For Lexus GS300, GS400, GS430 1998, 1999, 2000, 2001, 2002, 2003, 2004, 2005 model year.
Cigarette lighter fuse – Cigarette Lighter and Power Outlet – Fuse CIG/15A |
MENU
Fuse box in passenger compartment.
- fuse box diagram (drivers side 1998-2001)
- fuse box diagram (drivers side 2002-2005)
- fuse box diagram (passenger side 1998-2001)
- fuse box diagram (passenger side 2002-2005)
Fuse box in engine compartment.
- fuse box diagram (engine 1998-2001)
- fuse box diagram (engine 2002-2005)
- relay box №1 diagram
- relay box №2 diagram
Fuse box in passenger compartment.
fuse box location.
locating is instrument panel junction.
fuse box diagram (drivers side 1998-2001).
Assignment of the fuses.
| Fuse | System | ||
|---|---|---|---|
| 5A | IGN | Cruise Control (3UZ-FE) Cruise Control (2JZ-GE) Electronically Controlled Transmission and A/T Indicator (3UZ-FE) Electronically Controlled Transmission and A/T Indicator (2JZ-GE) Engine Control (3UZ-FE) Engine Control (2JZ-GE) Radiator Fan and Condenser Fan | |
| 5A | IGN | SRS VSC | |
| 5A | SRS-B | Combination Meter Headlight SRS Tailiight | |
| 5A | STARTER | Electronically Controlled Transmission and A/T Indicator (3UZ-FE) Electronically Controlled Transmission and A/T Indicator (2JZ-GE) Engine Control (3UZ-FE) Engine Control (2JZ-GE) Starting and Ignition (3UZ-FE) Starting and Ignition (2JZ-GE) | |
| 7.5A | OBD | Engine Control (3UZ-FE) Engine Control (2JZ-GE) | |
| 7.5A | PANEL | Illumination | |
| 10A | FUEL OPN | Fuel Lid Opener | |
| 10A | GAUGE | Back-Up Light Charging Combination Meter Cruise Control (3UZ-FE) Cruise Control (2JZ-GE) Electronically Controlled Transmission and A/T Indicator (3UZ-FE) Electronically Controlled Transmission and A/T Indicator (2JZ-GE) Engine Control (3UZ-FE) Engine Control (2JZ-GE) Headlight Headlight Beam Level Control Key Reminder and Seat Belt Warning LEXUS Navigation System PPS Radio and Player (MARK LEVINSON) Shift Lock SRS Stop Light Tailiight Turn Signal and Hazard Warning Light VSC Wiper and Washer | |
| 10A | HEATER | Automatic Air Conditioning Multiplex Communication System Rear Window Defogger and Mirror Heater | |
| 10A | TAIL | Tailiight | |
| 15A | CIG | Cigarette Lighter and Power Outlet | |
| 15A | ECU-IG | Auto Antenna Automatic Glare-Resistant EC Mirror Automatic Light Control Cellular Mobile Telephone Electric Tension Reducer Headlight Beam Level Control Interior Light Key Reminder and Seat Belt Warning Light Auto Turn Off Luggage Compartment Door Opener Moon Roof Multiplex Communication System Power Seat (Driver’s Seat w/ Driving Position Memory) Power Tilt and Power Telescopic Power Window PPS Remote Control Mirror Seat Heater Theft Deterrent and Door Lock Control VSC Wireless Door Lock Control | |
| 15A | FR FOG | Fog Light Multiplex Communication System | |
