Fuses and Relay Citroen Jumpy 2007-2016

For Citroen Jumpy /Dispatch (G9) 2007, 2008, 2009, 2010, 2011, 2012, 2013, 2014, 2015, 2016 model year.

MENU

Fuse box No. 1 in passenger compartment, (type 1).

Fuse box No. 1 in passenger compartment, (type 2).

Fuse box No. 2 in passenger compartment.

Fuse box No. 3 in passenger compartment.

Fuse box No. 1 in engine compartment.

Fuse box No. 2 in engine compartment (type 1).

Fuse box No. 2 in engine compartment (type 2).

Additional fuse in luggage compartment.

Footwell fuse box.​

Fuse box No. 1 in passenger compartment, (type 1).

fuse box diagram.

Fuse 1
Rear wiper motor
15.0 A
Fuse 3
Airbag control unit
5.0 A
Fuse 4
Cruise control switch
Diagnostic connector
Air conditioning
Adaptive headlights
Headlights
Steering angle sensor
Coolant pump
Rear wiper relay
ESP accelerometer gyroscope
Fuel additive pump
10.0 A
Fuse 5
Driver’s side power window
Electric mirror controls
Power window switch, front passenger
30.0 A
Fuse 6
Not used
Fuse 7
Courtesy light(s)
Glovebox illumination switch
Front left vanity light
Rear courtesy light(s)
Front right vanity light
Audio system
5.0 A
Fuse 8
Alarm control unit
Audio system
Radio
Telephone
Alarm siren
Trailer fuse box
20.0 A
Fuse 9
Cigarette lighter
Rear 12V socket
30.0 A
Fuse 10
Controls under the steering wheel
Suspension control unit
Instrument panel
15.0 A
Fuse 11
Diagnostic connector
Ignition switch
15.0 A
Fuse 12
Parking assistance
Airbag control unit
Seat belt control unit
Handsfree kit
15.0 A
Fuse 13
Fuse box in engine compartment
Trailer fuse box
5.0 A
Fuse 14
Air-conditioning control unit
Instrument panel
Rain and light sensor
Air-conditioning control panel
15.0 A
Fuse 15
Tailgate/boot release relay
Door latch assembly
30.0 A
Fuse 17
Heated rear windscreen
Electric mirrors
Heated rear windscreen, left side
Heated rear windscreen, right side
10.0 A
16
Shunt

Fuse box No. 1 in passenger compartment, (type 2).

fuse box diagram.

Fuse 1
Rear wiper
15.0 A
Fuse 2
No information is available
Fuse 3
Airbag control unit
5.0 A
Fuse 4
Steering angle sensor
ESP sensor
Rear wiper relay
Diagnostic socket
Clutch switch
Air-conditioning control panel
Headlight levelling
Diesel particulate filter additive pump
10.0 A
Fuse 5
Electric mirrors
Power window, passenger’s side
30.0 A
Fuse 6
Driver’s power window
Passenger’s power window
30.0 A
Fuse 7
Interior light(s)
Glovebox illumination
5.0 A
Fuse 8
Multifunction display
Alarm siren
Audio system
CD changer
Telephone
20.0 A
Fuse 9
Front cigarette lighter
Diagnostic socket
30.0 A
Fuse 10
Height sensor
Steering wheel controls
Instrument panel
15.0 A
Fuse 11
Diagnostic socket
Ignition switch
15.0 A
Fuse 12
Handsfree kit
Airbag control unit
Parking assistance control unit
15.0 A
Fuse 13
Fuse box in engine compartment
Trailer control unit
5.0 A
Fuse 14
Rain sensor
Rear air conditioning
Automatic air conditioning
Instrument panel
15.0 A
Fuse 15
No information is available
16
No information is available
Fuse 17
Heated rear windscreen
Heated mirror(s)
10.0 A

Fuse box No. 2 in passenger compartment.

Fuse 1
Heated front seats
30.0 A
Fuse 2
Rear 12V socket
20.0 A
Fuse 3
Trailer fuse box
(50A also used)
40.0 A
Fuse 4
Not used

Fuse box No. 3 in passenger compartment.

Fuse 36
Tailgate/boot release relay
15.0 A
Fuse 37
Tailgate/boot release relay
10.0 A
Fuse 38
Rear wiper relay
20.0 A
Fuse 39
Coolant pump relay
10.0 A
Fuse 40
Rear-view mirror
5.0 A

Fuse box No. 1 in engine compartment.

Fuse FL1
Power steering pump
100.0 A
Fuse FL2
Cooling fan, high-speed relay
60.0 A
Fuse FL3
Cooling fan relay, left side
60.0 A
Fuse FL4
Suspension control unit
40.0 A
Fuse FL5
Preheating control unit
100.0 A
Fuse FL6
Not used

Fuse box No. 2 in engine compartment (type 1).

Fuse 1
Main relay
20.0 A
Fuse 2
Horns
15.0 A
Fuse 3
Front and rear windscreen washers
10.0 A
Fuse 4
Headlight washer pump
20.0 A
Fuse 5
Engine control unit
Diesel fuel heater
Fuel additive pump
Fuel pump
15.0 A
Fuse 6
Mass airflow meter
Cooling fan, high-speed relay
Brake pedal switch
Power steering pump
Transmission switch
Selector lever lock solenoid
10.0 A
Fuse 7
ABS/ESP control unit
10.0 A
Fuse 8
Starter solenoid
20.0 A
Fuse 9
Brake pedal switch
10.0 A
Fuse 10
Turbo pressure control solenoid
Engine control unit
Water in fuel sensor
Turbo regulation solenoid
30.0 A
Fuse 11
Heating and air conditioning
Blower, additional heater
40.0 A
Fuse 12
Front wiper control
30.0 A
Fuse 13
Fuses on the BSI (Intelligent power distribution module)
40.0 A
Fuse 14
Not used
30.0 A
Fuse 15
Right main beam
10.0 A
Fuse 16
Left main beam
10.0 A
Fuse 17
Left dipped beam
15.0 A
Fuse 18
Right dipped beam
15.0 A
Fuse 19
Engine control unit
Electronic EGR valve
Oil vapour recirculation heater
Mass airflow meter
Diesel fuel heater
15.0 A
Fuse 20
Engine control unit
Turbo pressure control solenoid
Water in fuel sensor
Injection pump, diesel
10.0 A
Fuse 21
Cooling fan relay, left side
Right cooling fan
Cooling fan, high-speed relay
5.0 A
Fuse MF1
Not used
Fuse MF2
ABS/ESP control unit
40.0 A
Fuse MF3
ABS/ESP control unit
30.0 A
Fuse MF4
Fuses on the BSI (Intelligent power distribution module)
60.0 A
Fuse MF5
Fuses on the BSI (Intelligent power distribution module)
70.0 A
Fuse MF6
Additional heater
20.0 A
Fuse MF7
Automatic transmission control unit
20.0 A
Fuse MF8
Blower relay
30.0 A
