For Citroen XM 1989, 1990, 1991, 1992, 1993, 1994, 1995, 1996, 1997, 1998, 1999, 2000, 2001 model year.
Cigarette lighter fuse – fuse box in passenger compartment – Fuse F36/15A/30A |
MENU
Fuse box in passenger compartment.
Fuse box in engine compartment.
Fuse box in passenger compartment.
fuse box diagram (since 1992).
Assignment of the fuses.
| 1 | Fog lamps relay |
| 2 | Sunroof supply relay |
| 3 | Electric window relay – front |
| 4 | Windscreen wiper intermittent relay |
| 5 | Engine running relay |
| 6 | Heated rear window relay |
| 7 | – |
| 8 | Seat heater relay |
| 9 | – |
| 10 | Rear screen intermittent wiper relay |
| 11 | Indicator/hazard warning relay |
| 12 | Side lamps ‘on’ warning buzzer |
| F1 | (10A)ABS |
| F2 | (10A) Stop lamps, brake pad wear warning lamp |
| F3 | (5A) Sparefuse |
| F4 | (10A) Instrument panel illumination, trip computer, digital display/clock illumination |
| F5 | (30A) Warning lamps, digital display, door mirror adjustment, indicators, trip computer/clock, interior lamps |
| F6 | (5A) Rear fog lamps |
| F7 | (20A) Sparefuse |
| F8 | (30A) Sparefuse |
| F9 | (30A) Accessories, windscreen wiper motor – front, windscreen wiper intermittent relay, rear screen wiper motor, rear screen intermittent wiper relay, heated rear window relay |
| F10 | (5A) Switch illumination, console illumination, bonnet lamp, side lamps, licence plate lamp |
| F11 | (5A) Digital display – language selection |
| F13 | (10A) Hazard warning lamps |
| F14 | (5A) Tail lamp – right |
| F15 | (5A) Digital display – language selection |
| F17 | (30A) Seat heater- rear, sunroof |
| F18 | (5A) Tail lamp – left |
| F19 | (15A) Suspension control module |
| F21 | (15A) Fog lamps – front, rear fog lamp warning lamp |
| F22 | (20A) Cellular telephone |
| F23 | (10A/15A) Instrument illumination rheostat, reversing lamps, air conditioning compressor, engine level/temperature control module, tachometer, engine oil temperature sensor, engine coolant temperature sensor |
| F25 | (30A) Heater |
| F26 | (20A) Sparefuse |
| F27 | (20A) Interior lamp delay relay, trip computer/clock, sill panel lamps, horn |
| F28 | (30A) Seat adjustment – right front |
| F29 | (30A) Electric windows – front |
| F30 | (30A) Seat adjustment – leftfront |
| F31 | (30A) Electric windows – rear |
| F32 | (30A) Headlamp washer |
| F33 | (30A) Heated rear window, door mirror heater |
| F34 | (30A) Suspension adjustment, central locking |
| F35 | (30A) Seat heater-front, armrest |
| F36 | (15A) Cigarette lighter, 12v socket, electric window cut-off – rear |
legend.
| 1 | Fog lamps relay |
| 2 | Sunroof supply relay |
| 3 | Electric window relay – front |
| 4 | Windscreen wiper intermittent relay |
| 5 | Engine running relay |
| 6 | Heated rear window relay |
| 7 | – |
| 8 | Seat heater relay – rear |
| 9 | Seat heater relay – front |
| 10 | Rear screen intermittent wiper relay |
| 11 | Indicator relay |
| 12 | Side lamps ‘on’ warning buzzer |
| F1 | (10A)ABS |
| F2 | (10A) Stop lamps, brake pad wear warning lamp, cruise control, water temperature control module, suspension system warning buzzer |
| F3 | (10A) Air conditioning system, heated rear window, door mirror heater, seat heater |
| F4 | (10A) Instrument panel illumination, digital display illumination, trip computer/clock illumination |
| F5 | (30A) Engine running relay, audio unit, digital display, door mirror adjustment, cellular telephone, instrument panel illumination rheostat, indicators, interior lamps, central locking, deadlock system, glovebox lamp, trip computer/clock, warning lamps |
| F6 | (5A) Rear fog lamps |
| F7 | (10A) Suspension control module, body movement sensor |
| F8 | (30A) Sparefuse |
| F9 | (30A) Electric window relay, sunroof relay, windscreen wipers, rear screen wiper, side lamps on warning buzzer, engine coolant blower motor (slow speed), seat adjustment relay – front |
| F10 | (5A) Side lamps, switch illumination, ashtray illumination |
| F11 | (5A) Digital display – language selection |
| F12 | – |
| F13 | (10A) Hazard waning lamps |
| F14 | (5A) RH tail lamp |
| F15 | (5A) Digital display – language selection |
| F16 | – |
| F17 | (30A) Seat heater – rear |
| F18 | (5A) LH tail lamp |
| F19 | – |
| F20 | – |
| F21 | (15A) Fog lamps- front/rear |
| F22 | (30A) Cellular telephone, central locking, deadlock, alarm system horn |
| F23 | (15A) Engine coolant temperature control module, tachometer, air conditioning system, reversing lamps, instrument warning lamps/gauges, speed sensor, interior lamp delay, engine coolant level control module, transmission (AT), alarm system, mirror adjustment control module |
| F24 | – |
| F25 | (30A) Sunroof |
| F26 | (20A) Sparefuse |
| F27 | (20A) Trip computer, clock, horn, instrument panel, door lamps, boot lid/tailgate lamp, interior lamp, interior lamp delay relay |
| F28 | (30A) Seat adjustment – front passenger |
| F29 | (30A) Electric windows – front, door mirror adjustment control module |
| F30 | (30A) Seat adjustment – front driver |
| F31 | (30A) Electric windows – rear, electric windows – front (anti pinch) |
| F32 | (30A) Headlamp washers |
| F33 | (30A) Heated rear window relay, door mirror heater |
| F34 | (30A) Suspension adjustment, central locking, alarm system, central locking signal control module, engine coolant control module |
| F35 | (30A) Seat heater-front, seat armrest adjustment – front, cigarettelighter |
| F36 | (30A) Cigarette lighter, audio unit memory |
Fuse box diagram (since 1995).
