For Courier 1995, 1996, 1997, 1998, 1999, 2000, 2001, 2002 model year.
| Cigarette lighter fuse – fuse box in passenger compartment – Fuse F1/15A |
Fuse box in passenger compartment.
fuse box location.
fuse box diagram (pre 1999).
Assignment of the fuses.
| 1 | – |
| 2 | Windscreen wiper intermittent relay (red) |
| 3 | Interior lamp delay relay (yellow) |
| 4 | – |
| 5 | Ignition main circuits relay (yellow/green) |
| 6 | Heated rear window relay (yellow) |
| 7 | Headlamp dim-dip relay I (green) |
| 8 | Side lamps ‘on’ warning buzzer (white) |
| 9 | Heated windscreen relay (grey) |
| 10 | Alarm system flasher relays (green) |
| 11 | Headlamp dim-dip relay II (blue) |
| 12 | – |
| 13 | – |
| 14 | – |
| 15 | – |
| F1 | (15A) Cigarette lighter |
| F2 | (30A) Heated rear window, door mirror heater |
| F3 | – |
| F4 | (10A) Interior lamps, clock, audio memory |
| F5 | (20A) Horn, alarm system |
| F6 | (10A) Side lamps – left |
| F7 | (10A) Side lamps – right |
| F8 | (15A) Central locking, door mirror adjustment |
| F9 | (15A) Seat adjustment |
| F10 | (15A) Seat heater, sunroof |
| F11 | (30A) Central locking, electric windows |
| F12 | (20A) Windscreen wiper motor, windscreen washers |
| F13 | (15A) Stop lamps, instrument panel |
| F14 | (10A) Airbag |
| F15 | (10A) Door mirror heater |
| F16 | (30A) Heater blower motor |
| F17 | (15A) Indicators |
| F18 | (15A) Ignition |
| F19 | (10A) Engine management, alarm system, audiounit |
| F20 | (10A) Dim dip |
| F21 | – |
| F22 | (10A) Diagnostic link |
| F41 | (10A) Rear fog lamp |
| F42 | (10A) Rear fog lamp |
| F43 | Headlamp high beam blocking diode |
| F44 | (20A) Central locking control module |
| F45 | (15A) Boot lid/tailgate release |
Fuse and relay box in passenger compartment, with double central locking, (06/1999 – 03/2000).
legend.
Fuse 1
Instrument panel
Cigarette lighter
15.0 A
Fuse 2
Heating and ventilation
Air conditioning
Instrument panel
Clock
Interior lights
7.5 A
Fuse 3
Multifunction modules
10.0 A
Fuse 4
Windows
20.0 A
Fuse 5
Horn
Exterior lights
15.0 A
Fuse 6
Windows
Heating and ventilation
Air conditioning
Instrument lighting
Audio
Interior lights
Daylight running system
10.0 A
Fuse 7
Instrument lighting
10.0 A
Fuse 8
Multifunction modules
Mirrors
15.0 A
Fuse 9
Exterior lights
25.0 A
Fuse 10
Seats
Sunroof
15.0 A
Fuse 11
Instrument lighting
Windows
30.0 A
Fuse 12
Multifunction modules
Wiper system
20.0 A
Fuse 13
ABS
Engine management (1.2/1.4)
Heating and ventilation
Air conditioning
Instrument panel
Parking assistance
Charging system
Exterior lights
Daylight running system
Windows
15.0 A
Fuse 14
Safety system
10.0 A
Fuse 15
Mirrors
7.5 A
Fuse 16
Heating and ventilation
Air conditioning
30.0 A
Fuse 17
Exterior lights
15.0 A
Fuse 18
Alarm system
Multifunction modules
Fuel system
Ignition
Engine management
Heating and ventilation
15.0 A
Fuse 19
ABS
Instrument panel
Clock
Audio
7.5 A
Fuse 20
Exterior lights
20.0 A
Fuse 21
Mirrors
Central locking
15.0 A
Fuse 22
Audio
10.0 A
Fuse 42
Multifunction modules
15.0 A
Fuse 43
Exterior lights
Daylight running system
10.0 A
Fuse 49
Exterior lights
Daylight running system
20.0 A
Fuse 50
Exterior lights
25.0 A
Relay R1
Ignition
Relay R2
Daylight running system
Relay R3
Daylight running system, parking light
Relay R4
Heated windscreen
Relay R5
Heated rear windscreen
Fuse and relay box in passenger compartment, with remote central locking, (05/2000 – 02/2001).
legend.
