For Dodge Avenger 1995 mode year.
Cigar Lighter fuse – in passenger compartment fuse №12/10A |
MENU
Fuse box in passenger compartment
Fuse box in engine compartment
Fuse box in passenger compartment.
The fuse block is behind the end cover at the left side of the instrument panel. Pull the cover straight away
from the instrument panel for access to fuses.
fuse box diagram.
Assignment of the fuses(1995).
| Fuses | Amps | Circuits Protected |
|---|---|---|
| 1 | 10A | Anti-Theft. |
| 2 | 10A | Turn Signal and Hazard Flashers. |
| 3 | 10A | Back-up Lights. |
| 4 | 15A | Amplifier. |
| 5 | 30A | Heater. |
| 6 | 10A | Door Locks. |
| 7 | 20A | Wipers. |
| 8 | 10A | Meters. |
| 9 | 30A | Rear Window Defogger. |
| 10 | 20A | Sunroof. |
| 11 | 20A | ELC-4. |
| 12 | 10A | Cigarette Lighter. |
| 13 | 15A | Heater Relay. |
| 14 | Spare | Not Used. |
Relay box diagram.
1- 10 Amp (Red) Remote Controlled Mirror
2- 10 Amp (Red) Door Mirror Heaters
3- Theft – Alarm Starter Relay (Automatic Transmission Models)
4- Theft – Alarm Horn Relay
5- Power Window Relay
6- Theft – Alarm Starter Relay (Manual Transmission Models)
Fuse box in engine compartment.
fuse box diagram.
Assignment of the fuses.
| Fuses | Amps | Circuits protected |
|---|---|---|
| 1 | 30A | Engine. |
| 2 | 30A | Power Window. |
| 3 | 60A | ABS. |
| 4 | 30A | Radiator Fan. |
| 5 | 30A | Ignition Switch. |
| 6 | 40A | Headlights. |
| 7 | 15A | Hazard. |
| 8 | 15A | Horn. |
| 9 | 20A | Stoplights. |
| 10 | 10A | Radio. |
| 11 | 10A | Room Lights. |
| 12 | 20A | Condensor Fan. |
| 13 | 10A | Air Conditioner. |
| 14 | 10A | Headlight Highbeam. |
| 15 | 15A | Foglamps. |
| 16 | 15A | Tailights. |
| Component | Location |
|---|---|
| A/C Compressor Clutch Relay | In engine compartment relay block. |
| A/C-Heater Blower Motor Relay | Under left side of instrument panel. See Fig. 2 . |
| A/C-Heater Blower Motor High Relay | Under right side of instrument panel, on blower motor. See Fig. 2 . |
| A/C Hi-Low Condenser Fan Relay | In engine compartment relay block. |
| A/T Relay (2.0L) | On cowl, at left rear of engine compartment. See Fig. 1 . |
| ASD Relay (2.0L) | On cowl, at left rear of engine compartment. See Fig. 1 . |
| Back-Up Light Relay (2.0L) | On cowl, at left rear of engine compartment. See Fig. 1 . |
| Cruise Control Relay (2.0L) | On cowl, at right rear of engine compartment. See Fig. 1 . |
| Door Lock Power Relay No. 1 | Under center console, near floor. |
| Door Lock Power Relay No. 2 (For Keyless Entry) | In left quarterpanel, in front of wheel housing. See Fig. 3 . |
| Foglight Relay | In engine compartment relay block. |
| Fuel Pump Relay (2.0L) | On cowl, at left rear of engine compartment. See Fig. 1 . |
| Headlight Relay | In engine compartment relay block. |
| High Beam Relay | At left headlight assembly. |
| Horn Relay | In engine compartment relay block. |
| Power Windows Relay | Under left side of instrument panel. |
| Radiator Fan Hi-Low Relay | In engine compartment relay block. |
| Rear Intermittent Wiper Relay | Integral with switch on center console. |
| Rear Window Defogger Relay | Under left side of instrument panel. See Fig. 2 . |
| Starter Relay | Under center console, near floor. See Fig. 2 . |
| Taillight Relay | In engine compartment relay block. |
| Theft-Alarm Horn Relay | Under left side of instrument panel. |
| Theft-Alarm Starter Relay | Under left side of instrument panel. |
| Turn Signal & Hazard Flasher Unit | Behind A/C control panel, in center console. See Fig. 2 . |
| Windshield Intermittent Wiper Relay | Left side of steering column. |
