For Mercedes ML (W 163) 1998,1999, 2000, 2001, 2002, 2003, 2004, 2005 model year.
Mercedes ML230, Mercedes ML270, Mercedes ML320, Mercedes ML350, Mercedes ML370, Mercedes ML400, Mercedes ML430, Mercedes ML500, Mercedes ML55 AMG
Cigarette lighter fuse (front) – Fuse box in passenger compartment – Fuse F2/15A or 20A |
MENU
Fuse box in engine compartment.
Fuse box in passenger compartment.
Fuse box in engine compartment.
fuse box location.
To gain access to the fuse box, release clamps (arrows), lift the fuse box cover (1) up and remove it. To close the fuse box, engage back end of cover, close, and secure with clamps.
fuse box diagram (pre 08.2001).
Assignment of the fuses (pre 08.2001).
| R1 | Heated rear window relay |
| R2 | Engine coolant blower motor relay |
| R3 | Fuel lift pump relay (except ML270 CDI) |
| R4 | Indicator relay, LH |
| R5 | Licence plate lamps relay, instrument panel |
| R6 | Stop lamps cut-off relay (ESP) |
| R7 | Indicator relay, RH |
| R8 | Starter motor relay |
| R9 | Side/tail lamps relay, RH |
| R10 | – |
| R11 | Ignition main circuits relay (ML270 CDI) |
| R12 | Ignition main circuits relay |
| R13 | Side/tail lamps relay, LH |
| R14 | Electric windows relay |
| R15 | Central locking relay – tailgate unlocking |
| R16 | Electric window relay, passenger |
| R17 | Windscreen wiper intermittent relay |
| R18 | Electric window relay, driver |
| R19 | Engine coolant pump relay |
| R20 | Central locking relay – doors locking |
| R21 | Heater blower relay, fuse box/relay plate cooling fan relay |
| R22 | Headlamp low beam relay |
| R23 | Central locking relay – passenger’s door and rear doors unlocking |
| R24 | Central locking relay – driver’s door unlocking |
| R25 | ABS pump motor relay |
| R26 | AC condenser blower motor relay |
| R27 | – |
| R28 | Secondary air injection (AIR) pump relay |
| R29 | Fog lamp relay, rear |
| R30 | Fog lamps relay, front |
| R31 | Horn relay (with alarm system) |
| F1 | (15A) Auxiliary power socket, front |
| F2 | (7,5A) LH indicators |
| F3 | (15A) RH headlamp – high beam |
| F4 | (30A) Sunroof motor |
| F5 | (7,5A) LH headlamp – high beam, headlamp high beam warning lamp |
| F6 | (7,5A) Rear screen wiper motor |
| F7 | (15A) Windscreen wash/wipe system, hazard warning lamps switch |
| F8 | (25A) Transfer box control module |
| F9 | (7,5A) Licence plate lamps, switch illumination |
| F10 | (10A) Audio system, vanity mirror lamps, trip computer, glove box lamp, cigarette lighter, airbag warning lamp, interior rearview mirror |
| F11 | (10A) Engine management (petrol) |
| F12 | (7,5A) LH side/tail lamps |
| F13 | (10A) Interior lamps, trip computer, seat belt warning lamp, steering position sensor, data link connector (DLC) |
| F14 | (10A) Engine management (Diesel) |
| F15 | (10A) Stop lamps |
| F16 | (15A) Data link connector (DLC), reverse gear position switch, AC control module, AC recirculation motor |
| F17 | (15A) Auxiliary power socket, load area |
| F18 | (25A) Trailer socket |
| F19 | (15A) Engine management (petrol) |
| F20 | (15A) Electric door mirrors |
| F21 | (25A) Audio system |
| F22 | (15A) Automatic transmission (AT), transfer box control module, traction control system (TCS), cruise control, steering position sensor |
| F23 | – |
| F24 | (7,5A) RH side/tail lamps |
| F25 | (7,5A) RH indicators |
| F26 | (15A) Engine management (petrol) |
| F27 | (40A) Traction control system (TCS) |
| F28 | (20A) Heated seats |
| F29 | (30A) Multi switch assembly – electric windows |
| F30 | (30A) Multi switch assembly – electric windows |
| F31 | (15A) Sunroof switch, electric door mirrors, rear electric windows |
| F32 | (30A) Electric seat, RH front |
| F33 | (30A) Electric seat, LH front |
| F34 | (7,5A) LH headlamp – low beam, headlamp adjustment |
| F35 | (7,5A) RH headlamp – low beam |
| F36 | (25A) Heated rear window |
| F37 | (20A) Horns |
| F38 | (20A) Fuel pump/fuel level sensor |
| F39 | – |
| F40 | (25A) Brake servo vacuum pump(ML270CDI) |
| F41 | (25A) Engine coolant pump motor, fuse box/relay plate cooling fan motor, auxiliary heater |
| F42 | (20A) Central locking |
| F43 | (30A) Heater blower relay, heater/AC blower motor, rear |
| F44 | (30A) AC condenser blower motors |
| F45 | (40A) Exhaust gas recirculation (EGR) vacuum pump |
| F46 | (7,5A) Rear fog lamp |
| F47 | (15A) Fog lamps, front |
| F48 | (20A) Alarm system horn |
Fuse box diagram (since 09.2001).