legend.
| 1 | Fog lamps relay |
| 2 | Sunroof supply relay |
| 3 | Electric window relay – front |
| 4 | Windscreen wiper intermittent relay |
| 5 | Engine running relay |
| 6 | Heated rear window relay |
| 7 | – |
| 8 | Seat heater relay – rear |
| 9 | Seat heater relay – front |
| 10 | Rear screen intermittent wiper relay |
| 11 | Indicator relay |
| 12 | Side lamps ‘on’ warning buzzer |
| F1 | (10A)ABS |
| F2 | (10A) Stop lamps, cruise control, water temperature control module |
| F3 | (10A) Air conditioning system, heated rear window, door mirror heater, seat heater |
| F4 | (5A) digital display (language selection) |
| F5 | (10A) Engine running relay, audio unit, digital display, door mirror adjustment, cellular telephone, instrument panel illumination rheostat, indicators, interior lamps, central locking, deadlock system, glovebox lamp, warning lamps |
| F6 | (5A) Rear fog lamps |
| F7 | (10A) Suspension control module, body movement sensor |
| F8 | (5A) Digital display – language selection |
| F9 | (30A) Electric window relay, sunroof relay, windscreen wipers, rear screen wiper, side lamps on warning buzzer, engine coolant blower motor (slow speed), seat adjustment relay – front, over speed audible warning |
| F10 | (5A) Side lamps, switch illumination, ashtray illumination |
| F11 | (10A) Instrument panel illumination, switch illumination lamps |
| F12 | (5A) Digital display – language selection |
| F13 | (10A) Hazard waning lamps, diagnostic link |
| F14 | (5A) RH tail lamp |
| F15 | (30A) Sparefuse |
| F16 | (5A) Sparefuse |
| F17 | (20A) Seat heater – rear |
| F18 | (5A) LH tail lamp |
| F19 | (15A) Engine coolant temperature control module, alarm system, air conditioning system, reversing lamps, instrument warning lamps/gauges, speed sensor, interior lamp delay, engine coolant level control module, transmission (AT), mirror adjustment control module, diagnostic link, catalytic converter control module |
| F20 | (5A) Sparefuse |
| F21 | (15A) Fog lamps- front/rear |
| F22 | – Bridged to fuse 22 |
| F23 | – Bridged to fuse 23 |
| F24 | (20A) Seat heater – front |
| F25 | (20A) Sunroof |
| F26 | (30A) Electric windows -rear |
| F27 | (15A) Alarm system, instrument panel, interior lamp, door lamps, boot lid/tailgate lamp, interior lamp delay relay, audio unit |
| F28 | (30A) Seat adjustment – front right |
| F29 | (15A) Sparefuse |
| F30 | (30A) Seat adjustment – front left |
| F31 | (10A) Engine control module, engine coolant temperature control module |
| F32 | (30A) Headlamp washer pump, horns |
| F33 | (30A) Heated rear window relay, door mirror heater |
| F34 | (30A) Suspension adjustment, central locking, alarm system, central locking signal control module, engine coolant control module |
| F35 | (30A) Electric windows – rear, electric windows – front (anti pinch) |
| F36 | (30A) Cigarette lighter |
Fuse box in engine compartment.
legend.
| Fuses | Amps | Circuits Protected |
|---|---|---|
| 1 | 30A | ABS Or ESP control unit |
| 2 | 20A | Not used |
| 3 | 30A | Cooling fan (40A also used) |
| 4 | 30A | Cooling fan |
| 5 | 30A | Air conditioning |
| 6 | 30A | EGR |
Fuse box diagram (since 1995).
legend.
| F1 | (10A) EGR control module, glow plugs relay |
| F2 | (30A) Air conditioning |
| F3 | (30A)ABS |
| F4 | – |
| F5 | – |
| F6 | – |
| F7 | – |
| F8 | – |
| F9 | (10A) Headlamp high beam – right |
| F10 | (10A)Automatic transmission 4HP20 or not used |
| F11 | (10A) Headlamp high beam – left |
| F12 | (10A) Oxygen sensor or not used |
| F13 | (10A) Headlamp low beam – left |
| F14 | (15A) Fusel pump or not used |
| F15 | (10A) Headlamp low beam – right |
