For Citroen Jumper /Relay 1994, 1995, 1996, 1997, 1998, 1999, 2000, 2001, 2002, 2003, 2004, 2005, 2006 model year.
Cigarette lighter fuse (front) – fuse box in passenger compartment – Fuse F44/15A |
MENU
Fuse box in passenger compartment.
Fuse box in passenger compartment (1994-2002).
Fuse box in engine compartment.
Fuse box in passenger compartment.
fuse box location.
fuse box diagram.
Assignment of the fuses.
| Fuse | Amps | CircuitsProtected |
|---|---|---|
| 12 | 5А | Right sidelight Right tail light |
| 13 | 5А | Left sidelight Left tail light |
| 24 | 5А | Number plate light(s) Warning light, sidelights Illumination, dashboard switches |
| 25 | 7.5А | Audio system |
| 26 | 7.5А | Brake light(s) |
| 27 | 7.5А | Electric rear-view mirror Cruise control Telephone Tachograph Remote control Alarm |
| 31 | 10А | Lighting control switch |
| 32 | 15А | Audio system |
| 33 | 7.5А | Fog light(s) |
| 35 | 7.5А | Power window controls |
| 37 | 10А | Dashboard illumination |
| 39 | 10А | Interior light(s) Diagnostic connector |
| 42 | 7.5А | ABS control unit |
| 43 | 15А | Windscreen washer(s) |
| 44 | 15А | Cigarette lighter |
| 49 | 15А | Headlight washers |
| 50 | 7.5А | Airbag control unit |
| 51 | 10А | Not used |
| 52 | 20А | 12V socket |
| 53 | 10А | Direction indicators Hazard warning lights Dashboard illumination |
| 55 | 30А | Blower, additional heater Additional heater |
Fuse box in passenger compartment (1994-2002).
fuse box diagram.
legend.
| Fuse | Amps | Circuits Protected |
|---|---|---|
| 34 | 10А | Tachograph Telephone Alarm Remote control |
| 38 | 20А | Central locking |
| 40 | 15А | Heated rear windscreen, right side |
| 41 | 10А | Heated rear-view mirror |
| 45 | 15А | Heated seat(s) |
| 47 | 20А | Front left power window |
| 48 | 20А | Front right power window |
| 54 | 15А | Heated rear windscreen, left side |
| 56 | 30А | Supplementary air conditioning |
| 57 | 15А | Blower, additional heater |
| 58 | 5А | Additional heater programmer |
| 59 | 15А | Shelf (supply) |
| 60 | 10А | Alarm |
| 61 | 20А | Additional heater |
| 63 | 30А | Special equipment |
| 64 | 20А | Special equipment |
| 65 | 10А | Accessory socket |
Fuse box in engine compartment.
legend.
| Fuse | Amps | Circuits protected |
|---|---|---|
| 1 | 60А | |
| 2 | 50А | |
| 3 | 30А | |
| 4 | 50А | |
| 5 | 30А | |
| 6 | 70А | |
| 7 | 70А | |
| 8 | 30А | |
| 9 | 15А | Front fog lights |
| 10 | 15А | Warning system Steering-wheel mounted controls |
| 11 | 10А | Engine control unit Engine electronics |
| 14 | 10А | Right dipped beam |
| 15 | 10А | Left dipped beam |
| 16 | 7.5А | Not used |
| 17 | 5А | Engine control unit Engine electronics |
| 18 | 7.5А | Engine control unit Engine electronics |
| 19 | 7.5А | Compressor |
| 20 | 30А | PTC |
| 21 | 15А | Fuel pump |
| 22 | 20А | Not used |
| 23 | 10А | Automatic charge unit |
| 24 | 15А | Automatic transmission control unit |
| 30 | 15А | Main beam |
