For Citroen C1 (B0) 2005, 2006, 2007, 2008, 2009, 2010, 2011, 2012, 2013, 2014 model year.
Cigarette lighter fuse – Fuse box in passenger compartment – Fuse F11/15A or F15/40A |
MENU
Fuse box in engine comparment.
Fuse box in passenger compartment.
Relay box in passenger compartment.
Fuse box in engine comparment.
fuse box location.
fuse box diagram.
Assignment of the fuses
| R1 | AC compressor clutch relay |
| R2 | Starter motor relay |
| F1 | (50A) Transmission, engine coolant blower motor – Diesel |
| F2 | – |
| F3 | (25A)ABS |
| F4 | (30A) Starter motor |
| F5 | (10A) Instrument panel lamp(s), indicators, hazard warning lamps |
| F6 | (10A) Side/tail lamps, headlamps |
| F7 | (15A) Interior lamps, instrument panel, audiounit |
| F8 | (15A) Engine control module (ECM), petrol |
| F9 | (10A) Horn |
| F10 | (7,5A) Engine coolant blower motor |
| F11 | (10A)ABS |
| F12 | (15A) Power steering |
| F13 | (7,5A) Starter motor |
| F14 | (7,5A) Engine control module (ECM) |
| F15 | (15A) Engine control module (ECM) |
| F16 | (10A) Headlamp high beam, right |
| F17 | (10A) Headlamp high beam, left |
| F18 | (10A) Headlamp low beam, right |
| F19 | (10A) Headlamp low beam, left |
| F20 | (10A) Engine control module (ECM) |
Fuse box in passenger compartment.
fuse box location.
These are located on each side of the instrument panel under the trim. Turn the steering wheel to the left, remove bolt B.
Turn the steering wheel to the right (do not forget to release the steering wheel using the key), remove bolt C.
For the rev counter, partially unscrew bolt D located behind it.
Raise the instrument panel trim, and the rev counter trim if necessary, to gain access to the fuses located on the left and on the right.
legend.
| F1 | (10A) Stop lamps, ABS, transmission |
| F2 | (25A) Central locking |
| F3 | (20A) Heated rear window |
| F4 | (7,5A) Tail lamps, instrument panel lamp(s), transmission selector lamps |
| F5 | (7,5A) Data link connector (DLC) |
| F6 | (7,5A) Rear fog lamps, instrument panel, transmission, instrument panel lamp(s) |
| F7 | (7,5A)ABS, powersteering, heater/air conditioning (AC) |
| F8 | (7,5A)ABS, powersteering, heater/air conditioning (AC), engine coolant blower motor |
| F9 | (10A) Tail lamps, central locking, electric windows, heated rear window, vehicle speedometer, heater/air conditioning (AC) |
| F10 | (20A) Windscreen wash/wipe system, rear screen wash/wipe system |
| F11 | (15A) Audio unit, alarm system or Cigarette lighter fuse |
| F12 | (7,5A) Windscreen wash/wipe system, rear screen wash/wipe system, ABS, power steering, heater/air conditioning (AC), central locking, electric windows, vehicle speedometer, heated rear window, engine coolant blower motor |
| F13 | (15A) Engine control module (ECM), alarm system, instrument panel, supplementary restraint system (SRS), transmission |
| F14 | (7,5A) Air conditioning (AC) |
| F15 | (40A) Auxiliary power socket, Cigarette lighter fuse |
| F16 | (30A) Electric windows |
| F17 | (40A) Heater/air conditioning (AC) |
Relay box in passenger compartment.
Relay R1
Accessories
Relay R2
Ignition coil relay
Relay R3
Heating and ventilation
Relay R4
Heated rear windscreen relay
