For Fiat Seicento /600 (187) 1998, 1999, 2000, 2001, 2002, 2003, 2004, 2005, 2006, 2007, 2008, 2009, 2010, 2011 model year.
Cigarette lighter fuse – fuse box in passenger compartment – Fuse F24/25A |
Fuse box in passenger compartment.
fuse box location.
To reach the fuse-box, loosen the screw B fastening the cover A.
fuse box diagram.
Assignment of the fuses.
R1 | Heated rear window relay |
R2 | Horn relay |
R3 | Ignition auxiliary circuits relay |
R4 | Front fog lamps relay |
R5 | Electric window circuit relay |
R6 | Indicator relay |
R7 | – |
F1 | (15A) Central locking |
F2 | (25A) Electric windows |
F3 | (10A) Anti-lock brake system (ABS) |
F4 | (10A) RH side lamp, LH tail lamp, LH licence plate lamp |
F5 | (10A) LH side lamp, RH tail lamp, RH licence plate lamp, instrument panel |
F6 | (10A) LH headlamp – low beam, headlamp adjustment motor, left |
F7 | (10A) RH headlamp – low beam, headlamp adjustment motor, right |
F8 | (10A) LH headlamp – high beam |
F9 | (10A) RH headlamp – high beam, headlamp high beam warning lamp |
F10 | (10A) Power steering |
F11 | (20A) Sunroof |
F12 | (7,5A) Ignition auxiliary circuits relay, sunroof motor relay, heated rear window relay, electric window circuit relay, telephone |
F13 | (20A) Light switch |
F14 | (20A) Heated rear window |
F15 | (15A) Interior lamps, audio system, alarm system |
F16 | (10A) Hazard warning lamps |
F17 | (15A) Horn |
F18 | (10A) Rear fog lamp/s |
F19 | (10A) Front fog lamps |
F20 | (20A) Light switch |
F21 | (10A) Stop lamps, reversing lamp/s |
F22 | (10A) Indicators, audio system, instrument panel |
F23 | (10A) Airbag |
F24 | (25A) Cigarette lighter, AC/heater blower motor |
F25 | (20A) Windscreen wash/wipe system |
Fuse box in engine compartment.
fuse box located.
fuse box (A) diagram.
legend.
№ | Amps | Circuits Protected |
---|---|---|
A | 30A | Injection control unit |
B | 40A | Ignition switch |
C | 30A | Engine cooling fan |
D | 60A | Dashboard fusebox power |
E | 30A | Climate control system |
F | 30A | Optional power circuits |
G | 40A | Electrical power steering system |
H | 60A | ABS |
fuse box (B) diagram.
legend.
№ | Amps | Description |
---|---|---|
1 | 7,5A | Fiat CODE and control unit (+30) |
2 | 15A | Injection system auxiliary units and climate control system auxiliary units |
3 | 7,5A | Fiat CODE and electronic injection control unit (15/54) |
Electrical components.
1 | AC compressor clutch cut-off relay |
2 | AC condenser blower motor relay |
3 | Aerial signal amplifier |
4 | Alarm system control module – if fitted |
5 | Alarm system signal sensor – headlining |
6 | Automatic clutch control module |
7 | Automatic clutch warning buzzer |
8 | Battery |
9 | Central locking control module |
10 | Data link connector (DLC), engine management – ^2000 |
11 | Data link connector (DLC), 16 pin – 2000^ |
12 | Fuse box/relay plate, engine bay |
13 | Fuse box/relay plate, fascia |
14 | Heater blower relay – with AC |
15 | Heater blower speed resistor |
16 | Horn |
17 | Immobilizer control module |
18 | Inertia fuel shut-off (IFS) switch |
19 | Interior lamp relay – if fitted |
20 | Power steering control module |
21 | Satellite fuse (40A), power steering – near battery |
22 | Satellite fuse (3A), automaticclutch – near battery |
23 | Satellite fuse (30A), air conditioning (AC) – near battery |
24 | Satellite fuse (30A), central locking, electric windows, sunroof, front fog lamps – near battery |
25 | Satellite fuse (60A), anti-lock brake system (ABS) – near battery |
26 | Satellite fuse (7,5A), engine management, automaticclutch, alarm system, immobilizer – nearECM |
27 | Satellite fuse (10A), engine management – nearECM |
28 | SRS control module |
29 | Starter motor relay – with automatic clutch |
30 | Steering position sensor |
31 | Sunroof motor relay – headlining |