legend (since 09.2001).
| R1 | Door mirror heater relay |
| R2 | Engine coolant blower motor relay |
| R3 | Fuel lift pump relay (ML400 CDI) |
| R4 | Indicator relay, LH |
| R5 | Licence plate lamps relay, instrument panel |
| R6 | Stop lamps cut-off relay (ESP) |
| R7 | Indicator relay, RH |
| R8 | Starter motor relay |
| R9 | Side/tail lamps relay, RH |
| R10 | – |
| R11 | Ignition main circuits relay (Diesel) |
| R12 | Ignition main circuits relay |
| R13 | Side/tail lamps relay, LH |
| R14 | Electric windows relay |
| R15 | Central locking relay – tailgate unlocking |
| R16 | – |
| R17 | Windscreen wiper intermittent relay |
| R18 | – |
| R19 | – |
| 20 | Central locking relay – doors locking |
| 21 | – |
| 22 | – |
| 23 | Central locking relay – passenger’s door and rear doors unlocking |
| 24 | Central locking relay – driver’s door unlocking |
| 25 | – |
| 26 | AC condenser blower motor relay |
| 27 | Rear screen washer pump relay |
| 28 | Secondary air injection (AIR) pump relay |
| 29 | Fog lamp relay, rear |
| 30 | Fog lamps relay, front |
| 31 | Horn relay (with alarm system) |
| F1 | – |
| F2 | (7,5A) LH indicators |
| F3 | – |
| F4 | (20A) Sunroof motor |
| F5 | – |
| F6 | (20A) Heated seats |
| F7 | (30A) Windscreen wash/wipe system, hazard warning lamps switch |
| F8 | (25A) Transfer box control module |
| F9 | (7,5A) Licence plate lamps, switch illumination |
| F10 | (10A) Audio system, vanity mirror lamps, trip computer, glove box lamp, cigarette lighter, airbag warning lamp, interior rearview mirror |
| F11 | (15A) Engine management (petrol) |
| F12 | (7,5A) LH side/tail lamps |
| F13 | (10A) Interior lamps, trip computer, seat belt warning lamp, steering position sensor, data link connector (DLC) |
| F14 | (25A) Engine management (Diesel) |
| F15 | (10A) Stop lamps |
| F16 | (15A) Data link connector (DLC), reverse gear position switch, AC control module, AC recirculation motor |
| F17 | (20A) Auxiliary power socket, load area |
| F18 | (25A) Trailer socket |
| F19 | (15A) Engine management (petrol) |
| F20 | – |
| F21 | (15A) Audio system, telephone |
| F22 | (15A) Automatic transmission (AT), transfer box control module, traction control system (TCS), cruise control, steering position sensor, trip computer, rain sensor |
| F23 | (15A) Headlamp level control module |
| F24 | (7,5A) RH side/tail lamps |
| F25 | (7,5A) RH indicators |
| F26 | (15A) Engine management (petrol) |
| F27 | (40A) Traction control system (TCS) |
| F28 | – |
| F29 | – |
| F30 | – |
| F31 | (15A) Sunroof switch, electric door mirrors, rear electric windows, mirror lamps |
| F32 | – |
| F33 | – |
| F34 | – |
| F35 | – |
| F36 | (10A) Door mirror heater |
| F37 | (20A) Horns |
| F38 | (20A) Fuel pump/fuel level sensor |
| F39 | – |
| F40 | (25A) Audio system |
| F41 | – |
| F42 | (20A) Central locking |
| F43 | (20A) AC/heater blower control module, rear |
| F44 | (15A) Rear screen washer pump, AC condenser blower motor relay (except ML320/ML350) |
| F45 | (40A) Exhaust gas recirculation (EGR) vacuum pump |
| F47 | (15A) Fog lamps, front |
| F48 | (20A) Alarm system horn |
Fuse box in passenger compartment.
