For Citroen Xsara 1997, 1998, 1999, 2000, 2001, 2002, 2003, 2004, 2005, 2006 model year.
Cigarette lighter fuse – fuse box in passenger compartment (pre 2000) – Fuse F16/20A Cigarette lighter fuse – fuse box in passenger compartment (since 2000) – Fuse F23/20A |
MENU
Fuse box in passenger compartment.
- fuse box diagram (pre 2000)
- fuse box diagram (since 2000 type 1)
- fuse box diagram (since 2000 type 2)
- fuse box diagram (since 2000 type 3)
Relays and diagnostic connector in passenger compartment.
Fuses on the BSI (built-in systems interface).
Relay box near the steering column.
Fuse box in engine compartment.
Fuse box No. 1 in engine compartment.
Fuse box in engine compartment (RHD).
Relay box in engine compartment.
Additional fuse box in engine compartment.
Fuse box in passenger compartment.
fuse box location.
Assignment of the fuses.
| 1 | Bridge |
| F1 | (10A) Audio system, audio unit CD changer |
| F2 | (5A) Transmission selector lamp, engine coolant blower motor control module, AC control module, AC refrigerant triple pressure switch, data link connector (DLC), vehicle speed sensor (VSS), instrument panel warning lamps, engine coolant blower motor relay – twin fan LH, engine coolant blower motor relay – twin fan RH, multifunction control module |
| F3 | (10A) ABS control module |
| F4 | (5A) RH tail lamp, LH side lamp |
| F5 | (5A) Daytime running lamps (if fitted) |
| F6 | (10A) Transmission control module (TCM) |
| F7 | (20A) Horn, trailer socket |
| F9 | (5A) LH tail lamp, RH side lamp, licence plate lamps |
| F10 | (30A) Rear electric windows |
| F11 | – |
| F12 | (20A) Instrument panel warning lamps, reversing lamps, stop lamps |
| F13 | (20A) Daytime running lamps (if fitted) |
| F14 | – |
| F15 | (20A) Engine coolant blower motor control module, multifunction control module |
| F16 | (20A) Cigarette lighter |
| F17 | – |
| F18 | (10A) Rear fog lamp |
| F19 | (5A) Lamps ‘on’ warning buzzer, side lamps |
| F20 | (30A) AC/heater air direction motor (^05/99) |
| F21 | (25A) Heated door mirrors, heated seats, heated rear window timer relay, air conditioning (AC) (^05/99) |
| F22 | (15A) Electric seats |
| F24 | (20A) Rear screen wash/wipe system, windscreen wash/wipe system, windscreen wiper motor, rain sensor |
| F25 | (10A) Audio system, clock, alarm system LED, instrument panel, data link connector (DLC), multifunction control module |
| F26 | (15A) Hazard warning lamps |
| F27 | (30A) Front electric windows, sunroof |
| F28 | (15A) Electric window cut-off switch, instrument panel, indicator relay, glove box lamp |
| F29 | (30A) Heated rear window timer relay, heated door mirrors |
| F30 | (15A) Rain sensor, reading lamps, outside air temperature sensor, rear screen wiper motor, electric windows, sunroof, electric door mirrors |
Fuse box diagram (since 2000 type 1).
legend.
Fuse 2
Air conditioning
Special equipment
5.0 A
Fuse 3
Instrument panel
Diagnostic socket
5.0 A
Fuse 4
Ignition control
BSI
5.0 A
Fuse 5
Automatic transmission relay
Automatic transmission lever
5.0 A
Fuse 6
Interior light(s)
5.0 A
Fuse 7
Navigation control unit
Dipped beam relay
Radio
Alarm system
10.0 A
Fuse 8
Hazard warning switch
Diagnostic system
Clock
Multifunction display
Protection and Switching unit
5.0 A
Fuse 9
BSI
5.0 A
Fuse 10
Radio
Horn
Special equipment
10.0 A
Fuse 11
Rear right sidelight
Front left sidelight
5.0 A
Fuse 12
Rear left sidelight
Front right sidelight
Number plate light(s)
5.0 A
Fuse 13
Not used
20.0 A
Fuse 14
Front power windows
30.0 A
Fuse 15
Relay, heated seats
Siren
20.0 A
Fuse 16
Sunroof motor
20.0 A
Fuse 17
Battery
15.0 A
Fuse 18
Lighting system
Clock
Heated rear windscreen
Rear power windows lock
Security alarm system
12V socket
Parking assistance
Cigarette lighter
Automatic transmission lever
Air conditioning
5.0 A
Fuse 19
Clutch switch
Brake light switch
10.0 A
Fuse 20
Speed sensor
Flow meter
Heater module
Coolant level sensor
Diesel contamination sensor
Immobiliser
5.0 A
Fuse 21
Not used
10.0 A
Fuse 22
Interior light(s)
5.0 A
Fuse 23
Cigarette lighter
12V socket
20.0 A
Fuse 23b
Cigarette lighter
20.0 A
Fuse 24
Radio
15.0 A
Fuse 24b
Radio
15.0 A
Fuse 25
Rear-view mirror dimming control
Clock
5.0 A
Fuse 26
Not used
20.0 A
Fuse 27
BSI
5.0 A
Fuse 28
Electric seats
15.0 A
1
Pretensioner and front airbag shunt
Fuse box diagram (since 2000 type 2).
