For 500 /500C 2013, 2014, 2015, 2016, 2017, 2018 model year.
Cigarette lighter fuse – fuse box in engine compartment – Fuse F15/15A |
Fuse box in passenger compartment.
fuse box location.
The interior fuse panel is part of the Body Control Module (BCM) and is located on the driver’s side under the instrument panel.
fuse box diagram.
Assignment of the fuses.
Vehicle Fuse Number | Mini Fuse | Description |
---|---|---|
F12 | 7.5 Amp Brown | Right Low Beam |
F32 | 5 Amp Tan | Front and Rear Ceiling Lights Trunk and Door Courtesy Lights |
F53 | 5 Amp Tan | Instrument Panel Node |
F38 | 20 Amp Yellow | Central Door Locking |
F36 | 10 Amp Red | Diagnostic Socket, Vehicle Radio, Climate Control System |
F43 | 20 Amp Yellow | Bi-Directional Washer |
F48 | 20 Amp Yellow | Passenger Power Window |
F13 | 7.5 Amp Brown | Left Low Beam, Headlamp Leveling |
F50 | 7.5 Amp Brown | Airbag |
F51 | 5 Amp Tan | Vehicle Radio Switch, Climate Control System, Stop Light, Clutch |
F37 | 5 Amp Tan | Stop Light Switch, Instrument Panel Node |
F49 | 5 Amp Tan | Exterior Mirror, GPS, Electric Mirror, Parking Sensor |
F31 | 5 Amp Tan | Ignition, Climate Control |
F47 | 20 Amp Yellow | Driver Power Window |
Fuse box in engine compartment.
The Front Distribution Unit is located on the right side of the engine compartment, next to the battery. To access the fuses, press the release tabs and remove the cover.
fuse box diagram.
legend.
Cavity | Maxi Fuse | Mini Fuse | Description |
---|---|---|---|
F01 | 60 Amp Blue | – | Body Controller |
F02 | 20 Amp Yellow | – | Audio Amplifier |
F03 | 20 Amp Yellow | – | Ignition Switch |
F04 | 40 Amp Orange | – | Anti-Lock Brake Pump |
F05 | 70 Amp Tan | – | Electric Power Steering |
F06 | 20 Amp Yellow | – | Radiator Fan – Single Speed |
F06 | 30 Amp Green | – | Radiator Fan – Low Speed |
F07 | 40 Amp Orange | – | Radiator Fan – High Speed |
F08 | 40 Amp Orange | – | Blower Motor |
F09 | – | 10 Amp Red | Powertrain |
F10 | – | 10 Amp Red | Horn |
Fll | – | 15 Amp Blue | Powertrain |
Fll | – | 10 Amp Red | Powertrain (Multiair – If Equipped) |
F14 | – | 5 Amp Tan | High Beam (Shutter) |
F15 | – | 15 Amp Blue | Cigar Lighter |
F16 | – | 7.5 Amp Brown | Transmission |
F17 | – | 25 Amp Clear | Powertrain (Multiair – If Equipped) |
F17 | – | 15 Amp Blue | Powertrain |
F18 | – | 15 Amp Blue | Powertrain |
F18 | – | 5 Amp Tan | Powertrain (Multiair – If Equipped) |
F19 | – | 7.5 Amp Brown | Air Conditioning |
F20 | – | 15 Amp Blue | Heated Seats – If Equipped |
F21 | – | 15 Amp Blue | Fuel Pump |
F22 | – | 20 Amp Yellow | Powertrain |
F23 | – | 20 Amp Yellow | Anti-Lock Brake Valves |
F24 | – | 7.5 Amp Brown | Stability Control System |
F30 | – | 15 Amp Blue | Fog Lamps |
F82 | 30 Amp Green | – | Sunroof/Convertible Top |
F83 | 20 Amp Yellow | – | Cooling Pump – If Equipped |
F84 | – | 10 Amp Red | Transmission |
F85 | 30 Amp Green | – | Rear Defroster |
F87 | – | 5 Amp Tan | Rear Defroster |
F90 | – | 5 Amp Tan | Heated Mirrors – If Equipped |
