For Fiat Panda (169) 2003, 2004, 2005, 2006, 2007, 2008, 2009, 2010, 2011 model year.
| Cigarette lighter fuse – fuse box in engine compartment – Fuse F44/20A (pre 2007) Cigarette lighter fuse – fuse box in engine compartment – Fuse F29/20A (since 2007) |
Fuse box in passenger compartment.
fuse box location.
The fusebox is on the steering wheel left- hand side.To gain access to the fusebox, slacken the cover F fastening screw E.G wired control unit H Body-computer control unit D fuse extracting pliers. The number identifying the electrical component corresponding to each fuse is on the cover back.
fuse box diagram.
Assignment of the fuses.
| FA | – |
| FB | – |
| F31 | (7,5A) Reversing lamps |
| F35 | (7,5A) Audio system |
| F37 | (10A) Stop lamps |
| F41 | (7,5A) Heated door mirrors |
| F45 | (25A) Heated seats |
| F46 | (20A) Sunroof |
| F49 | (7,5A) Air conditioning (AC), fuel/water separator sensor, tyre pressure monitor control module |
| F50 | (10A) Airbag |
| F51 | (7,5A) Instrument panel, multifunction control module |
| F12 | (10A) RH headlamp – low beam |
| F13 | (10A) LH headlamp – low beam |
| F38 | (20A) Central locking |
| F39 | (10A) Air conditioning (AC), audio system, data link connector (DLC), multifunction control module, telephone, tyrepressure monitor control module |
| F40 | (30A) Heated rear window |
| F43 | (30A) Windscreen wash/wipe system |
| F47 | (20A) Electric windows |
| F48 | (20A) Electric windows |
| F52 | (15A) Rear screen wiper motor |
| F53 | (15A) Rear screen wash, windscreen washers |
Fuse box in engine compartment.
fuse box location.
fuse box diagram (pre 2007).
legend.
| 2 | Headlamp high beam relay |
| 3 | Horn relay |
| 5 | AC compressor clutch relay |
| 6 | Engine coolant blower motor relay 1 – low speed |
| 7 | Engine coolant blower motor relay 2 – high speed |
| 8 | Heater blower relay |
| 9 | Engine control (EC) relay |
| 10 | Fuel lift pump relay – Diesel |
| 14 | Fog lamp relay |
| 17 | Headlamp washer pump relay |
| 19 | Fuel heater relay |
| 20 | Starter motor inhibitor switch relay |
| 21 | Transmission system relay – Selespeed |
| F1 | (70A) Multifunction control module |
| F2 | (40A) Fascia fuse box/relay plate 1 (F45/F54) |
| F3 | (30A) Automatic transmission (AT) – Selespeed |
| F4 | (60A) Anti-lock brake system (ABS) |
| F5 | (60A) Power steering |
| F6 | (30A) Engine coolant blower motor 1 – low speed |
| F7 | (40A) Engine coolant blower motor 2 – high speed |
| F8 | (30A) Air conditioning (AC) |
| F9 | (20A) Headlamp washers |
| F10 | (15A) Horn |
| F11 | (15A) Engine management |
| F14 | (15A) Headlamp high beam |
| F16 | (7,5A) Engine management |
| F17 | (15A) Engine management |
| F18 | (7,5A) Engine management |
| F19 | (7,5A) Air conditioning (AC) |
| F20 | (30A) Fuel filter heater |
| F21 | (15A) Fuel lift pump |
| F22 | (30A) Engine management |
| F23 | (30A) Ignition switch |
| F24 | (15A) Power steering |
| F30 | (15A) Front fog lamps |
| F32 | (15A) Engine management |
| F36 | (20A) Trailer control module |
| F42 | (7,5A) Anti-lock brake system (ABS), stop lamps |
| F44 | (20A) Cigarette lighter |
| F71 | (80A) Glow plugs |
| F72 | (30A) Engine coolant heater 1 |
| F73 | (50A) Engine coolant heater 2 |
Fuse box in engine compartment (since 2007).
legend.
Fuse 1
Air-conditioning compressor
7.5 A
Fuse 2
Main beam
15.0 A
Fuse 3
Horn
15.0 A
Fuse 4
Trailer control unit
15.0 A
Fuse 5
Engine management
7.5 A
Fuse 6
ABS
Or
ESP control unit
20.0 A
Fuse 7
Fog lights
15.0 A
Fuse 8
Fuel pump
Fuse 9
Headlight washer
20.0 A
Fuse 10
Gearbox
15.0 A
Fuse 11
Gas injection control unit
Or
Not used
20.0 A
Fuse 12
Engine management
Gearbox
7.5 A
Fuse 13
Electric steering
10.0 A
Fuse 14
ABS
Brake lights
7.5 A
Fuse 15
Engine cooling fan
40.0 A
Fuse 16
Dashboard
70.0 A
Fuse 17
ABS
Or
ESP control unit
40.0 A
Fuse 18
Electric steering
60.0 A
Fuse 19
Engine cooling fan
30.0 A
Fuse 20
Selespeed
30.0 A
Fuse 21
Ignition switch
20.0 A
Fuse 22
Not used
Fuse 23
Not used
Fuse 24
Fuse box No. 2 in passenger compartment
30.0 A
Fuse 25
Engine management
Air-conditioning compressor
15.0 A
Fuse 26
Engine management
10.0 A
Fuse 27
Engine management
20.0 A
Fuse 28
Climate control fan
30.0 A
Fuse 29
Accessory socket
Cigarette lighter
20.0 A
Relay R1
Cooling fan relay
Relay R2
Cooling fan relay
Relay R3
Selespeed gearbox relay
Relay R4
Main relay
Relay R5
Climate control fan relay
Relay R6
Accessory socket relay
Cigarette lighter
Relay R7
Headlight washer relay
Relay R8
Fog light relay
Relay R9
Immobiliser relay
Relay R10
LPG solenoid valves
Or
Not used
Relay R11
Main beam relay
Relay R12
Horn relay
Relay R13
Climate control compressor relay
Manual climate control compressor
Relay R14
Fuel pump relay
Additional relay, fuel pump