Fuse 1
Instrument panel
Cigarette lighter
15.0 A
Fuse 2
Heating and ventilation
Air conditioning
Instrument panel
Clock
Interior lights
Security system
7.5 A
Fuse 3
Multifunction modules
Exterior lights
Security system
10.0 A
Fuse 4
Windows
20.0 A
Fuse 5
Horn
Exterior lights
15.0 A
Fuse 6
Windows
Heating and ventilation
Air conditioning
Instrument lighting
Audio
Interior lights
Exterior lights
7.5 A
Fuse 7
Instrument lighting
Exterior lights
7.5 A
Fuse 8
Multifunction modules
Mirrors
Exterior lights
Central locking
Interior lights
15.0 A
Fuse 9
Exterior lights
Interior lights
Instrument lighting
25.0 A
Fuse 10
Seats
Sunroof
15.0 A
Fuse 11
Instrument lighting
Windows
30.0 A
Fuse 12
Multifunction modules
Wiper system
20.0 A
Fuse 13
ABS
Heating and ventilation
Air conditioning
Instrument panel
Parking assistance
Charging system
Exterior lights
Daylight running system
Windows
Navigation system
15.0 A
Fuse 14
Safety system
10.0 A
Fuse 15
Mirrors
Windows
7.5 A
Fuse 16
Heating and ventilation
Air conditioning
30.0 A
Fuse 17
Exterior lights
15.0 A
Fuse 18
Alarm system
Multifunction modules
Central locking
Wiper system
Engine management
Ignition
Fuel system
15.0 A
Fuse 19
Instrument panel
Clock
Audio
Navigation system
Telephone
7.5 A
Fuse 20
Exterior lights
Interior lights
Instrument panel
20.0 A
Fuse 21
Mirrors
Central locking
15.0 A
Fuse 22
Audio
Communication network
Navigation system
Telephone
10.0 A
Fuse 42
No information is available
Fuse 43
Daylight running system
10.0 A
Fuse 49
No information is available
Fuse 50
No information is available
25.0 A
Relay R1
Heated windscreen
Relay R2
Ignition
Relay R3
Heated rear windscreen
Fuse and relay box in passenger compartment, with remote central locking, (02/2001 – 2002).
legend.
Fuse 1
Instrument panel
Cigarette lighter
15.0 A
Fuse 2
Heating and ventilation
Air conditioning
Instrument panel
Clock
Interior lights
Security system
7.5 A
Fuse 3
Multifunction modules
Exterior lights
Security system
10.0 A
Fuse 4
Windows
20.0 A
Fuse 5
Horn
Exterior lights
15.0 A
Fuse 6
Windows
Heating and ventilation
Air conditioning
Instrument lighting
Audio
Interior lights
Exterior lights
7.5 A
Fuse 7
Instrument lighting
Exterior lights
7.5 A
Fuse 8
Multifunction modules
Mirrors
Exterior lights
Central locking
Interior lights
15.0 A
Fuse 9
Exterior lights
Interior lights
Instrument lighting
25.0 A
Fuse 10
Seats
Sunroof
15.0 A
Fuse 11
Instrument lighting
Windows
30.0 A
Fuse 12
Multifunction modules
Wiper system
20.0 A
Fuse 13
ABS
Heating and ventilation
Air conditioning
Instrument panel
Parking assistance
Charging system
Exterior lights
Daylight running system
Windows
Navigation system
15.0 A
Fuse 14
Safety system
10.0 A
Fuse 15
Mirrors
Windows
7.5 A
Fuse 16
Heating and ventilation
Air conditioning
30.0 A
Fuse 17
Exterior lights
15.0 A
Fuse 18
Alarm system
Multifunction modules
Central locking
Wiper system
Engine management
Ignition
Fuel system
15.0 A
Fuse 19
Instrument panel
Clock
Audio
Navigation system
Telephone
7.5 A
Fuse 20
Exterior lights
Interior lights
Instrument panel
20.0 A
Fuse 21
Mirrors
Central locking
15.0 A
Fuse 22
Audio
Communication network
Navigation system
Telephone
10.0 A
Fuse 43
Daylight running system
10.0 A
Fuse 44
Central locking
15.0 A
Relay R1
Tailgate/boot lock
Relay R2
Heated rear windscreen
Relay R3
Ignition
Relay R4
Daylight running system parking light or tailgate/boot lock
Relay R5
Heated windscreen
Relay R6
Daylight running system (DRL
Fuse box in engine compartment.
fuse box location.
fuse box diagram (pre 1999).
legend.
