For Ford Ka (07) 1996, 1997, 1998, 1999, 2000, 2001, 2002, 2003, 2004, 2005, 2006, 2007, 2008 model year.
| Cigarette lighter — interior—fuse box F5/15A |
menu
Fuse box in the passenger compartment.
- circuit diagram of the fuse box (1996)
- circuit diagram of the fuse box (01.1997-08.1997)
- circuit diagram of the fuse box (09.1997-08.1998)
- circuit diagram of the fuse box (09.1998-01.1999)
- circuit diagram of the fuse box (02.1999-2001)
- fuse box diagram (2000-2008)
Fuse box in the passenger compartment.
location of the fuse box.
The fuse box is located under the instrument panel to the left of the steering column.
circuit of the fuse box (1996).
Purpose of fuses.
| 1 | Electric fan relay of the engine cooling system |
| 2 | Intermittent wiper relay |
| 3 | – |
| 4 | – |
| 5 | Main ignition circuit relays |
| 6 | Rear window heating relay |
| 7 | Starter relay |
| 8 | Warning buzzer for switching on the headlights |
| 9 | Low beam relay for headlamps |
| 10 | High beam relay for headlights |
| 11 | Motor Control Relay (EC) |
| 12 | Fuel pump relay |
| 13 | AC Relay |
| 14 | Motor Control Relay Diode (EC) |
| F1 | (20A) Rear window heating-without ABS/central locking |
| F2 | (10A) Audio system, clock, interior lighting lamps, Data link connector (DLC), Air conditioning (AC) – with ABS |
| F3 | (10A) Data Link Connector (DLC) (without ABS) |
| F4 | (3A) Engine Management Module (ECM) |
| F5 | (15A) Cigarette Lighter |
| F6 | (10A) Left side / rear lights, instrument panel illumination, headlight corrector, warning buzzer for turning on the headlights |
| F7 | (10A) Right side / rear lights, license plate lighting |
| F8 | (10A) Left headlight-low beam |
| F9 | (10A) Right headlight-low beam |
| F10 | (10A) Left headlight-high beam, instrument panel |
| F11 | (10A) Right headlight-high beam |
| F12 | (30A) Heater fan motor, AC recirculation |
| F13 | (15A) Light switch (headlights/fog lights), ABS, reverse lights, brake lights, dashboard |
| F14 | (30A) Power windows |
| F15 | (20A) Light switch (headlamps/fog lights) |
| F16 | (20A) Windscreen Wiper/Washer |
| F17 | (10A) Air conditioning( AC), engine control, instrument panel, main ignition circuit relay |
| F18 | (10A) SRS control unit |
| F19 | (10A) Fuel Pump |
| F20 | (15A) Engine control, Air conditioning (AC) |
| F21 | (20A) Alarm, audible alarm (AC) |
| F22 | (10A) Indicators |
| F23 | (40A) Ignition switch |
| F24 | (10A) air conditioner / heater |
| F26 | (10A) Audio System |
| F27 | (10A) Heated Oxygen Sensor (HO2S) |
| F28 | (3A) Anti-lock braking system (ABS) |
| F29 | (30A) Motor of the engine cooling system fan-without AC |
| F30 | (15A) Central locking — without ABS |
| F32 | (30A) Anti-lock braking system (ABS) |
Circuit diagram of the fuse box (01.1997-08.1997).
legend.
