For Fiat Doblo /-Cargo (263, 152) 2010, 2011, 2012, 2013, 2014, 2015, 2016, 2017, 2018 model year.
| Cigarette lighter fuse – fuse box in passenger compartment (2010-2014)– Fuse F95/F96/15A Cigarette lighter fuse – fuse box in passenger compartment (2015-2018)– Fuse F3/15A |
MENU
Fuse box in engine compartment.
Fuse box in passenger compartment.
Fuse box in engine compartment.
fuse box locaton.
fuse box diagram.
legend.
Fuse 1a
Rear right power window
20.0 A
Fuse 1b
Accessory socket
50.0 A
Fuse 2
Brake vacuum pump
40.0 A
Fuse 3
Glow plug control unit
(50A also used)
60.0 A
Fuse 4
Rear left power window
20.0 A
Fuse 5
Body control unit
60.0 A
Fuse 6
Cooling fan, low speed
30.0 A
Fuse 7
Ignition switch
20.0 A
Fuse 8
Cooling fan, high speed
30.0 A
Fuse 9
Additional heater
50.0 A
Fuse 10
Headlight washer
20.0 A
Fuse 11
Climate control fan
40.0 A
Fuse 12
Engine management
(15A also used)
20.0 A
Fuse 13
Engine control
10.0 A
Fuse 14
Engine management
Or
Not used
10.0 A
Fuse 15
Brake control (BS)
20.0 A
Fuse 16
Additional heater
30.0 A
Fuse 17
Fuel pump
15.0 A
Fuse 18
Engine control
7.5 A
Fuse 19
Fog lights
15.0 A
Fuse 20
Not used
Fuse 21
Manual climate control compressor
7.5 A
Fuse 22
Tailgate
10.0 A
Fuse 23
Main beam
15.0 A
Fuse 24
Heated mirrors
7.5 A
Fuse 25
Rear windscreen demister and defroster
30.0 A
Fuse 26
12V socket
30.0 A
Fuse 27
Accessory socket
30.0 A
Fuse 28
Battery sensor
5.0 A
Fuse 29
Engine management
7.5 A
Fuse 30
Brake control (BS)
Electric steering
5.0 A
Fuse 31
Horns
10.0 A
Relay R1
Climate control fan
Power socket
Heated seats
Relay R2
Cooling fan, high speed
Relay R3
Headlight washer
Relay R4
Horns
Relay R5
Cooling fan, low speed
Relay R6
Heated rear windscreen
Heated mirrors
Relay R7
Engine management system
Relay R8
Fuel pump relay
Additional relay, fuel pump
Relay R9
Start signal
Or
Not used
Relay R10
Fog lights
Relay R11
Climate control compressor relay
Relay R12
Headlight relay, main beam
Relay R13
Start signal
Or
Not used
Fuse box in passenger compartment.
fuse box location (2010-2014).
Assignment of the fuses.
| Fuse | Amps | Circuits Protected |
|---|---|---|
| F12 | 7,5A | Right low beam |
| F13 | 7,5A | Low left light, headlight lever |
| F31 | 5A | Int. power for engine fusebox relay coils and body computer relay coils |
| F32 | 7,5A | Front courtesy light, rear courtesy light, lights on sun visors, door clearance lights, boot light |
| F36 | 10A | Power + battery for EOBD diagnostic socket, automatic climate control unit, alarm siren, sound system, convergence control unit Blue&Me™, tyre pressure detector control unit |
| F37 | 5A | Int. power for instrument panel, brake pedal switch, third brake light |
| F38 | 20A | Door lock/unlock motors, dead lock actuator motors, tailgate lock motor |
| F43 | 15A | Windscreen/rear window washer pump |
| F47 | 20A | Window winder motor for front door driver’s side |
| F48 | 20A | Left low beam, headlight corrector |
| F49 | 5A | Int. power for control panel lights, parking control unit, tyre pressure detector control unit, electric door mirror motor, rain sensor, electric top control unit, My-port infotainment socket |
| F50 | 7,5A | air bag |
| F51 | 7,5A | Int. power for brake pedal switch, clutch pedal switch, interior heater, convergence control unit Blue&Me™, sound system set-up |
| F53 | 5A | Instrument panel |
| F94 | 15A | Rear socket |
| F95 | 15A | Cigarette lighter/Passenger compartment socket |
| F96 | 15A | Cigarette lighter/Passenger compartment socket |
| F97 | 10A | Heated driver seat |
| F98 | 10A | Heated passenger seat |
Fuse box location (2015-2018).
To access the fuses, remove snap-fitted protective cover.
legend.
| Fuses | Amps | Circuits Protected |
|---|---|---|
| F01 | 10A | Heated driver seat |
| F02 | 10A | Heated passenger seat |
| F03 | 15A | Cigar lighter |
| F04 | 20A | Third power socket on dashboard |
| F05 | 20A | Driver’s side rear electric window |
| F06 | 20A | Passenger’s side rear electric window |
| F12 | 7,5A | Right low beam |
| F13 | 7,5A | Left low beam, headlight corrector |
| F31 | 5A | Int. power for engine fusebox relay coils and body computer relay coils |
| F32 | 7,5A | Front courtesy light rear courtesy light lights on sun visors, door clearance lights, boot light |
| F36 | 10A | Supply + battery for EOBD diagnosis socket, radio, tyre pressure monitoring control unit |
| F37 | 5A | Int. power for instrument panel, brake pedal switch, third brake light |
| F38 | 20A | Door locking/unlocking motors, dead lock actuator motors, tailgate unlocking motor |
| F43 | 15A | Windscreen/rear window washer pump |
| F47 | 20A | Electric window motor on driver-side front door |
| F48 | 20A | Electric window motor on passenger-side front door |
| F49 | 5A | Int. power for control panel lights, parking control unit, tyre pressure detector control unit, electric door mirror motor, rain sensor, electric top control unit, My-port infotainment socket |
| F50 | 7,5A | air bag |
| F51 | 7,5A | Int. power for brake pedal switch, clutch pedal switch, interior heater, convergence control unit Blue&Me™, sound system set-up |
| F53 | 5A | Instrument panel |
