For Dodge Ram Van 1990, 1991, 1992, 1993, 1994 model year.
Dodge Ram Van (B150, B250, B350)
| Cigarette lighter fuse – Fuse box in passenger compartment – Fuse №9/15A) |
MENU
Fuse box in passenger compartment
Fuse box in passenger compartment.
Fuse box is located underneath glove compartment door.
Fuse box diagram.
Assignment of the fuses (1991-1994).
| Fuses | Amps | Circuits protected |
|---|---|---|
| 1 | Not Used | |
| 2 | 20 Amp (Yellow) | Radio Memory, Interior Courtesy Lights, Power Mirrors, Time-Delay Light & Relay, Underhood Light. |
| 3 | 10 Amp (Red) (1991-1993) 20 Amp (Yellow) (1994) | Hazard Flashers. |
| 4 | Not Used | |
| 5 | Not Used (1991-1993) 5 Amp (Tan) (1994) | ABS System. |
| 6 | 10 Amp (Red) | Back-Up Lights, Rear Window Heater Switch & Timer. |
| 7 | 30 Amp (Lt. Green) | A/C-Heater Blower Motor, Auxiliary A/C-Heater Relay. |
| 8 | 30 Amp (Circuit Breaker) | Power Windows. |
| 9 | 15 Amp (Lt. Blue) | Cigarette Lighter. |
| 10 | 20 Amp (Yellow) | Windshield Wipers. |
| 11 | 10 Amp (Red) | Radio, Clock. |
| 12 | 20 Amp (Yellow) | Turn Signals, Van Conversion Relay, Rear Wheel Anti-Lock Brake Module. |
| 13 | 20 Amp (Yellow) | Horn. |
| 14 | 20 Amp (Yellow) | Headlight Switch, Clock Display, Outside Lights (Park, Tail & Side Marker). |
| 15 | 20 Amp (Yellow) | Stoplights, Buzzers, Auxiliary A/C-Heater System, RWAL Brake Solenoid. |
| 16 | 30 Amp (Circuit Breaker) | Power Door Locks & Relay. |
| 17 | 5 Amp (Tan) | Gauges, Warning Lights, Speedometer, Overdrive, Lock-Out, Seal Belt Buzzer. |
| 18 | 2 Amp (Gray) | Speed Control. |
| 19 | Not Used | |
| 20 | 3 Amp (Violet) | Instrument Panel Illumination Lights. |
| Component | Location |
|---|---|
| A/C Clutch Relay | On firewall. See Fig. 1 . |
| Auto Shutdown Relay | On left inner fender well near firewall. |
| Fuel Pump Relay | On firewall, behind brake booster. See Fig. 1 . |
| Hazard Flasher Relay | On lower right side bracket, on relay block. See Fig. 2 . |
| Headlight/Key/Seat Belt Buzzer | Behind dash, on bracket above steering column. |
| Heated Rear Window Relay | On bracket, at lower right corner of instrument cluster. |
| Horn Relay | On relay block. See Fig. 2 . |
| Ignition Light Time Delay Relay | Behind dash, above instrument cluster. See Fig. 2 . |
| Part Throttle Unlock Relay | On firewall. See Fig. 1 . |
| Power Door Lock Relay | On steering column support bracket. See Fig. 3 . |
| Starter Relay | On firewall, to left of brake booster. See Fig. 1 . |
| Turn Signal Flasher Relay | On upper right side bracket, on relay block. See Fig. 2 . |