| 1 | Electric fan relay of the engine cooling system |
| 2 | Intermittent wiper relay |
| 3 | Engine oil pressure indicator light switch |
| 4 | – |
| 5 | Main ignition circuit relays |
| 6 | Rear window heating relay |
| 7 | Starter relay |
| 8 | Warning buzzer for switching on the headlights |
| 9 | Headlamp low beam relay |
| 10 | Headlamp high beam relay |
| 11 | Engine control (EC) relay |
| 12 | Fuel pump relay |
| 13 | AC relay |
| 14 | Engine control (EC) relay diode |
| F1 | (20A) Heated rear window, central locking |
| F2 | (10A) Data link connector (DLC), interior lamps, clock, AC/heater, audio system |
| F3 | (30A) Anti-lock brake system (ABS) |
| F4 | (3A) Engine control module (ECM) |
| F5 | (15A) Cigarette lighter |
| F6 | (10A) Headlamp adjustment, headlamps’on’warning buzzer, LH side/tail lamps, fascia illumination |
| F7 | (10A) RH side/tail lamps, licence plate lamps |
| F8 | (10A) LH headlamp – low beam |
| F9 | (10A) RH headlamp – low beam |
| F10 | (10A) LH headlamp – high beam, instrument panel |
| F11 | (10A) RH headlamp – high beam |
| F12 | (30A) Heater blower motor, AC recirculation |
| F13 | (15A) Engine oil pressure warning lamp relay – with ABS |
| F14 | (30A) Electric windows |
| F15 | (20A) Light switch (headlamps/fog lamps) |
| F16 | (20A) Intermittent wiper relay, windscreen wiper/washer |
| F17 | (10A) Air conditioning / heater, engine control, instrument panel, main ignition circuit relay |
| F18 | (10A) SRS control unit |
| F19 | (10A) Fuel Pump |
| F20 | (15A) Engine control system, immobilizer, cooling fan motor-AC |
| F21 | (30A) Motor of the engine cooling system fan-without AC |
| F22 | (10A) Indicators |
| F23 | (30A) Anti-lock braking system (ABS) |
| F24 | (40A) Ignition switch |
| F26 | (10A) Audio System, Motor Control Module (ECM) |
| F27 | (10A) Heated Oxygen Sensor (HO2S) |
| F28 | (3A) Anti-lock braking system (ABS) |
| F29 | (20A) Emergency alarm, beep |
| F30 | (10A) Rear fog lamps |
Circuit diagram of the fuse box (09.1997-08.1998).
legend.
| 1 | Electric fan relay of the engine cooling system |
| 2 | Intermittent wiper relay |
| 3 | Engine oil pressure indicator light switch |
| 4 | – |
| 5 | Main ignition circuit relays |
| 6 | Rear window heating relay |
| 7 | Starter relay |
| 8 | Warning buzzer for switching on the headlights |
| 9 | Low beam relay for headlamps |
| 10 | High beam relay for headlights |
| 11 | Motor Control Relay (EC) |
| 12 | Fuel pump relay |
| 13 | AC Relay |
| 14 | Motor Control Relay Diode (EC) |
| F1 | (20A) Rear window heating, central locking |
| F2 | (10A) Data Link Connector (DLC), interior lighting lamps, clock, air conditioner / heater, audio system |
| F3 | (30A) Anti-lock braking system (ABS) |
| F4 | (3A) Engine Management Module (ECM) |
| F5 | (15A) Cigarette Lighter |
| F6 | (10A) Headlight adjustment, warning buzzer for switching on the headlights, left side / rear lights, instrument panel illumination |
| F7 | (10A) Right side / rear lights, license plate lighting |
| F8 | (10A) Left headlight-low beam |
| F9 | (10A) Right headlight-low beam |
| F10 | (10A) Left headlight-high beam, instrument panel |
| F11 | (10A) Right headlight-high beam |
| F12 | (30A) Heater fan motor, AC recirculation |
| F13 | (15A) Engine Oil Pressure indicator lamp Switch – with ABS |
| F14 | (30A) Power windows |
| F15 | (20A) Light switch (headlamps/fog lights) |
| F16 | (20A) Windscreen wiper intermittent relay, windscreen wash/wipe system |
| F17 | (10A) AC/heater, engine management, instrument panel, ignition main circuits relay |
| F18 | (10A) SRS control module |
| F19 | (10A) Fuel pump |
| F20 | (15A) Engine management, immobilizer, engine coolant blower motor – with AC |
| F21 | (30A) Engine coolant blower motor (without AC) |
| F22 | (10A) Indicators |
| F23 | (30A) Anti-lock brake system (ABS) |
| F24 | (40A) Ignition switch |
| F25 | (20A) Hazard warning lamps, horn |
| F26 | (10A) Audio system, engine control module(ECM) |
| F27 | (10A) Heated oxygen sensor (HO2S) |
| F29 | (10A) Rear fog lamps |
| F30 | (3A) Anti-lock brake system (ABS) |
Fuse box diagram (09.1998-01.1999).
legend.
