For Daihatsu Charade (G2) 1993, 1994, 1995, 1996, 1997, 1998, 1999, 2000, 2001 model year.
Cigarette lighter fuse – fuse box in passenger compartment – Fuse F11/15A |
Fuse box in passenger compartment.
fuse box location.
fuse box diagram
LHD
RHD
Assignment of the fuses.
R1 | Indicator relay |
F1 | (20A) Heated rear window |
F2 | (10A) Engine electrics |
F3 | (15A) Audio |
F4 | (10A) Starter motor |
F5 | (15A) Indicator lamps |
F6 | (15A) Horn, hazard lamps |
F7 | (15A) Windscreen wiper motor |
F8 | (10A) Rear fog lamp, tail lamp – left |
F9 | (10A) Instruments |
F10 | (10A) Tail lamp – right |
F11 | (15A) Cigarette lighter |
F12 | (20A) Spare |
F13 | (15A) Spare |
F14 | (10A) Spare |
F15 | (15A) Headlamp – left |
F16 | (15A) Headlamp – right |
F17 | (20A) Ignition No.1 |
F18 | (30A) Heater blower motor |
F19 | (15A) Stop lamps |
F20 | (15A) Interior lamp |
F21 | (15A) Ignition No.2 |
F22 | (30A) Main No.2 |
F23 | (20A) Main No.1 |
Fuse box in engine compartment.
legend.
Fuses | Amps | Circuits Protected |
---|---|---|
1 | 50A | ABS Or ESP control unit |
2 | 40A | Headlights |
3 | 30A | Cooling fan |
4 | 30A | Air-conditioning fan |
5 | 10A | Air conditioning |
6 | 10A | MVO |
7 | 15A | Fuel injection system |
8 | 10A | Daylight running system control unit |
R1 | Main relay | |
R2 | Fuel injection system | |
R3 | Cooling fan | |
R4 | Air-conditioning fan |