| 15A | RADIO N0.2 | Auto Antenna Automatic Air Conditioning Cellular Mobile Telephone Clock Interior Light Key Reminder and Seat Belt Warning LEXUS Navigation System Light Auto Turn Off Luggage Compartment Door Opener Multiplex Communication System Power Seat (Driver’s Seat w/ Driving Position Memory) Power Tilt and Power Telescopic Power Window Radio and Player (Except MARK LEVINSON) Radio and Player (MARK LEVINSON) Remote Control Mirror Shift Lock Theft Deterrent and Door Lock Control Wireless Door Lock Control | |
| 15A | STOP | Cruise Control (3UZ-FE) Cruise Control (2JZ-GE) | |
| 15A | STOP | Electronically Controlled Transmission and A/T Indicator (3UZ-FE) Electronically Controlled Transmission and A/T Indicator (2JZ-GE) Engine Control (3UZ-FE) Engine Control (2JZ-GE) Multiplex Communication System Stop Light VSC | |
| 20A | D FR DOOR | Automatic Light Control Interior Light Key Reminder and Seat Belt Warning Light Auto Turn Off Multiplex Communication System Power Seat (Driver’s Seat w/ Driving Position Memory) Power Tilt and Power Telescopic Power Window Remote Control Mirror Theft Deterrent and Door Lock Control Wireless Door Lock Control | |
| 20A | D RR DOOR | Interior Light Light Auto Turn Off Multiplex Communication System Power Window Theft Deterrent and Door Lock Control Wireless Door Lock Control | |
| 20A | WASHER | Headlight Cleaner Wiper and Washer | |
| 25A | WIPER | Wiper and Washer | |
| 30A | D P/SEAT | Multiplex Communication System Power Seat (Driver’s Seat w/ Driving Position Memory) Power Seat (Driver’s Seat w/o Driving Position Memory) | |
Fuse box diagram (drivers side 2002-2005).
legend.
| Fuse | System | |
|---|---|---|
| 5A | IGN | Cruise Control (2JZ-GE) Cruise Control (3UZ-FE) Electronically Controlled Transmission and A/T Indicator (2JZ-GE) Electronically Controlled Transmission and A/T Indicator (3UZ- FE) Engine Control (2JZ-GE) Engine Control (3UZ-FE) Radiator Fan and Condenser Fan SRS VSC |
| 5A | SRS-B | Combination Meter Headlight SRS Taillight |
| 5A | STARTER | Electronically Controlled Transmission and A/T Indicator (2JZ-GE) Electronically Controlled Transmission and A/T Indicator (3UZ- FE) Engine Control (2JZ-GE) Engine Control (3UZ-FE) Starting and Ignition (2JZ-GE) Starting and Ignition (3UZ-FE) |
| 7.5A | OBD | Engine Control (2JZ-GE) Engine Control (3UZ-FE) |
| 7.5A | PANEL | Illumination |
| 10A | FUEL OPN | Fuel Lid Opener |
| 10A | GAUGE | Audio System (MARK LEVISON) Back-Up Light Charging Combination Meter Cruise Control (2JZ-GE) Cruise Control (3UZ-FE) Electronically Controlled Transmission and A/T Indicator (2JZ-GE) Electronically Controlled Transmission and A/T Indicator (3UZ- FE) Engine Control (2JZ-GE) Engine Control (3UZ-FE) Headlight Headlight Beam Level Control Key Reminder and Seat Belt Warning LEXUS Navigation System PPS Shift Lock SRS Stop Light Taillight Turn Signal and Hazard Warning Light VSC Wiper and Washer |
| 10A | HEATER | Automatic Air Conditioning Multiplex Communication System Rear Window Defogger and Mirror Heater |
| 10A | TAIL | Taillight |
| 15A | CIG | Cigarette Lighter and Power Outlet |