To gain access to the fuse box, turn both locks (3) 90°counterclockwise and remove cover in direction of arrow. To close the fuse box, engage back end of cover, slide the cover towards vehicle front and secure by turning both locks (3) clockwise to the stop.
fuse box diagram.
legend.
| R1 | Seat adjustment relay |
| R2 | Fuel pump (FP) relay (petrol) |
| 3 | – |
| R4 | Heated rear window relay |
| R5 | Headlamp washer pump relay |
| R6 | – |
| R7 | – |
| R8 | – |
| R9 | Ignition main circuits relay |
| F1 | (7,5A) Airbag assembly passenger disable warning lamp |
| F2 | (20A) Cigarette lighter, front (15A also used) |
| F3 | (15A) Rear screen wiper motor |
| F4 | (40.0 A) Blower motor or not used |
| F5 | (7,5A) Instrument panel, air conditioning (AC) |
| F6 | (20A) Auxiliary power socket |
| F7 | – |
| F8 | (20A) Heated front seats or not used |
| F9 | – |
| F10 | (30A) Seat operating switch, driver (35A also used) |
| F11 | (30A) Seat operating switch, passenger (35A also used) |
| F13 | (20A) Fuel pump/fuel level sensor |
| F16 | – |
| F17 | (25A) Heated rear window |
| F18 | – |
| F19 | (30A) Headlamp washer pump |
| F20 | Right main beam 7.5 A |
or
not usedF21Left main beam
7.5 A
or not usedF22-F23-F24Motors, rear power windows
25.0 A
or not usedF25Motors, front power windows
25.0 A
or not usedF26
(70A) Ignition main circuits relay
| 1 | AC control module – behind audio unit(—08/01) |
| 2 | AC/heater control module- in AC/heater function control panel (09/01—) |
| 3 | AC/heater blower speed resistor – near blower motor |
| 4 | AC sunlight sensor |
| 5 | Aerial module – tailgate |
| 6 | Alarm system control module (combined with multifunction control module) |
| 7 | Alarm system gradient sensor (combined with trip computer) |
| 8 | Alarm system horn – engine bay |
| 9 | Alarm system in car movement sensor (combined with trip computer) |
| 10 | Audio unit output amplifier (if fitted) – behind LH fascia |
| 11 | Battery |
| 12 | Brake servo vacuum pump – LH engine bay |
| 13 | Brake servo vacuum pump control module – LH engine bay |
| 14 | Compass control module (navigation system) – under trim panel, neartailgatecatch |
| 15 | Data link connector (DLC) |
| 16 | Fuse box/relay plate, engine bay |
| 17 | Fuse box/relay plate, footwell |
| 18 | Headlamp control module, LH (gas discharge headlamps) |
| 19 | Headlamp control module, RH (gas discharge headlamps) |
| 20 | Horns 1/2- behind front bumper |
| 21 | Immobilizer control module – attached to multifunction control module 2(12/99—) |
| 22 | Immobilizer read coil – in ignition switch |
| 23 | Indicator relay/hazard warning lamps relay – in multifunction control module 1 |
| 24 | Light sensor-top centre ofwindscreen |
| 25 | Multifunction control module 1 – attached to engine bay fuse box/relay plate- functions: Interior lamps, exterior lamps, horns, windscreen wipers, AC pressure sensing, central locking, electric windows, indicators, alarm system, sunroof, heated seats, immobilizer (—>11/99) |
| 26 | Multifunction control module2- functions: Central locking, headlamp washers, heated rear window, heated seats, AC condenser blower motor, interior lamps |
| 27 | Navigation system control module (combined with audio unit) – (if fitted) |
| 28 | Outside air temperature sensor |
| 29 | Parking aid control module – behind switch panel |
| 30 | Rain sensor – top centre of wind screen |
| 31 | Satellite fuse 1 – near battery |
| 32 | Satellite fuse 2 (FL7,5/10A), engine management – in module box – Diesel |
| 33 Seat adjustment control module (with memory), left front – under seat | |
| 34 Seat adjustment control module (with memory), right front – under seat | |
| 35 Side airbag crash sensor, left- bottom of B-post (09/01^) | |
| 36 Side airbag crash sensor, right- bottom of B-post (09/01^) | |
| 37 Supplementary restraint system (SRS) control module | |
| 38 Telephone system interface module – under front seat | |
| 39 Transfer box control module | |
| 40 Transfer box range selection motor – on transfer box | |
| 41 Transmission control module (TCM) | |
| 42 Transmission shift control module – selector lever | |
| 43 Trip computer | |