legend.
Fuse 2
Air conditioning
Special equipment
5.0 A
Fuse 3
Instrument panel
Diagnostic socket
5.0 A
Fuse 4
Ignition control
BSI
5.0 A
Fuse 5
Automatic transmission relay
Automatic transmission lever
5.0 A
Fuse 6
Interior light(s)
5.0 A
Fuse 7
Navigation control unit
Dipped beam relay
Radio
Alarm system
5.0 A
Fuse 8
Hazard warning switch
Diagnostic system
Clock
Multifunction display
Protection and Switching unit
5.0 A
Fuse 9
BSI
5.0 A
Fuse 10
Radio
Horn
Special equipment
Security alarm system relay
Headlight washer relay
Dipped beam
20.0 A
Fuse 11
Rear right sidelight
Front left sidelight
5.0 A
Fuse 12
Rear left sidelight
Front right sidelight
Number plate light(s)
5.0 A
Fuse 13
Daylight running system
20.0 A
Fuse 14
Front power windows
30.0 A
Fuse 15
Relay, heated seats
20.0 A
Fuse 16
Sunroof motor
20.0 A
Fuse 17
Blower
30.0 A
Fuse 18
Lighting system
Steering wheel rotation sensor
Clock
Heated rear windscreen
Rear power windows lock
Security alarm system
Multifunction display
12V socket
Parking assistance
Cigarette lighter
Automatic transmission lever
Air conditioning
5.0 A
Fuse 19
Rear fog light(s)
Instrument panel
10.0 A
Fuse 20
Left dipped beam
Altimetric corrector
10.0 A
Fuse 21
Right dipped beam
Instrument panel warning lights
10.0 A
Fuse 22
Interior light(s)
Rain sensor
5.0 A
Fuse 23
Cigarette lighter
12V socket
20.0 A
Fuse 23b
Cigarette lighter
12V socket
20.0 A
Fuse 24
Radio
15.0 A
Fuse 24b
Radio
15.0 A
Fuse 25
Rear-view mirror dimming control
Clock
5.0 A
Fuse 26
Wiper switch, front and rear
20.0 A
Fuse 27
BSI
5.0 A
Fuse 28
Electric seats
15.0 A
1
Pretensioner and front airbag shunt
Fuse box diagram (since 2000 type 3).
legend.
Fuse 1
Shunt
Fuse 2
Air conditioning
Special equipment
5.0 A
Fuse 3
Instrument panel
Diagnostic connector
5.0 A
Fuse 4
BSI (Intelligent power distribution module)
5.0 A
Fuse 5
Automatic transmission
5.0 A
Fuse 6
Interior light(s)
5.0 A
Fuse 7
Navigation system
Dipped beam relay
Radio
Alarm
5.0 A
Fuse 8
Hazard warning light switch illumination
Clock
Diagnostic connector
5.0 A
Fuse 9
BSI (Intelligent power distribution module)
5.0 A
Fuse 10
Auto PC
Horn
Trailer connector socket
Alarm
Headlight washers
Special equipment
20.0 A
Fuse 11
Left sidelight
Right tail light
5.0 A
Fuse 12
Right sidelight
Left tail light
Number plate light(s)
5.0 A
Fuse 13
Daylight running system
20.0 A
Fuse 14
Power window relay
30.0 A
Fuse 15
Heated front seat(s)
20.0 A
Fuse 16
Blower
20.0 A
Fuse 17
Blower
30.0 A
Fuse 18
Instrument lighting
5.0 A
Fuse 19
Fog light(s)
Fog light switch illumination
10.0 A
Fuse 20
Left dipped beam
Headlight levelling
Left
10.0 A
Fuse 21
Right dipped beam
Headlight switch illumination
10.0 A
Fuse 22
Courtesy mirror
Rain sensor
Glovebox illumination
Interior light(s)
5.0 A
Fuse 23
Cigarette lighter
Accessory socket
20.0 A
Fuse 23b
Cigarette lighter
Accessory socket
20.0 A
Fuse 24
Audio system
10.0 A
Fuse 24b
Audio system
10.0 A
Fuse 25
Clock
Electric rear-view mirror
5.0 A
Fuse 26
Front and rear wipers
30.0 A
Fuse 27
BSI (Intelligent power distribution module)
5.0 A
Fuse 28
Electric driver’s seat
15.0 A
Relays and diagnostic connector in passenger compartment.
legend.
