0 A
Fuse 2
Interior light(s)
Cigarette lighter
Clock
Radio memory
15.0 A
Fuse 3
Central/double locking
Security system
Heated seats
Hazard warning lights
Direction indicators
20.0 A
Fuse 4
Heated rear windscreen
30.0 A
Fuse 5
Headlights
Headlight washers
Air conditioning
Engine management (CFI) (30A also used)
10.0 A
Fuse 6
Headlights
Heated rear windscreen
Heating and ventilation
Air conditioning
Radio
Sunroof
Headlight levelling
Fog lights
Number plate light(s)
Sidelights
Instrument lighting
10.0 A
Fuse 7
Headlight levelling
Fog lights
Number plate light(s)
Sidelights
Instrument lighting
10.0 A
Fuse 8
Headlights
10.0 A
Fuse 9
Headlights
10.0 A
Fuse 10
Headlights
15.0 A
Fuse 11
Headlights
15.0 A
Fuse 12
Heater blower
Reversing light(s)
20.0 A
Fuse 13
Heating and air conditioning
Engine management (CFI and 1.4 EFI)
30.0 A
Fuse 14
Front fog light(s)
Air conditioning
Heated seats (20A also used)
15.0 A
Fuse 15
Horn
15.0 A
Fuse 16
Wiper motor
Windscreen washer pump
(10A also used)
Automatic transmission
Starter system
20.0 A
Fuse 17
Reversing lights
Cigarette lighter
Clock
Heated rear windscreen
Airbags
10.0 A
Fuse 18
Power windows
Electric seats
Sunroof
30.0 A
Fuse 19
Engine management
Security system
Air conditioning
20.0 A
Fuse 20
Engine management
10.0 A
Fuse 21
Direction indicators
Hazard warning lights
Security system
10.0 A
Fuse 22
Direction indicators
Hazard warning lights
Security system
10.0 A
Fuse 23
Airbag
10.0 A
Fuse 24
Security system
Central locking
Mirrors (20A also used)
10.0 A
Fuse 25
Central locking
15.0 A
Fuse 26
Heated rear windscreen
30.0 A
Fuse 27
Heated rear windscreen
30.0 A
Fuse 28
Heated rear windscreen
20.0 A
Fuse 29
Security system
Airbag
Central locking
10.0 A
Fuse 30
Security system
Central locking
Mirrors
20.0 A
Relay R1
Heated rear windscreen
Relay R2
Front intermittent wash/wipe system
Relay R3
Fuel injection system or supply relay
Relay R4
Air conditioning (-> 01/1994)
Headlight washers (from 01/1994)
Relay R5
Ignition
Relay R6
Immobiliser
Relay R7
Main beam
Relay R8
Reduced dipped beam
Relay R9
Not used
Relay R10
Security system
Relay R11
Heated windscreen
Relay R12
ABS
Or
ESP control unit
Relay R13
Automatic transmission
Horn, XR2i (-> 01/1994)
Relay R14
Fuel pump
Relay R15
Fog lights (XR2i)
Relay R16
Dipped beam
Relay R17
Reduced dipped beam
Relay R18
Heated seats (Norway, Sweden, Finland, Denmark)
Air conditioning

Cookie	Duration	Description
cookielawinfo-checkbox-analytics	11 months	This cookie is set by GDPR Cookie Consent plugin. The cookie is used to store the user consent for the cookies in the category "Analytics".
cookielawinfo-checkbox-functional	11 months	The cookie is set by GDPR cookie consent to record the user consent for the cookies in the category "Functional".
cookielawinfo-checkbox-necessary	11 months	This cookie is set by GDPR Cookie Consent plugin. The cookies is used to store the user consent for the cookies in the category "Necessary".
cookielawinfo-checkbox-others	11 months	This cookie is set by GDPR Cookie Consent plugin. The cookie is used to store the user consent for the cookies in the category "Other.
cookielawinfo-checkbox-performance	11 months	This cookie is set by GDPR Cookie Consent plugin. The cookie is used to store the user consent for the cookies in the category "Performance".
viewed_cookie_policy	11 months	The cookie is set by the GDPR Cookie Consent plugin and is used to store whether or not user has consented to the use of cookies. It does not store any personal data.