| 1 | Engine coolant blower motor relay – without AC |
| 2 | Windscreen wiper intermittent relay |
| 3 | – |
| 4 | – |
| 5 | Ignition main circuits relay |
| 6 | Heated rear window relay |
| 7 | Starter motor relay |
| 8 | Headlamps ‘on’ warning buzzer |
| 9 | Headlamp low beam relay |
| 10 | Headlamp high beam relay |
| 11 | Engine control (EC) relay |
| 12 | Fuel pump relay |
| 13 | AC relay |
| 14 | Engine control (EC) relay diode |
| F1 | (20A) Heated rearwindow, central locking, sunroof |
| F2 | (10A) Data link connector (DLC), interior lamps, clock, AC/heater, audio system |
| F3 | (30A) Anti-lock brake system (ABS) |
| F4 | (3A) Engine control module (ECM) |
| F5 | (15A) Cigarette lighter |
| F6 | (10A) Headlamp adjustment, headlamps ‘on’ warning buzzer, LH side/tail lamps, fascia illumination |
| F7 | (10A) RH side/tail lamps, licence plate lamps |
| F8 | (10A) LH headlamp – low beam |
| F9 | (10A) RH headlamp – low beam |
| F10 | (10A) LH headlamp – high beam, instrument panel |
| F11 | (10A) RH headlamp – high beam |
| F12 | (30A) Heater blower motor, AC recirculation |
| F13 | (15A) Light switch (headlamps/fog lamps), reversing lamps, stop lamps |
| F14 | (30A) Electric windows |
| F15 | (20A) Light switch (headlamps/fog lamps) |
| F16 | (20A) Windscreen Cleaner/Washer, Rear window cleaner/washer |
| F17 | (10A) Air conditioning / heater, engine control, instrument panel, rear fog lamp switch, main ignition circuit relay |
| F18 | (10A) SRS control unit |
| F19 | (10A) Fuel Pump |
| F20 | (15A) Electric fan relay engine cooling system, engine control system, immobilizer-without air conditioning |
| F21 | (30A) Motor of the engine cooling system fan-without AC |
| F22 | (10A) Indicators |
| F23 | (30A) Anti-lock braking system (ABS) |
| F24 | (40A) Ignition switch |
| F25 | (20A) Emergency alarm, beep |
| F26 | (10A) Audio system, sunroof |
| F27 | (10A) Heated Oxygen Sensor (HO2S) |
| F29 | (10A) Rear fog lamps |
| F30 | (3A) Anti-lock braking system (ABS) |
Circuit diagram of the fuse box (02.1999-2001).
legend.
| 1 | Motor relay of the engine cooling system fan-without AC |
| 2 | Intermittent wiper relay |
| 3 | – |
| 4 | Cigarette lighter relay |
| 5 | Main ignition circuit relays |
| 6 | Rear window heating relay |
| 7 | Starter relay |
| 8 | Warning buzzer for switching on the headlights |
| 9 | Low beam relay for headlamps |
| 10 | High beam relay for headlights |
| 11 | Fuel pump relay |
| 12 | AC Relay |
| 13 | Motor Control Relay (EC) |
| 14 | Tailgate opening relay |
| 15 | – |
| F1 | (20A) Rear window heating, central locking, sunroof, rear view mirrors (with central locking) |
| F2 | (10A) Data Link Connector (DLC), interior lighting lamps, clock, air conditioner / heater, audio system |
| F3 | (30A) Anti-lock braking system (ABS) |
| F4 | (3A) Engine Management Module (ECM) |
| F5 | (15A) Cigarette Lighter |
| F6 | (10A) Right license plate lamp (09/99^), headlight corrector, warning buzzer for switching on the headlights, left side/rear lights, instrument panel illumination |
| F7 | (10A) License plate light bulbs (^08/99), right side / rear lights |
| F8 | (10A) Left headlight-low beam |
| F9 | (10A) Right headlight-low beam |
| F10 | (10A) Left headlight-high beam, instrument panel |
| F11 | (10A) Right headlight-high beam |
| F12 | (30A) Heater fan motor, AC recirculation |
| F13 | (15A) Light switch (headlights/fog lights), reverse lights, brake lights |
| F14 | (30A) Power windows |
| F15 | (20A) Light switch (headlamps/fog lights) |
| F16 | (20A) Windscreen Cleaner/Washer, Rear window cleaner/washer |
| F17 | (10A) Air conditioning / heater, engine control, ABS, instrument panel, main ignition circuit relay |
| F18 | (10A) SRS control unit |
| F19 | (10A) Fuel Pump |
| F20 | (15A) Engine control system, immobilizer, electric fan relay engine cooling system-without air conditioning |
| F21 | (30A) Motor of the engine cooling system fan-without AC |
| F22 | (10A) Indicators |
| F23 | (20A) Emergency alarm, beep |
| F24 | (40A) Ignition switch |
| F25 | (30A) Anti-lock braking system (ABS) |
| F26 | – |
| F27 | (10A) Trunk lid opening relay |
| F28 | (10A) Exterior rearview mirrors |
| F29 | (10A) Rear fog lamps |
| F30 | (10A) Heated Oxygen Sensor (HO2S) 1 |
| F31 | – |
| F32 | – |
| F33 | – |
| F34 | – |
| F35 | (10A) Audio system, sunroof |
| F36 | (3A) Anti-lock braking system (ABS) |
Circuit diagram of the fuse box (2000-2008).
