For Fiat Marea /-Weekend/Marengo (185) 1996, 1997, 1998, 1999, 2000, 2001, 2002, 2003 model year.
| Cigarette lighter fuse – fuse box in passenger compartment – Fuse F7/20A |
Fuse box in passenger compartment.
fuse box location (fuse box №1/№2).
Insert the screws A, press the left side of the cover В lightly and take the cover by freeing it from the retaining tabs.
fuse box №1 diagram.
Assignment of the fuses.
| 1 | Ignition auxiliary circuits relay |
| 2 | Heated rear window relay |
| 3 | Horn relay |
| F1 | (30A) Heated door mirrors, heated rear window |
| F2 | (10A) Instrument panel(2001^), hazard warning lamps |
| F3 | (10A) Indicators, instrument panel, stop lamps |
| F4 | (10A) Alarm system, Instrument panel (^2000), interior lamps |
| F5 | (20A) Air conditioning (AC) (^2000), horn |
| F6 | (20A) Headlamp washers, rear screen wash/wipe system, windscreen wash/wipe system |
| F7 | (20A) Cigarette lighter, heater/air conditioning (AC) |
| F8 | (10A) Headlamp adjustment, headlamp washers, LH headlamp – low beam |
| F9 | (10A) Electric door mirrors, LH side lamp, licence plate lamp, RH tail lamp |
| F10 | (10A) Audio system, instrument illumination, heater/air conditioning (AC), LH tail lamp, licence plate lamp, RH side lamp |
| F11 | (30A) Air conditioning (AC) |
| F12 | (10A) RH headlamp – low beam |
| F13 | (10A) Audio system, central locking, rear fog lamps |
| F14 | (10A) LH headlamp – high beam |
| F15 | (10A) RH headlamp – high beam |
Fuse box No. 2 in passenger compartment (pre 2000).
legend.
| R1 | Fog light(s) |
| F1 | (20A) Central locking |
| F2 | (15A) Fog lamps |
| F3 | (7,5A) Airbag |
| F4 | (7,5A) Heated door mirrors |
| F5 | (20A) Sunroof |
| F6 | (30A) Rear electric windows |
| F7 | (30A) Front electric windows |
| F8 | (10A) Heated seats |
Fuse box No. 2 in passenger compartment (since 2000).
legend.
| F1 | (7,5A) Air conditioning (AC) – petrol |
| F2 | (20A) Headlamp washers |
| F3 | (7,5A) Engine coolant blower motor relay, engine management, immobilizer – petrol |
| F4 | (10A) Anti-lock brake system (ABS) |
| F5 | (7,5A) Air conditioning (AC) |
| F6 | (7,5A) Engine management, immobilizer – petrol |
| F7 | (7,5A) Audio system, interior lamps, telephone |
| F8 | (15A) Fog lamps |
| F9 | (25A) Rear electric windows |
| F10 | (25A) Front electric windows |
| F11 | (30A) Cigarette lighter, heated seats, sunroof |
| F12 | (10A) Airbag |
Relay in passenger compartment.
3A/D – Supplementary fusebox
4 – Junction unit
5 – Dipped headlamps relay feed
32 – Fog lamp control relay
150 – Injection sytem control relay (1747) (JTD)
151 – Lambda probe control relay for fuel pump and injectors
152 – Fuse protecting injection system (1747) (JTD)
250 – Fuse protecting fuel pump (1747)
257 – Fuel pump control relay (1747)
326 – Additional heater control unit
328 – Hazard warning lights relay
332 – Ignition activated power relay
344 – Protection fuse ie. (JTD)
Fuse box №1 in engine compartment.
fuse box location.
fuse box diagram.
legend.
| F1 | (30A) Engine management – petrol |
| F2 | (60A) Fuse box/relay plate, engine bay 2, fascia fuse box/relay plate 1 (F1, F2, F6, F7), headlamp low beam relay, ignition main circuits relay (pre 2000) (80A) Fascia fuse box/relay plate 2 (F2, F5, F8-F11) (since 2000) |
| F3 | (40A) Engine management |
| F4 | (80A) Fascia fuse box/relay plate 1 (pre 2000) (80A) Fascia fuse box/relay plate 1 (F9-F13) (since 2000) |
| F5 | (30A/40A/50A) Engine coolant blower motor 1 |
| F6 | (40A) Engine coolant blower motor 2 – Turbo Diesel (since 2000) |
| F7 | (60A) Anti-lock brake system (ABS) |
| F8 | (40A) Engine coolant blower motor 2 – Diesel TD except 1,9-100 without AC (pre 2000) (30A) Engine management – Diesel (since 2000) |
Fuse box №2 in engine compartment.
legend.
| 1 | Engine coolant blower timer relay – with AC (pre 2000) Engine coolant blower motor relay 2 (2000) |
| 2 | Engine coolant blower motor relay 1 – with AC |
| 3 | AC compressor clutch relay |
| 4 | Headlamp washer pump relay |
| 5 | Engine coolant blower motor relay 2 -1,8/2,0 with AC |
| 6 | Starter motor inhibitor switch relay (pre 2000) Fuel pump(FP) relay – 2,0 (since 2000) |
| 7 | Transmission fluid cooler pump motor relay (pre 2000) Starter motor inhibitor switch relay (since 2000) |
| 8 | Camshaft position (CMP) motor relay – 2,0 |
| F1 | (10A) Immobilizer (pre 2000) (15A) Engine management-2,0 (since 2000) |
| F2 | (10A) Anti-lock brake system (ABS) (pre 2000) (15A) Engine management-2,0 (since 2000) |
| F3 | (20A) Headlamp wash/wipe system |
| F4 | (10A) Automatic transmission (AT) (pre 2000) (20A) Air conditioning (AC) – with AC (2000) |
| F5 | (5A) Automatic transmission (AT) |
Relay location – engine compartment (petrol).
3B-3C – Power fusebox
96 – Power fuse protecting ABS
98 – Headlamp washer intermittent function
122 – Engine cooling fan low speed relay
123 – Engine cooling fan high speed timer
124 – Air condiitoning compressor control relay
129 – Power fuse protecting engine coling fan
150 – Injection system relay feed
151 – Lambda probe control relay for fuel pump and injectors
152 – Fuse protecting injection system
152A – Fuse protecting injection system
152B – Fuse protecting injection system
273 – Fuse protecting automatic transmission system
274 – Fuse protecting automatic transmission system
276 – Starter enablement relay
368 – Relay diode for injection system control
Relay location – engine compartment (diesel).
3A/D – Supplementary fusebox
4 – Junction unit
5 – Dipped headlamps relay feed 32 Fog lamp control relay
150 – Injection sytem control relay (1747) (JTD)
151 – Lambda probe control relay for fuel pump and injectors
152 – Fuse protecting injection system (1747) (JTD)
250 – Fuse protecting fuel pump (1747)
257 – Fuel pump control relay (1747)
326 – Additional heater control unit
328 – Hazard warning lights relay
332 – Ignition activated power relay.
344 – Protection fuse ie. (JTD)