| 15A | ECU-IG | Auto Antenna Automatic Glare-Resistant EC Mirror Automatic Light Control Cellular Mobile Telephone Electric Tension Reducer Headlight Beam Level Control Interior Light Key Reminder and Seat Belt Warning Light Auto Turn Off System Luggage Compartment Door Opener Moon Roof Multiplex Communication System Power Seat (Driver’s Seat w/ Driving Position Memory) Power Tilt and Telescopic Power Window PPS Remote Control Mirror Seat Heater Theft Deterrent and Door Lock Control VSC Wireless Door Lock Control |
| 15A | FR FOG | Fog Light Multiplex Communication System |
| 15A | RADIO NO.2 | Audio System (Except MARK LEVISON) Audio System (MARK LEVISON) Auto Antenna Automatic Air Conditioning Cellular Mobile Telephone Clock Interior Light Key Reminder and Seat Belt Warning LEXUS Navigation System Light Auto Turn Off System Luggage Compartment Door Opener Multiplex Communication System Power Seat (Driver’s Seat w/ Driving Position Memory) Power Tilt and Power Telescopic Power Window Remote Control Mirror Shift Lock Theft Deterrent and Door Lock Control Wireless Door Lock Control |
| 15A | STOP | Cruise Control (2JZ-GE) Cruise Control (3UZ-FE) Electronically Controlled Transmission and A/T Indicator (2JZ-GE) Electronically Controlled Transmission and A/T Indicator (3UZ-FE) Engine Control (2JZ-GE) Engine Control (3UZ-FE) Multiplex Communication System Stop Light VSC |
| 20A | D RR DOOR | Interior Light Light Auto Turn Off System Multiplex Communication System Power Window Theft Deterrent and Door Lock Control Wireless Door Lock Control |
| 20A | WASHER | Headlight Cleaner Wiper and Washer |
| 25A | WIPER | Wiper and Washer |
| 30A | D P/SEAT | Multiplex Communication System Power Seat (Driver’s Seat w/ Driving Position Memory) Power Seat (Driver’s Seat w/o Driving Position Memory) |
Fuse box diagram (passenger side 1998-2001).
legend.
| Fuse | System | |
|---|---|---|
| 5A | ECU-B2 | Automatic Air Conditioning Headlight (w/ Daytime Running Light) Multiplex Communication System Power Seat (Driver’s Seat w/ Driving Position Memory) |
| 10A | DOME | Auto Antenna Clock Garage Door Opener Interior Light |
| 10A | DOME | Light Auto Turn Off Multiplex Communication System Power Window Radio and Player (Except NAKAMICHI) Radio and Player (NAKAMICHI) Theft Deterrent and Door Lock Control Wireless Door Lock Control |
| 10A | MIR HTR | Rear Window Defogger and Mirror Heater |
| 15A | TV | LEXUS Navigation System |
| 20A | P FR DOOR | Interior Light Key Reminder and Seat Belt Warning Light Auto Turn Off Luggage Compartment Door Opener Multiplex Communication System Power Seat (Driver’s Seat w/ Driving Position Memory) Power Tilt and Power Telescopic Power Window Remote Control Mirror Theft Deterrent and Door Lock Control Wireless Door Lock Control |
| 20A | P RR DOOR | Interior Light Light Auto Turn Off Multiplex Communication System Power Window Theft Deterrent and Door Lock Control Wireless Door Lock Control |
| 20A | SEAT HTR | Seat Heater |
| 25A | S/ROOF | Moon Roof |
| 30A | DEFOG | Rear Window Defogger and Mirror Heater |
| 30A | P P/SEAT | Power Seat (Front Passenger’s Seat) Power Tilt and Power Telescopic |
Fuse box diagram (passenger side 2002-2005).
legend.
