Fuses and Relay Fiat Croma 2005-2012

For Fiat Croma (194) 2005, 2006, 2007, 2008, 2009, 2010, 2011, 2012 model year.

Fuse box in passenger compartment.

fuse box location.

To gain access, loosen the fastening screw A and remove the cover.

fuse box diagram.

Assignment of the fuses.

Fuse 12
Right dipped beam
Right headlights
15.0 A
Fuse 13
Left dipped beam
Left headlights
Headlight levelling
15.0 A
Fuse 31
Headlight washer
Right tail light
7.5 A
Fuse 32
Courtesy lights
Instrument lighting
Heated rear windscreen
Heated rear-view mirror
Driver’s door control unit
Passenger’s door control unit
Ignition coil
15.0 A
Fuse 33
Rear power windows
Luggage compartment
20.0 A
Fuse 34
Luggage compartment
20.0 A
Fuse 35
Engine control unit, diesel
7.5 A
Fuse 36
Trailer
Instrument lighting
Central locking
20.0 A
Fuse 37
Engine control unit, diesel
Headlight levelling
Trip computer
Brake pedal switch
ESP
Brake lights
Dipped beam
Instrument lighting
Main beam
10.0 A
Fuse 38
Central locking
15.0 A
Fuse 39
Courtesy light(s)
Radio
Telephone
Alarm
Air conditioning
Diagnostic connector
Tyre pressure control system
10.0 A
Fuse 40
Heated rear windscreen
Heated rear windscreen and mirrors
30.0 A
Fuse 41
Heated rear windscreen
Heated rear windscreen and mirrors
Windscreen washer
15.0 A
Fuse 42
ESP
ABS control unit
7.5 A
Fuse 43
Windscreen wash/wipe system
Headlight washer
30.0 A
Fuse 44
Cigarette lighter
Accessory socket
Rear 12V socket
20.0 A
Fuse 45
Sunroof motor
20.0 A
Fuse 46
Sunroof motor
20.0 A
Fuse 47
Front power windows
20.0 A
Fuse 48
Front power windows
20.0 A
Fuse 49
Cruise control
Radio
Telephone
ESP
Heated driver’s seat
Navigation system
Air conditioning
Parking sensor
Sunroof
Mirror adjustment
Alarm
Windscreen wash/wipe system
Dipped beam
Instrument lighting
Direction indicators
Hazard warning lights
Number plate light(s)
Sidelights
7.5 A
Fuse 50
Airbag
Left number plate light
7.5 A
Fuse 51
Electric steering
Number plate light(s)
Tyre pressure control system
10.0 A
Fuse 52
Cigarette lighter
Rear wash/wipe system
Luggage compartment
15.0 A
Fuse 53
Direction indicator
Hazard warning lights
Instrument panel
10.0 A
Fuse FL70
Fuse box in passenger compartment
70.0 A
Fuse FL71
Fuse box in engine compartment
150.0 A
Relay R1
Dipped beam relay
Relay R11
Heated rear windscreen relay
Relay R12
Cigarette lighter relay
Relay R13
Front power window relay

Fuse box in engine compartment.

fuse box location.

fuse box diagram.

legend.

Fuse 1
Fuse box in passenger compartment
60.0 A
Fuse 2
Air conditioning
Or
Not used
40.0 A
Fuse 3
Steering lock
20.0 A
Fuse 4
ABS
ESP
40.0 A
Fuse 5
ABS
ESP
40.0 A
Fuse 6
Engine cooling
40.0 A
Fuse 7
Engine cooling
40.0 A
Fuse 8
Air-conditioning fan relay
Automatic air conditioning
40.0 A
Fuse 9
Headlight washers
20.0 A
Fuse 10
Horn relay
Left headlight
15.0 A
Fuse 11
Engine control unit, diesel
Right headlight
EGR valve
Injection pump, diesel
15.0 A
Fuse 14
Right main beam
10.0 A
Fuse 15
Left main beam
10.0 A
Fuse 16
Engine control unit, diesel
7.5 A
Fuse 17
Engine control unit, diesel
10.0 A
Fuse 18
Engine control unit, diesel
Automatic transmission
Main relay
7.5 A
Fuse 19
Compressor clutch relay
7.5 A
Fuse 20
Preheating relay
15.0 A
Fuse 21
Engine control unit, diesel
Fuel pump relay
15.0 A
Fuse 22
Engine control unit, diesel
15.0 A
Fuse 23
Navigation system
Radio
20.0 A
Fuse 30
Fog light relay
Left tail light
15.0 A
Relay R2
Main beam relay
Relay R3
Horn relay
Relay R5
Compressor clutch relay
Relay R8
Air-conditioning fan relay
Relay R9
Main relay
Relay R10
Fuel pump relay
Additional relay, fuel pump
Relay R14
Fog light relay
Relay R17
No information is available
Relay R19
Preheating relay

Fuse box in luggage compartment.

fuse box location.

fuse box diagram.

legend.
