For Fiat Doblo /-Cargo (223) 2000, 2001, 2002, 2003, 2004, 2005, 2006, 2007, 2008, 2009, 2010 model year.
Cigarette lighter fuse – fuse box in passenger compartment – Fuse F10/20A |
MENU
Fuse box in passenger compartment.
Fuse box in engine compartment.
Fuse box in passenger compartment.
fuse box location.
To access the fuses, press the cover at the points shown in figure open it.
Assignment of the fuses.
1 | Headlamp relay |
2 | Door mirror heater relay |
3 | Heated rear window relay |
4 | Rear screen wiper relay |
F1 | (15A) Audio system |
F2 | (10A) Boot lamp |
F3 | (20A) Central locking |
F4 | (10A) Hazard warning lamps |
F5 | (7,5A) Reversing lamp |
F6 | (15A) Rear screen wiper |
F7 | (7,5A) Door mirror heaters |
F8 | (30A) Windscreen washer pump |
F9 | (30A) Heated rear window |
F10 | (20A) Cigarette lighter |
F11 | (15A) Heated front seat |
F12 | (20A) Electric window motor, front left |
F13 | (20A) Headlamp control module |
F14 | (7,5A) Airbag |
F15 | (7,5A) Instrument panel lamp(s) |
F16 | – |
F17 | – |
F18 | (10A) Instrument panel lamp(s), warning lamps, ignition switch |
F19 | (7,5A) ABS control module |
F20 | (10A) Headlamp high beam,right |
F21 | – |
F22 | (20A) Electric window motor, front right |
F23 | (7,5A) Ignition system |
F24 | – |
F25 | (10A) Headlamp high beam,left |
Right headlights
7.5 A
Fuse 2
Courtesy light(s)
Luggage compartment light(s)
7.5 A
Fuse 3
Instrument panel
5.0 A
Fuse 4
Central locking
20.0 A
Fuse 5
Bluetooth control unit
Climate control
Diagnostic socket
Radio
10.0 A
Fuse 6
Windscreen washer
Rear windscreen washer
15.0 A
Fuse 7
Passenger's power window
20.0 A
Fuse 8
Dipped beam
Headlight levelling
7.5 A
Fuse 9
Airbag
7.5 A
Fuse 10
Bluetooth control unit
Climate control
Electric mirrors
Brake light switch
Clutch switch
Radio
7.5 A
Fuse 11
Brake light switch
Instrument panel
5.0 A
Fuse 12
Electric sunroof
Control panel
Accessory socket
Reversing light switch
Parking sensor
5.0 A
Fuse 13
Engine compartment junction block
5.0 A
Fuse 14
Driver's side power window
20.0 A
Fuse box in engine compartment.
fuse box location.
legend.
1 | Headlamp high beam relay |
2 | Heater blower relay |
3 | Horn relay |
4 | Fog lamp relay |
5 | – |
6 | Engine coolant blower motor relay |
7 | AC compressor clutch relay |
8 | Engine coolant blower motor relay |
9 | Fuel pump (FP) relay |
10 | Engine control (EC) relay |
11 | – |
12 | Engine control (EC) relay |
F1 | (40A) Ignition auxiliary circuits relay |
F2 | (70A) Lighting circuits control relay, door mirror heater relay, heated rear window relay, rear screen wiper relay, audio unit, telephone connector, navigation system, interior lamps (sun visor), glove box, luggage compartment lamp, data link connector (DLC) |
F3 | (30A) Except 1,9D: Alternator cooling fan (low speed) |
F4 | (40A) Except 1,9D: Alternator cooling fan |
F5 | (60A) Glow plugs |
F6 | (50A) Anti-lock brake system (ABS) |
F7 | (20A) Ignition switch |
F8 | (7,5A) Engine control module (ECM) fuse – battery voltage |
F9 | (15A) Fuel pump(FP) |
F10 | (7,5A) Fuel pump (FP) (Diesel) |
F11 | (20A) Fuel pump (FP) (1,2 petrol) |
F12 | (15A) Tachometer |
F13 | – |
F14 | (20A) Fuel filter heater – Diesel |
F15 | (10A) Headlamp high beam |
F16 | (30A) Engine coolant blower motor |
F17 | (10A) Headlamp high beam |
F18 | (15A) Horn |
F19 | (7,5A) Air conditioning (AC) |
F20 | (7,5A) Engine control module (ECM) |
F21 | (15A) Fog lamps |
F22 | – |
legend.
Fuse 1a
Rear right power window
20.0 A
Fuse 1b
Accessory socket
50.0 A
Fuse 2
Brake vacuum pump
40.0 A
Fuse 3
Glow plug control unit
(50A also used)
60.0 A
Fuse 4
Rear left power window
20.0 A
Fuse 5
Body control unit
60.0 A
Fuse 6
Cooling fan, low speed
30.0 A
Fuse 7
Ignition switch
20.0 A
Fuse 8
Cooling fan, high speed
30.0 A
Fuse 9
Additional heater
50.0 A
Fuse 10
Headlight washer
20.0 A
Fuse 11
Climate control fan
40.0 A
Fuse 12
Engine management
(15A also used)
20.0 A
Fuse 13
Engine control
10.0 A
Fuse 14
Engine management
Or
Not used
10.0 A
Fuse 15
Brake control (BS)
20.0 A
Fuse 16
Additional heater
30.0 A
Fuse 17
Fuel pump
15.0 A
Fuse 18
Engine control
7.5 A
Fuse 19
Fog lights
15.0 A
Fuse 20
Not used
Fuse 21
Manual climate control compressor
7.5 A
Fuse 22
Tailgate
10.0 A
Fuse 23
Main beam
15.0 A
Fuse 24
Heated mirrors
7.5 A
Fuse 25
Rear windscreen demister and defroster
30.0 A
Fuse 26
12V socket
30.0 A
Fuse 27
Accessory socket
30.0 A
Fuse 28
Battery sensor
5.0 A
Fuse 29
Engine management
7.5 A
Fuse 30
Brake control (BS)
Electric steering
5.0 A
Fuse 31
Horns
10.0 A
Relay R1
Climate control fan
Power socket
Heated seats
Relay R2
Cooling fan, high speed
Relay R3
Headlight washer
Relay R4
Horns
Relay R5
Cooling fan, low speed
Relay R6
Heated rear windscreen
Heated mirrors
Relay R7
Engine management system
Relay R8
Fuel pump relay
Additional relay, fuel pump
Relay R9
Start signal
Or
Not used
Relay R10
Fog lights
Relay R11
Climate control compressor relay
Relay R12
Headlight relay, main beam
Relay R13
Start signal
Or
Not used