| Fuse | System | |
|---|---|---|
| 10A | DOME | Audio System (Except MARK LEVISON) Audio System (MARK LEVISON) Auto Antenna Clock Garage Door Opener Interior Light Light Auto Turn Off System Multiplex Communication System Power Window Theft Deterrent and Door Lock Control Wireless Door Lock Control |
| 10A | ECU-B2 | Automatic Air Conditioning Automatic Light Control Combination Meter Headlight Interior Light Key Reminder and Seat Belt Warning Light Auto Turn Off System Luggage Compartment Door Opener Multiplex Communication System Power Seat (Driver’s Seat w/ Driving Position Memory) Power Tilt and Power Telescopic Power Window Remote Control Mirror Theft Deterrent and Door Lock Control Wireless Door Lock Control |
| 10A | MIR HTR | Rear Window Defogger and Mirror Heater |
| 15A | TV | LEXUS Navigation System |
| 20A | ECU-B3 | Interior Light Key Reminder and Seat Belt Warning Light Auto Turn Off System Luggage Compartment Door Opener Multiplex Communication System Power Seat (Driver’s Seat w/ Driving Position Memory) Power Tilt and Power Telescopic Power Window Remote Control Mirror Theft Deterrent and Door Lock Control Wireless Door Lock Control |
| 20A | P RR DOOR | Interior Light Light Auto Turn Off System Multiplex Communication System Power Window Theft Deterrent and Door Lock Control Wireless Door Lock Control |
| 20A | SEAT HTR | Seat Heater |
| 25A | S/ROOF | Moon Roof |
| 30A | DEFOG | Rear Window Defogger and Mirror Heater |
| 30A | P P/SEAT | Power Seat (Front Passenger’s Seat) |
Fuse box in engine compartment.
fuse box location.
fuse box diagram (engine 1998-2001).
Assignment of the fuses.
| Fuse | System | ||||
| 5A | ALT-S | Charging | |||
| 10A | H-LP L UPR | Headlight (w/o Daytime Running Light) | |||
| 10A | H LP R UPR | Headlight (w/o Daytime Running Light) | |||
| 10A | HORN | Horn Multiplex Communication System Theft Deterrent and Door Lock Control | |||
| 10A | MPX-B | Automatic Light Control Combination Meter Interior Light Key Reminder and Seat Belt Warning Light Auto Turn Off Luggage Compartment Door Opener Multiplex Communication System Power Seat (Driver’s Seat w/ Driving Position Memory) Power Tilt and Power Telescopic Power Window Remote Control Mirror Theft Deterrent and Door Lock Control Wireless Door Lock Control | |||
| 10A | TURN-HAZ | Turn Signal and Hazard Warning Light | |||
| 15A | AM2 | Engine Control (1UZ-FE) Engine Control (2JZ-GE) Starting and Ignition (1 UZ-FE) Starting and Ignition (2JZ-GE) | |||
| 15A | ETCS | Cruise Control (1 UZ-FE) Cruise Control (2JZ-GE) Engine Control (1 UZ-FE) Engine Control (2JZ-GE) | |||
| 15A | H-LP L LWR | Headlight (w/ Daytime Running Light) Headlight (w/o Daytime Running Light) | |||
| 15A | H-LP R LWR | Fog Light Headlight (w/ Daytime Running Light) Headlight (w/o Daytime Running Light) Multiplex Communication System | |||
| 15A | TEL | Cellular Mobile Telephone | |||
| 20A | RADIO N0.1 | Radio and Player (Except NAKAMICHI) Radio and Player (NAKAMICHI) | |||
| 25A | EFI | Cruise Control (1 UZ-FE) Cruise Control (2JZ-GE) Electronically Controlled Transmission and A/T Indicator (1 UZ-FE) Electronically Controlled Transmission and A/T Indicator (2JZ-GE) Engine Control (1 UZ-FE) | |||
| 25A | EFI | Engine Control (2JZ-GE) Engine Immobiliser System (1UZ-FE) Engine Immobiliser System (2JZ-GE) | |||
| 30A | CDS FAN | Radiator Fan and Condenser Fan | |||
| 30A | DRL N0.1 | Headlight (w/ Daytime Running Light) | |||
| 30A | DRL N0.2 | Headlight (w/ Daytime Running Light) | |||
| 30A | H-LP CLN | Headlight Cleaner | |||
| 30A | RDI FAN | Radiator Fan and Condenser Fan | |||
| 40A | ABS N0.2 | VSC | |||
| 40A | MAIN | Automatic Light Control Headlight (w/ Daytime Running Light) Headlight (w/o Daytime Running Light) Headlight Beam Level Control Headlight Cleaner Light Auto Turn Off Multiplex Communication System Starting and Ignition (1UZ-FE) Starting and Ignition (2JZ-GE) Theft Deterrent and Door Lock Control | |||
| 50A | FAN MAIN | Radiator Fan and Condenser Fan | |||
| 50A | HEATER | Automatic Air Conditioning | |||
| 60A | ABS N0.1 | VSC | |||
| 120A | ALT | Automatic Light Control Charging Engine Control (1UZ-FE) Engine Control (2JZ-GE) Illumination Light Auto Turn Off Multiplex Communication System Radiator Fan and Condenser Fan Rear Window Defogger and Mirror Heater Seat Heater Taillight Theft Deterrent and Door Lock Control | |||
Fuse box diagram (engine 2002-2005).