Fuse 1
Fuse box
Relay R1
Central locking
Relay R2
Flasher relay
Relay R3
Not used
Relay R4
Not used
Relay R5
Engine running
Relay R6
Heated rear windscreen
Relay R7
Rear windows
Relay R8
Not used
Relay R9
Not used
Relay R10
Windows
Sunroof
Relay R11
Sidelights
Relay R12
Wiper system
Relay R13
Dipped beam
Relay R14
Wiper system
D
Diagnostic connector
legend.
Relay R1
Central locking, rear doors
Relay R2
Flasher unit
Relay R3
Not used
Relay R4
Not used
Relay R5
Not used
Relay R6
Blower relay
Relay R7
Not used
Relay R8
Relay, rear power windows
Relay R9
Heated rear windscreen switch
Relay R10
Engine running relay
Relay R11
Not used
Relay R12
Front power windows
Sunroof
Relay R13
Windscreen wiper delay
Relay R14
Speed control relay
Relay R15
Rain sensor relay
Relay R16
Daylight running system relay
Relay R17
Dipped beam relay (with daylight running system)
legend.
| 1 | Rear electric window cut-off relay |
| 2 | Indicator relay |
| 3 | – |
| 4 | – |
| 5 | – |
| 6 | Engine running circuits relay |
| 7 | Heated rear window timer relay |
| 8 | Electric window relay – rear |
| 9 | – |
| 10 | Heater blower relay |
| 11 | – |
| 12 | Electric window relay – front/sunroof motor relay |
| 13 | Windscreen wiper intermittent relay |
| 14 | Rain sensor relay (speed control) |
| 15 | Rain sensor relay |
| 16 | Daytime running lamps relay – side lamps |
| 17 | Daytime running lamps relay – low beam |
Fuses on the BSI (built-in systems interface). (since 2000)
fuse box diagram.
legend.
| F1 | (20A) Central locking |
| F2 | (25A) Windscreen wipers |
| F3 | (30A) Heated door mirrors, heated rear window |
| F4 | (15A) Air conditioning (AC) |
| F5 | (30A) Electric windows, sunroof |
| F6 | (15A) Anti-lock brake system (ABS), CAN data bus |
Relay box near the steering column. (since 2000)
| 1 | Electric window relay, rear – circuit breaker |
| 2 | Transmission park position interlock solenoid relay |
| 3 | Seat heater relay |
Fuse box in engine compartment.
fuse box location (near the battery).
legend.
| 1 | Front fog lamps relay |
| 2 | AC compressor clutch cut-off relay |
| 3 | AC compressor clutch relay |
| 4 | Headlamp washer pump delay relay |
| 5 | Fuel injection timing solenoid relay |
| 6 | Starter motor relay – AT |
| 7 | Power steering system relay |
| FA | (60A) Fuel system, ignition switch |
| FB | (40A) Fuel system, ignition switch |
| FC | (80A) Fuel system, fuse box (fascia) |
| FD | (40A) Fuel system, light switch |
| FE | (40A) Fuel system, engine coolant blower motor |
| FF | (40A) Fuel system, engine coolant blower motor |
| FG | – |
| FH | (50A) Anti-lock brake system (ABS) |
| F1 | (20A) Headlamp washers |
| F2 | – |
| F3 | (20A/30A) Engine coolant blower motor- 120W/200W(1998^) |
| F4 | – |
| F5 | (30A) Engine coolant blower motor – 120W/200W(1998^) |
| F6 | (20A) Front fog lamp relay |
| F7 | (5A) Engine coolant blower motor – with AC (^1997) |
| F8 | – |
| F9 | (15A) Fuel pump |
| F10 | (10A) Throttle body heater |
| F11 (15A) Oxygen sensor heater | |
| F12 (10A) LH headlamp-high beam | |
| F13 (10A) RH headlamp – high beam | |
| F14 (10A) LH headlamp-low beam | |
| F15 (10A) RH headlamp – low beam | |
Fuse box diagram (since 2000).