Fuse 23
Left main beam
10.0 A
Fuse 24
Right main beam
10.0 A
Fuse 25
Left dipped beam
10.0 A
Fuse 26
Right dipped beam
10.0 A
Fuse 27
Oxygen sensor
15.0 A
Fuse 28
Engine management
15.0 A
Fuse 29
Reversing light(s)
Air conditioning
Front fog lights
20.0 A
Fuse 30
ABS control unit, terminal 7
3.0 A
Fuse 31
ABS control unit, terminal 25
30.0 A
Fuse 32
Powertrain control unit (PCM)
3.0 A
Fuse 33
ABS control unit, terminal 9
30.0 A
Fuse 34
Transmission brake solenoid
25.0 A
Fuse 35
Fuel pump
10.0 A
Fuse 36
Cooling fan
Starter motor
60.0 A
Fuse 37
No information is available
40.0 A
Fuse 38
Ignition switch safety relay
60.0 A
Fuse 39
Fuses 1 – 5
60.0 A
Fuse 40
Ignition switch
Light switch
60.0 A
Relay R1
Air-conditioning shut-off
Relay R2
Engine management
Relay R3
No information is available
Relay R4
Front fog lights
Relay R5
Dipped beam
Relay R6
Main beam
Relay R7
Air conditioning
Relay R8
Cooling fan, stage 2
Relay R9
Cooling fan
Relay R10
No information is available
Relay R11
Starter motor
Relay R12
Starter motor
Fuse and relay box in engine compartment, (06/1999 – 03/2000).
legend.
Fuse 23
Exterior lights
Daylight running system
10.0 A
Fuse 24
Exterior lights
Daylight running system
10.0 A
Fuse 25
Exterior lights
Daylight running system
10.0 A
Fuse 26
Exterior lights
Daylight running system
10.0 A
Fuse 27
Engine management (15A also used)
10.0 A
Fuse 28
Cooling system
Fuel system
Engine management
Air conditioning
Alarm system
15.0 A
Fuse 29
Air conditioning
Exterior lights
20.0 A
Fuse 30
ABS
Or
ESP control unit
3.0 A
Fuse 31
ABS
Or
ESP control unit
30.0 A
Fuse 32
Engine management
3.0 A
Fuse 33
ABS
Or
ESP control unit
30.0 A
Fuse 34
Engine management
30.0 A
Fuse 35
Engine management
10.0 A
Fuse 36
Cooling system
Ignition system
Engine management
Air conditioning
60.0 A
Fuse 37
Cooling system
Air conditioning
40.0 A
Fuse 38
Instrument lighting
30.0 A
Fuse 39
Instrument panel
Horn
Clock
Audio
Exterior lights
Interior lights
Daylight running system
Data link connector
60.0 A
Fuse 40
Ignition
60.0 A
Relay R1
Air conditioning
Relay R2
Supply relay
Relay R3
Fuel pump
Relay R4
Fog lights
Relay R5
Dipped beam
Relay R6
Main beam
Relay R7
Air conditioning
Relay R8
Cooling fan, high speed
Relay R9
Cooling fan
Relay R10
Immobiliser
Relay R11
Additional relay
Fuse and relay box in engine compartment, (05/2000 – 2002).
legend.
Fuse 23
Exterior lights
Daylight running system
10.0 A
Fuse 24
ABS
Or
ESP control unit
20.0 A
Fuse 25
Exterior lights
Daylight running system
10.0 A
Fuse 26
ABS
Engine cooling system
20.0 A
Fuse 27
Exterior lights
Daylight running system
10.0 A
Fuse 28
ABS
Or
ESP control unit
3.0 A
Fuse 29
Exterior lights
Daylight running system
10.0 A
Fuse 30
Security system
Power steering
Engine cooling system
Engine management
Fuel system
Air conditioning
Instrument panel
15.0 A
Fuse 31
Engine management
Fuel system
Ignition (20A also used)
10.0 A
Fuse 32
Exterior lights
Air conditioning
20.0 A
Fuse 33
Engine management
3.0 A
Fuse 34
Wiper system
Sunroof
Engine management (SE engines)
30.0 A
Fuse 35
Not used
Fuse 36
Security system
Remote central locking
Wiper system
Engine management (15A also used)
10.0 A
Fuse 37
No information is available
3.0 A
Fuse 38
Airbags
30.0 A
Fuse 51
Daylight running system
Mirrors
Instrument panel
Central locking
Airbags
Engine cooling system
Ignition
Engine management
Air conditioning
60.0 A
Fuse 52
Daylight running system
Airbags
Engine cooling system
40.0 A
Fuse 53
No information is available
60.0 A
Fuse 54
Airbags
60.0 A
Fuse 55
Instrument panel
60.0 A
Fuse 56
No information is available
60.0 A
Relay K46
Cooling fan, high speed
Relay K158
Air conditioning
Relay K32
Air conditioning
Relay K26
Fog lights
Relay K157
Additional relay
Relay K70
Not used
Relay K167
Not used
Relay K45
Cooling fan
Relay K94
Immobiliser
Relay K36
Dipped beam
Relay K13
Power save relay
Relay K37
Main beam
Relay K219
Power save relay
Relay K69
Not used
Relay K4
Fuel pump