legend.
| 1 | Motor cooling system electric fan relay 1-without AC |
| 2 | Intermittent wiper relay |
| 3 | Interior lighting relay – with remote central locking |
| 4 | Fog lamp relay |
| 5 | Main ignition circuit relays |
| 6 | Rear window heating relay |
| 7 | Starter motor inhibitor switch relay |
| 8 | Headlamps ‘on’ warning buzzer |
| 9 | Headlamp low beam relay |
| 10 | Headlamp high beam relay |
| 11 | Engine control (EC) relay |
| 12 | Fuel pump (FP) relay |
| 13 | AC relay |
| 14 | Alarm system flasher relay – LH – with remote central locking |
| 15 | Alarm system flasher relay – RH – with remote central locking |
| F1 | (20A) Heated rear window, central locking |
| F2 | (10A) Audio system, clock, data link connector (DLC), heater/air conditioning (AC), instrument illumination, interior lamps |
| F3 | (30A) Anti-lock brake system (ABS) |
| F4 | (3A) Engine management |
| F5 | (15A) Cigarette lighter, instrument panel |
| F6 | (10A) Instrument illumination, LH side/tail lamps |
| F7 | (10A) RH side/tail lamps |
| F8 | (10A) LH headlamp – low beam |
| F9 | (10A) RH headlamp – low beam |
| F10 | (10A) LH headlamp – high beam, instrument panel |
| F11 | (10A) RH headlamp – high beam |
| F12 | (30A) Heater blower motor |
| F13 | (15A) Light switch (headlamps/fog lamps), reversing lamps, stop lamps |
| F14 | (30A) Electric windows |
| F15 | (20A) Light switch (headlamps/fog lamps) |
| F16 | (15A/20A) Alarm system, heated windshield, windscreen wiper/washer |
| F17 | (10A/15A) Engine control, heater/air conditioner (AC), dashboard, interior lighting |
| F18 | (10A) SRS control unit |
| F19 | (10A/25A) Engine control, Fuel pump |
| F20 | (15A) Engine control system, cooling fan motor-without air conditioning |
| F21 | (20A/30A) Front fog lights (1,3 Siemens), electric motor fan-without AC (1,3 EECV) |
| F22 | (10A) Indicators |
| F23 | (20A) Emergency alarm, beep |
| F24 | (40A) Ignition switch |
| F25 | (30A) Anti-lock braking system (ABS) |
| F26 | (3A) Generator (03.07^) |
| F27 | (10A) Alarm, trunk lid opening relay |
| F28 | (10A) Electric exterior mirrors |
| F29 | (10A) Rear fog lamps |
| F30 | (10A) Motor control |
| F31 | – |
| F32 | (15A) Sunroof |
| F33 | (15A) Alarm system (03.07^) |
| F34 | (30A) Motor of the engine cooling system fan-without AC |
| F35 | (10A) Audio system, instrument panel, sunroof |
| F36 | (3A) Anti-lock braking system (ABS) |
