For Fiat Palio /-Weekend/Strada/Siena/Albea (178) 1997, 1998, 1999, 2000, 2001, 2002, 2003, 2004, 2005, 2006 model year.
Cigarette lighter fuse – fuse box in passenger compartment – Fuse F19/30A (pre 2001) Cigarette lighter fuse – fuse box in passenger compartment – Fuse F44/20A (since 2001) |
Fuse box in passenger compartment.
fuse box location.
fuse box diagram (pre 2001).
Assignment of the fuses.
Fuse 1
Windscreen wiper(s)
Windscreen washer(s)
Rear wiper
Rear washer
20.0 A
Fuse 2
Front power windows
Electric mirrors
25.0 A
Fuse 3
Rear power windows
25.0 A
Fuse 4
Left main beam
10.0 A
Fuse 5
Right main beam
10.0 A
Fuse 6
Rear fog light(s)
10.0 A
Fuse 7
Front left sidelight
Right tail light
Instrument panel lighting
Climate control switches
10.0 A
Fuse 8
Front right sidelight
Left tail light
Number plate light(s)
Cigarette lighter illumination
Clock illumination
Glovebox light(s)
10.0 A
Fuse 9
Fog light
15.0 A
Fuse 10
Central locking
20.0 A
Fuse 11
Heated rear windscreen
30.0 A
Fuse 12
Hazard warning lights
10.0 A
Fuse 13
Horn
20.0 A
Fuse 14
Brake lights
Electric mirrors
10.0 A
Fuse 15
Direction indicators
Clock
Instrument panel supply
Reversing light(s)
Airbag
Alarm control unit
Radio
15.0 A
Fuse 16
Air-conditioning compressor
Cooling fan
10.0 A
Fuse 17
Left dipped beam
10.0 A
Fuse 18
Right dipped beam
Headlight levelling
10.0 A
Fuse 19
Blower
Cigarette lighter
30.0 A
Fuse 20
Interior light(s)
Alarm system
Clock
Radio
10.0 A
Fuse 21
Not used
10.0 A
Fuse 22
ABS
Or
ESP control unit
10.0 A
Fuse 23
Fiat CODE
10.0 A
Fuse 24
Headlight washers
20.0 A
Fuse 25
Not used
Fuse SP1
Spare fuse/relay
10.0 A
Fuse SP2
Spare fuse/relay
15.0 A
Fuse SP3
Spare fuse/relay
20.0 A
Fuse SP4
Spare fuse/relay
30.0 A
Relay 138
Rear fog light relay
Relay 185
Key discharge relay
Relay 178
Headlight washer relay
Relay 80
Relay, rear power windows
Relay 198
Hazard warning light relay (with remote central locking)
Relay 63
Central locking control unit
Relay E4
Front fog light relay
Relay E5
Dipped beam relay
Relay E9
Heated rear windscreen relay
Relay E10
Horn relay
Fuse box in passenger compartment (since 2001).
legend.
Fuse 12
Right dipped beam
10.0 A
Fuse 13
Headlight levelling
Left dipped beam
10.0 A
Fuse 31
Reversing light(s)
Blower relay
Heater
Air conditioning
7.5 A
Fuse 32
Sidelights
+30
15.0 A
Fuse 33
Rear left power window
20.0 A
Fuse 34
Rear right power window
20.0 A
Fuse 35
Reversing lights
Instrument panel lighting
10.0 A
Fuse 36
Trailer control unit
+30
15.0 A
Fuse 37
Brake lights
Instrument panel
10.0 A
Fuse 38
Central locking
20.0 A
Fuse 39
+30
Radio
Alarm system
Diagnostic socket
10.0 A
Fuse 40
Heated rear windscreen
30.0 A
Fuse 41
Not used
Or
Mirrors
7.5 A
Fuse 42
ABS control unit
7.5 A
Fuse 43
Windscreen wiper(s)
Windscreen washer pump
30.0 A
Fuse 44
Cigarette lighter
20.0 A
Fuse 45
Not used
Or
Heated seats
15.0 A
Fuse 46
Not used
Or
Sunroof
30.0 A
Fuse 47
Front left power window
20.0 A
Fuse 48
Front right power window
20.0 A
Fuse 49
Control lights
Electric mirrors
Courtesy light(s)
7.5 A
Fuse 50
Airbag
7.5 A
Fuse 51
Control lights
Instrument lighting
Number plate light(s)
7.5 A
Fuse 52
Rear wiper
15.0 A
Fuse 53
Direction indicators
Instrument panel warning lights
Hazard warning lights
10.0 A
Relay T01
Dipped beam relay
Relay T11
Heated rear windscreen relay
Relay T12
Windscreen wiper relay(s)
Cigarette lighter relay
Relay T13
Power window relay
Fuse box in engine compartment (pre 2001).
legend.
Fuse 1
Fuel injection
Ignition system
15.0 A
Fuse 2
Fuel injection
Fiat CODE
5.0 A
Relay 3
Multiple relay
Relay box in engine compartment (pre 2001).
Relay 1
Cooling fan, stage 2 timer
Relay 2
Cooling fan, stage 1
Relay 3
Cooling fan, stage 2
Relay 4
Air-conditioning compressor
Fuse box in engine compartment (since 2001).
legend.
Fuse FL0
Not used
Fuse FL1
Dashboard power, standard functions
Fuse box in passenger compartment
70.0 A
Fuse FL2
Dashboard power, optional functions
Fuse box in passenger compartment
40.0 A
Fuse FL3
Ignition switch
20.0 A
Fuse FL4
ABS power
50.0 A
Fuse FL5
Climate control fan relay
60.0 A
Fuse FL6
Cooling fan, stage 1 (30A for single stage fan)
(40A also used)
30.0 A
Fuse FL7
Cooling fan, stage 2
(40A also used)
60.0 A
Fuse FL8
Fan relay
40.0 A
Fuse F09
Headlight washer
20.0 A
Fuse F10
Horn relay
15.0 A
Fuse F11
No information is available
15.0 A
Fuse F14
Right main beam
10.0 A
Fuse F15
Left main beam
10.0 A
Fuse F16
Engine control system relay
7.5 A
Fuse F17
Engine control unit
7.5 A
Fuse F18
+30
Engine control unit
7.5 A
Fuse F19
Air-conditioning compressor relay
Or
Horn
7.5 A
Fuse F20
Not used
Fuse F21
Fuel pump relay
Additional relay, fuel pump
15.0 A
Fuse F22
Ignition coils
Injectors
20.0 A
Fuse F23
Spare relay
15.0 A
Fuse F30
Fog lights
15.0 A
Relay T02
Main beam relay
Relay T03
Horn relay
Relay T05
Air-conditioning compressor relay
Or
Horn
Relay T06
Cooling fan relay, stage 1
Relay T07
Cooling fan relay, stage 2
Relay T08
Air conditioning
Blower relay
Relay T09
Main relay
Relay T10
Fuel pump relay
Additional relay, fuel pump
Relay T14
Fog light relay
Relay T17
Headlight washer relay
Relay T19
Not used
Relay T20
Spare relay
