For Fiat Multipla (186) 1998, 1999, 2000, 2001, 2002, 2003, 2004, 2005, 2006, 2007, 2008, 2009, 2010, 2011 model year.
| Cigarette lighter fuse – fuse box in passenger compartment – Fuse F9/15A |
Fuse box in passenger compartment.
fuse box location.
The fuse box is located under the oddments tray on the driver’s side.
fuse box diagram.
Assignment of the fuses.
| 1 | Ignition auxiliary circuits relay 1 |
| 2 | Heated rear window relay |
| 3 | Horn relay |
| 4 | Ignition auxiliary circuits relay 2 |
| F1 | (10A) RH headlamp – high beam |
| F2 | (10A) LH headlamp – high beam |
| F3 | (20A) Electric windows, combination switch, rear fog lamp, sunroof, navigation system |
| F4 | (10A) LH headlamp – low beam |
| F5 | (30A) AC/heater blower motor |
| F6 | (10A) Audio unit illumination lamp, cigarette lighter lamp, navigation system illumination lamp, RH licence plate lamp, RH side/tail lamps |
| F7 | (10A) Heater control lamp(s), LH licence plate lamp, LH side/tail lamps |
| F8 | (10A) Headlamp adjustment, RH headlamp – low beam |
| F9 | (15A) AC compressor clutch, cigarettelighter |
| F10 | (20A) Headlamp washers, rear screen wash/wipe system, windscreen wash/wipe system |
| F11 | (20A) Horn |
| F12 | (10A) Alarm system, alarm/central locking signal sensor, audio system, data link connector (DLC), interior lamps, instrument panel, instrument illumination,telephone |
| F13 | (15A) Airbag, alarm system, anti-lock brake system (ABS), audio system, clutch pedal position (CPP) switch (Diesel), indicators/hazard warning lamps, instrument panel, parkingaid sensors, reversing lamps, stop lamps, telephone |
| F14 | (10A) Indicators/hazard warning lamps |
| F15 | (30A) Heated door mirrors, heated rear window |
| F16 | (7,5A) Ignition auxiliary circuits relay |
| F17 | (7,5A) AC recirculation motor, electric door mirrors, AC/heater blower motor relay |
| F18 | (20A) Central locking |
| F19 | (25A) Auxiliary power socket |
| F20 | (15A) Fog lamps |
| F21 | (25A) Electric seats |
| F22 | (7,5A) Heated door mirrors |
| F23 | (7,5A) Airbag |
| F24 | (25A) Electric windows (rear) |
| F25 | (25A) Navigation system, refrigerator, sunroof |
Fuse box No. 2 in passenger compartment.
legend.
| 1 | Electric windows control module (ELX) |
| 2 | Ignition auxiliary circuits relay 3 |
| 3 | Central locking control module |
| 4 | Electric window relay, front/rear (SX) |
| 5 | Fog lamp relay |
| F1 | (30A) Electric windows, front (ELX) |
| F2 | (20A) Electric window, passenger’s side(SX) |
Fuse box in engine compartment.
fuse box location.
fuse box diagram.
legend.
| 1 | Fuel pump relay |
| 2 | Engine coolant blower motor relay |
| 3 | Engine coolant blower motor relay |
| 4 | Headlamp washer pump delay relay |
| 5 | AC compressor clutch relay |
| 6 | Fuel heater relay |
| F1 | (20A) Auxiliary heater |
| F2 | (7,5A) Immobilizer |
| F3 | (10A) Engine management (Euro3) |
| F4 | (10A) Anti-lock brake system (ABS) |
| F5 | (20A) Engine management |
| F6 | (20A) Headlamp washers |
| F7 | (7,5A) Engine management, immobilizer |
Fuse box No. 2 in engine compartment.
legend.
| F1 | (80A) Fascia fuse box/relay plate 1 |
| F2 | (60A) Electric windows relay, fascia fuse box/relay plate 1, headlamp low beam relay, ignition auxiliary circuits relay |
| F3 | (30A) Ignition switch |
| F4 | (30A) Engine management |
| F5 | – |
Additional fuses and relays in engine compartment.
Relay J35
Blower relay
Relay J34
Air-conditioning compressor fan, stage 1
Fuse B57
Taxi package
7.5 A
Fuse B8
Cooling fan (40A with air conditioning)
30.0 A
Fuse B37
Not used
60.0 A
Fuse B7
ABS
Or
ESP control unit
60.0 A
