For Citroen C2 (A6) 2003, 2004, 2005, 2006, 2007, 2008, 2009, 2010 model year.
| Cigarette lighter fuse – Fuse box in passenger compartment (pre 2005) – Fuse F22/30A Cigarette lighter fuse – Fuse box in passenger compartment (since 2005) – Fuse F9/30A |
MENU
Fuse box in passenger compartment (pre 2005).
Fuse box in passenger compartment (since 2005).
Fuse box in engine compartment (pre 2005).
Fuse box in engine compartment (since 2005).
Fuse box in passenger compartment (pre 2005).
fuse box location.
fuse box diagram (pre 2005).
Assignment of the fuses (pre 2005).
| F1 | (15A) Data link connector (DLC) |
| F4 | (20A) Alarm system, audio unit, digital clock, digital multifunction display, fuse box(engine bay), steering column function control module, telematics |
| F5 | (15A) Alarm system horn |
| F6 | (10A) Data link connector (DLC), steering column function control module, transmission mode selection switch |
| F7 | (15A) Alarm system, ambient light sensor, rain sensor |
| F9 | – |
| F10 | (40A) Heated rear window, electric door mirrors |
| F11 | (15A) Rear screen wash/wipe system |
| F12 | (30A) Electric windows |
| F14 | (10A) Fuse box (engine bay), SRS control module, steering column function control module |
| F15 | (15A) Audio unit, digital multifunction display, heater/air conditioning (AC), instrument panel, parking aid control module, telematics |
| F16 | (30A) Central locking |
| F20 | (10A) RH tail lamp |
| F21 | (15A) LH tail lamp, stop lamp (high level) |
| F22 | (30A) Accessories connector – front, audio system, cigarette lighter, electric door mirrors, interior lamp, digital clock, licence plate lamps, vanity mirror lamps |
Fuse box in passenger compartment (since 2005).
To access the fuses under the dashboard, detach the cover by sliding your fi ngers in the space between the bottom of the dashboard and the steering wheel.
fuse box diagram (since 2005).
legend.
| Ref. | Rating | Function |
|---|---|---|
| 3 | 5 A | Airbags |
| 4 | 10 A | Diagnostic socket – Particle filter additive – Clutch switch – Steering angle sensor |
| 5 | 30 A | |
| 6 | 30 A | Screen wash |
| 8 | 20 A | Digital clock – Controls at the steering wheel – Radio – Display |
| 9 | 30 A | Cigar-lighter – Digital clock – Interior lamps – Vanity mirror |
| 10 | 15 A | Alarm |
| 11 | 15 A | Ignition switch – Diagnostic socket |
| 12 | 15 A | Airbag ECU – Rain and brightness sensor |
| 14 | 15 A | Parking assistance – Instrument panel – Air conditioning – Bluetooth telephone |
| 15 | 30 A | Central locking – Deadlocking |
| 17 | 40 A | Demisting – deicing of the rear screen |
| 18 | SHUNT | CUSTOMER PARK SHUNT |
Fuse box in engine compartment (pre 2005).
To access the fusebox located in the engine compartment, remove the battery cover and detach the lid.
fuse box diagram (pre 2005).
legend (pre 2005).
| 1 | (10A) Electronic stability program (ESP) control module, fuel/water separator sensor, glow plugs, reversing lamp, transmission control module (TCM), vehicle speed sensor (VSS) |
| 2 | (15A) Fuel pump |
| 3 | (10A) ABS control module, electronic stability program (ESP) control module |
| 4 | (10A) Brake pedal position (BPP) switch, clutch pedal position(CPP) switch, cruise control, engine control module (ECM), engine coolant heater relays, engine coolant ‘low’ sensor, power steering control module, starter motor inhibitor switch relay |
| 5 | (10A) Fuel additive control module – (if fitted) |
| 6 | (15A) Front fog lamps |
| 7 | (20A) Headlamp washer pump |
| 8 | (20A) Engine management |
| 9 | (15A) LH headlamp – low beam |
| 10 | (15A) RH headlamp – low beam |
| 11 | (10A) LH headlamp – high beam |
| 12 | (10A) RH headlamp – high beam |
| 13 | (15A) Horn |
| 14 | (10A) Windscreen/rear screen washer pump |
| 15 | (30A) Engine management |
| 16 | (30A) Secondary air injection (AIR) pump |
| 17 | (30A) Windscreen wiper motor |
| 18 | (40A) Heater/air conditioning (AC) |
| MF1 | (30A) Engine coolant blower motor |
| MF2 | (30A) Anti-lock brake system (ABS) |
| MF3 | (30A) Anti-lock brake system (ABS) |
| MF4 | (60A) Multifunction control module 1 |
| MF5 | (70A) Multifunction control module 1 |
| MF6 | (20A) Heated seats |
| MF7 | (30A) Ignition switch |
| MF8 | (80A) Power steering |
Fuse box in engine compartment (since 2005).
legend (since 2005).
| Ref. | Rating | Function |
|---|---|---|
| 1 | 20 A | Water-in-diesel-fuel sensor |
| 2 | 15 A | |
| 3 | 10 A | Screen wash |
| 4 | 20 A | Headlamp wash |
| 5 | 15 A | Fuel pump |
| 6 | 10 A | Power steering |
| 7 | 10 A | Coolant level sensor |
| 8 | 25 A | Starter |
| 9 | 10 A | ECUs (ABS, ESP) |
| 10 | 30 A | Engine control actuators (Ignition coil, Electrovalve, Oxygen sensor, Injection) – Canister purge |
| 11 | 40 A | Air blower |
| 12 | 30 A | Windscreen wiper |
| 14 | 30 A | Air pump (petrol version) – Diesel fuel heater |