legend.
| Fuse | System | |
|---|---|---|
| 5A | ALT-S | Charging |
| 10A | HORN | Horn Multiplex Communication System Theft Deterrent and Door Lock Control |
| 10A | TURN-HAZ | Turn Signal and Hazard Warning Light |
| 15A | AM2 | Engine Control (2JZ-GE) Engine Control (3UZ-FE) Starting and Ignition (2JZ-GE) Starting and Ignition (3UZ-FE) |
| 15A | ETCS | Cruise Control (2JZ-GE) Cruise Control (3UZ-FE) Engine Control (2JZ-GE) Engine Control (3UZ-FE) |
| 15A | H-LP L LWR | Headlight |
| 15A | H-LP R LWR | Fog Light Headlight Multiplex Communication System |
| 15A | TEL | Cellular Mobile Telephone |
| 20A | D FR | Automatic Light Control Interior Light Key Reminder and Seat Belt Warning Light Auto Turn Off System Multiplex Communication System Power Seat (Driver’s Seat w/ Driving Position Memory) Power Tilt and Power Telescopic Power Window Remote Control Mirror Theft Deterrent and Door Lock Control Wireless Door Lock Control |
| 20A | P FR | Interior Light Light Auto Turn Off System Multiplex Communication System Power Seat (Driver’s Seat w/ Driving Position Memory) Power Window Remote Control Mirror Theft Deterrent and Door Lock Control Wireless Door Lock Control |
| 25A | EFI | Cruise Control (2JZ-GE) Cruise Control (3UZ-FE) Electronically Controlled Transmission and A/T Indicator (2JZ-GE) Electronically Controlled Transmission and A/T Indicator (3UZ-FE) Engine Control (2JZ-GE) Engine Control (3UZ-FE) Engine Immobilizer System (2JZ-GE) Engine Immobilizer System (3UZ-FE) |
| 30A | CDS FAN | Radiator Fan and Condenser Fan |
| 30A | DRL NO.1 | Headlight |
| 30A | DRL NO.2 | Headlight |
| 30A | H-LP CLN | Headlight Cleaner |
| 30A | RADIO NO.1 | Audio System (Except MARK LEVISON) Audio System (MARK LEVISON) |
| 30A | RDI FAN | Radiator Fan and Condenser Fan |
| 40A | ABS NO.2 | VSC |
| 40A | MAIN | Automatic Light Control Headlight Headlight Beam Level Control Headlight Cleaner Light Auto Turn Off System Multiplex Communication System Starting and Ignition (2JZ-GE) Starting and Ignition (3UZ-FE) Theft Deterrent and Door Lock Control |
| 50A | FAN MAIN | Radiator Fan and Condenser Fan |
| 50A | HEATER | Automatic Air Conditioning |
| 60A | ABS NO.1 | VSC |
| 120A | ALT | Automatic Light Control Charging Engine Control (2JZ-GE) Engine Control (3UZ-FE) Illumination Light Auto Turn Off System Multiplex Communication System Radiator Fan and Condenser Fan Rear Window Defogger and Mirror Heater Seat Heater Taillight Theft Deterrent and Door Lock Control |
H-LP L UPR – Headlight (left) (15A)
H-LP R UPR Headlight (right) (15A)
