For Fiat Tempra /Marengo (159) 1990, 1991, 1992, 1993, 1994, 1995, 1996 model year.
Cigarette lighter fuse – fuse box in passenger compartment – Fuse F4/10A (box type 1) Cigarette lighter fuse – fuse box in passenger compartment – Fuse F13/20A (box type 2) |
Fuse box in passenger compartment.
fuse box location.
fuse box diagram (type 1).
Assignment of the fuses.
Fuse 1
Instrument panel
Washer pump
Reversing light(s)
10.0 A
Fuse 2
Right parking light(s)
Left tail light(s)
Right number plate light
Instrument panel
Left trailer light
10.0 A
Fuse 3
Left parking light(s)
Right tail light(s)
Left number plate light
Right trailer light
Instrument panel
10.0 A
Fuse 4
Cigarette lighter
Horn
Brake lights
10.0 A
Fuse 5
Central locking
20.0 A
Fuse 6
Clock
Interior light(s)
Instrument panel
7.5 A
Fuse 7
Heated rear windscreen and mirrors
20.0 A
Fuse 8
Hazard warning lights
10.0 A
Fuse 9
Cooling fan
10.0 A
Fuse 10
Not used
Fuse 11
Not used
Fuse 12
Not used
Fuse 13
Direction indicators
7.5 A
Fuse 14
Rear fog light(s)
7.5 A
Fuse 15
Front fog lights
20.0 A
Fuse 16
Right dipped beam
10.0 A
Fuse 17
Left dipped beam
10.0 A
Fuse 18
Left main beam
10.0 A
Fuse 19
Right main beam
10.0 A
Fuse 20
Front wiper system
20.0 A
Fuse 21
Heated rear windscreen
Sliding roof
20.0 A
Fuse 22
Blower
20.0 A
Fuse 23
Not used
Fuse 24
Not used
Fuse 25
Window(s)
30.0 A
Fuse 26
Mixture heater
20.0 A
Fuse 27
ABS
Or
ESP control unit
10.0 A
Relay R1
Heated rear windscreen
Relay R2
Central locking
Relay R3
Horn
Relay R4
Exterior light(s)
Relay R5
Intermittent wash/wipe system
Relay R6
Not used
Relay R7
Not used
Relay R8
Not used
Relay R9
Not used
Relay R10
Flasher unit
Relay R11
Rear fog light(s)
Relay R12
Not used
Relay R13
Dipped beam
Relay R14
Main beam
Relay R15
Starter system
Fuse box diagram (type 2).
legend.
Fuse 1
Hazard warning lights
10.0 A
Fuse 2
Direction indicators
7.5 A
Fuse 3
Rear fog light(s)
7.5 A
Fuse 4
Instrument panel
Reversing light(s)
Fuel cut-off
Washer pump
10.0 A
Fuse 5
Left dipped beam
10.0 A
Fuse 6
Right dipped beam
10.0 A
Fuse 7
Front and rear wiper system
20.0 A
Fuse 8
Blower
20.0 A
Fuse 9
Left main beam
10.0 A
Fuse 10
Right main beam
10.0 A
Fuse 11
Clock
Interior light(s)
20.0 A
Fuse 12
Cooling fan
25.0 A
Fuse 13
Horn
Brake light(s)
Cigarette lighter
20.0 A
Fuse 14
Heated rear windscreen
Sliding roof
20.0 A
Fuse 15
Heated rear windscreen
Mirror(s)
10.0 A
Fuse 16
Left parking light(s)
Right tail light(s)
Left number plate light
Right trailer light
Instrument panel
10.0 A
Fuse 17
Right parking light(s)
Left tail light(s)
Right number plate light
Instrument panel
Left trailer light
10.0 A
Relay R1
Dipped beam
Relay R2
Starter system
Relay R3
Main beam
Relay R4
Intermittent wash/wipe system
Relay R5
Flasher unit
Relay R6
Horn
Relay R7
Heated rear windscreen
Relay R8
Rear fog light(s)
Relay R9
Exterior light(s)
