Fuse box diagram Citroen Berlingo 2

For Citroen Berlingo (B9) 2008, 2009, 2010, 2011, 2012, 2013, 2014, 2015, 2016, 2017, 2018 model year.

Cigarette lighter fuse – Fuse box in passenger compartment – Fuse F9/30A

fuse box location.

Assignment of the fuses

Fuses	Amps	Circuits Protected
1	20A	Engine control unit Cooling fan control unit
2	15A	Horns
3	10A	Front and rear windscreen washers
4	20A	Headlight washers
5	15A	Fuel pump Or Not used
6	10A	ABS/ESP control unit Double relay Power steering unit ESP accelerometer gyroscope Power steering pump
7	10A	Stop switch Clutch switch
8	25A	Starter relay
9	10A	Relay 3 protection switch unit Headlight adjustment
10	30A	Ignition coil Injection control unit Or Not used
11	40A	Blower control relay
12	30A	Front wiper control
13	40A	Fuses on the BSI (Intelligent power distribution module)
14	30A	Exhaust heat exchanger pump
15	10A	Right main beam
16	10A	Left main beam
17	15A	Left dipped beam
18	15A	Right dipped beam
19	15A	Canister purge solenoid(s) Oxygen sensor in front of the catalytic converter Oxygen sensor behind the catalytic converter Or Not used
20	10A	Exhaust heat exchanger solenoid valve
21	5A	Cooling fan control unit
MF1	40A	Blower relay
MF2	40A	Trailer relay Air-conditioning relay (50A also used)
MF3	50A	Cooling fan
MF4	80A	Fuses on the BSI (Intelligent power distribution module)
MF5	80A	Fuses on the BSI (Intelligent power distribution module)
MF6	50A	ABS motor relay Or Electronic stability program (ESP) relay
MF7	40A	Fuse box in passenger compartment
MF8	30A	ABS motor relay Or Electronic stability program (ESP) relay

legend.

F1	(20A) Engine management
F2	(15A) Horn
F3	(10A) Windscreen wash/wipe system
F4	(20A) Headlamp wash/wipe system
F5	(15A) Engine management
F6	(10A) ABS/ESP control unit Double relay Power steering unit ESP accelerometer gyroscope Power steering pump
F7	(10A) Stop lamps
F8	(25A) Starting system
F9	(10A) Relay 3 protection switch unit Headlight adjustment
F10	(30A) Engine management
F11	(40A) Heater blower motor
F12	(30A) Windscreen wipers
F13	(40A) Fuses on the BSI (Intelligent power distribution module)
F14	(30A) Engine management
F15	(10A) Headlamp high beam, right
F16	(10A) Headlamp high beam, left
F17	(15A) Headlamp low beam, right
F18	(15A) Headlamp low beam, left
MF1	(40A) Heater blower motor
MF2	(40A/50A) Trailer relay Air-conditioning relay
MF3	(50A) Engine coolant blower motor
MF4	(80A) Fuses on the BSI (Intelligent power distribution module)
MF5	(80A) Fuses on the BSI (Intelligent power distribution module)
MF6	(50A)ABS/ESP system
MF7	(40A) Fuse box in passenger compartment
MF8	(30A)ABS/ESP system

legend.

Fuses	Amps	Circuits protected
1	5A	Battery sensor Or Brake light switch
2	15A	Diagnostic socket
3	15A	Brake light switch or not used
4	Not used
FL5	80A	Power steering pump
FL6	70A	Pre-post heating
FL7	100A	Relay 3 protection switch unit
FL8	Not used
FL9	Not used
FL10	30A	Engine management relay or not used

fuse box locate in the lower dashboard on the lefthand side (behind the cover).

fuse box diagram.

legend.

F1	(15A) Rear screen wiper
F2	(30A) Central locking
F3	(5A) Supplementary restraint system (SRS) control module
F4	(10A) Diagnostic socket Headlight adjustment Rear-view mirror dimming control Additional fuel pump Control panel Traction control switch
F5	(30A) Front electric windows
F6	(30A) Luggage compartment opening relay
F7	(5A) Interior lamps
F8	(20A) Tyre pressure monitor control unit Radio Multifunction display Interior protection control unit Control panel Alarm siren Trailer control unit Body control unit
F9	(30A) Front 12V socket Cigarette lighter Interior lights Map reading light(s)
F10	(15A) Upper steering column
F11	(15A) Ignition switch
F12	(15A) Rain and light sensor Airbag control unit Trailer control unit Body control unit
F13	(5A) Fuse and relay box in engine compartment Control panel
F14	(15A) Parking assistance Handsfree kit Air-conditioning control panel
F15	(30A) Central locking
F16	Shorting link connector
F17	(40A) Heated rear windscreen Heated mirror(s)

1	ABS control module
2	AC control module
3	AC/heater blower control module
4	Alarm system control module
5	Battery
6	Data link connector (DLC)
7	Engine control module (ECM)
8	Engine coolant blower motor control module
9	Fuel additive control module – near fuel tank
10	Fuse box/relay plate , engine bay 1
11	Fuse box/relay plate , engine bay 2
12	Fuse box/relay plate , engine bay 3
13	Fuse box/relay plate , fascia 1
14	Fuse box/relay plate , fascia 2
15	Fuse box/relay plate , load area
16	Glow plug control module
17	Heater blower speed resistor
18	Horn
19	Multifunction control module 1 – incorporated in engine bay fuse box/relay plate 1 – functions: Engine management, horn , starter motor, windscreen wash/wipe system
20	Multifunction control module 2- incorporated in fascia fuse box/relay plate 1 – functions: Central locking , electric windows , heated rear window, interior lamps , indicators/hazard warning lamps, immobilizer, rear screen wiper
21	Multifunction control module 3 – incorporated in load area fuse box/relay plate – functions: Trailer socket
22	Outside air temperature sensor – in RH door mirror
23	Parking aid control module
24	Relay module (RM) 1 – functions: ABS/ESP system
25	Relay module (RM) 2 – functions: Auxiliary heater
26	Steering column function control module
27	Stop-start system control module – behind LH front wheel arch liner
28	Supplementary restraint system (SRS) control module
29	Transmission control module (TCM) – on transmission
30	Tyre pressure monitor control module
