For Daihatsu Charade (G1) 1987, 1988, 1989, 1990, 1991, 1992, 1993 model year.
| Cigarette lighter fuse – fuse box in passenger compartment – Fuse F3/15A |
Fuse box in passenger compartment.
fuse box diagram (Germany).
Assignment of the fuses.
Fuse 1
Spare fuse/relay
15.0 A
Fuse 2
Horn
Flasher relay
15.0 A
Fuse 3
Cigarette lighter
15.0 A
Fuse 4
Left tail lights
10.0 A
Fuse 5
Right tail lights
Clock
10.0 A
Fuse 6
Windscreen wiper(s)
Rear wiper(s)
15.0 A
Fuse 7
Alternator
Cooling fan relay
15.0 A
Fuse 8
Warning lights
10.0 A
Fuse 9
Flasher relay
Reversing light(s)
15.0 A
Fuse 10
Left headlight
15.0 A
Fuse 11
Right headlight
15.0 A
Fuse 12
Spare fuse/relay
10.0 A
Relay M
Flasher relay
Relay L
Lights on
Relay K
Intermittent wiper relay
Fuse 13
Heated rear windscreen
15.0 A
Fuse 14
Heater (except CB-80 engine)
20.0 A
Fuse 15
Electric sunroof
20.0 A
Fuse 16
Brake lights
10.0 A
Fuse 17
Not used
Fuse box in passenger compartment, (Europe except Germany).
legend.
Fuse 1
Spare fuse/relay
15.0 A
Fuse 2
Horn
Flasher relay
15.0 A
Fuse 3
Cigarette lighter
15.0 A
Fuse 4
Brake light switch
Interior light(s)
10.0 A
Fuse 5
Clock
Sidelight switch
10.0 A
Fuse 6
Windscreen wiper(s)
Rear wiper(s)
15.0 A
Fuse 7
Alternator
Cooling fan relay
15.0 A
Fuse 8
Warning lights
10.0 A
Fuse 9
Flasher relay
Reversing light(s)
15.0 A
Fuse 10
Left headlight
15.0 A
Fuse 11
Right headlight
15.0 A
Fuse 12
Spare fuse/relay
10.0 A
Relay M
Flasher relay
Relay L
Lights on
Relay K
Intermittent wiper relay
Fuse 13
Heated rear windscreen
15.0 A
Fuse 14
Heater (except CB-80 engine)
20.0 A
Fuse 15
Electric sunroof
20.0 A
Fuse 16
Not used
Fuse 17
Power windows
30.0 A