type 1
type 2.
legend (type 1 and type 2).
| 1 | (10A) Automatic transmission (AT), engine coolant blower motor relay, reversing lamps |
| 2 | (15A) Engine coolant heater, fuel pump |
| 3 | (10A) Anti-lock brake system (ABS) |
| 4 | (10A) Automatic transmission (AT), engine management |
| 5 | (10A) Alarm system horn – if fitted, automatic transmission (AT), engine management |
| 6 | (15A) Front fog lamps |
| 7 | (20A) Headlamp washer pump |
| 8 | (20A) Anti-lock brake system (ABS), engine coolant blower motor relay, engine management |
| 9 | (15A) LH headlamp – low beam |
| 10 | (15A) RH headlamp – low beam |
| 11 | (10A) LH headlamp – high beam |
| 12 | (10A) RH headlamp – high beam |
| 13 | (15A) Horn |
| 14 | (10A) Rear screen washer pump |
| 15 | (30A) Engine management |
| 16 | (30A) Secondary air injection (AIR) pump |
| 17 | (30A) Windscreen wipers |
| 18 | (40A) Heater/air conditioning (AC) |
| MF1 | (50A) Engine coolant blower motor relay |
| MF2 | (50A) Anti-lock brake system (ABS) |
| MF3 | (30A) Engine coolant heater |
| MF4 | (50A) Multifunction control module 1 |
| MF5 | (50A) Anti-lock brake system (ABS), multifunction control module 1 |
| MF6 | (30A) Fuse box/relay plate, fascia 1 |
| MF7 | (50A) Ignition switch |
| MF8 | (70A) Fuse box/relay plate, fascia 1 |
Fuse box No. 1 in engine compartment.
Fuse MF1
BSI
50.0 A
Fuse MF4
Anti-lock brakes
50.0 A
Fuse 5
Dipped beam relay
15.0 A
Fuse 6
Not used
30.0 A
Fuse 7
Fuel burning heater
25.0 A
Fuse MF8
Fuse box No. 1 in passenger compartment
70.0 A
Fuse MF9
BSI
50.0 A
Fuse MF10
Additional heater relay
40.0 A
Fuse MF11
Fuse box No. 1 in passenger compartment
30.0 A
Fuse MF12
Ignition switch
50.0 A
Fuse MF13
Not used
40.0 A
Fuse 14
Alarm siren
5.0 A
Fuse MF15
Cooling fan
50.0 A
Fuse MF16
Not used
40.0 A
Fuse MF17
Not used
30.0 A
Fuse 18
Main beam
10.0 A
Fuse 19
Main beam
10.0 A
Fuse 20
Brake light(s)
10.0 A
Fuse 21
Not used
5.0 A
Fuse 22
BSI
20.0 A
Fuse 23
Anti-lock brakes
10.0 A
Fuse 24
Preheating
Double relay
Cooling fan relay
Diesel fuel heater
Coolant level
Turbocharger
Vehicle speed sensor
Engine control unit
Flow meter
Diesel contamination sensor
5.0 A
Fuse 25
Fuel pump
15.0 A
Fuse 26
Double relay
30.0 A
Fuse 27
Double relay
Automatic transmission control unit
20.0 A
Fuse 28
Oxygen sensor
EGR
Injection pump, diesel
EGR solenoid
15.0 A
Fuse 29
Air pump
Additional heater
30.0 A
Fuse 30
Front fog lights
Instrument panel warning lights
20.0 A
Fuse 31
Not used
10.0 A
Fuse 32
Diesel fuel heater
Automatic transmission
Reversing light(s)
15.0 A
Fuse 33
Automatic transmission control unit
Automatic transmission relay
5.0 A
Fuse 34
Not used
5.0 A
Relay R1
Air pump relay
Relay R2
Rear fog light(s)
Relay R3
Headlight washer pump
Relay R4
Diagnostic system
Automatic gearbox
Fuse box in engine compartment (RHD).
Fuse 5
Dipped beam relay
15.0 A
Fuse 6
Not used
Fuse 7
Additional heater system
25.0 A
Fuse 14
Alarm
5.0 A
Fuse 18
Main beam
10.0 A
Fuse 19
Main beam
10.0 A
Fuse 20
Brake light(s)
10.0 A
Fuse 21
Not used
5.0 A
Fuse 22
BSI (Intelligent power distribution module)
20.0 A
Fuse 23
ABS control unit
10.0 A
Fuse 24
Speed sensor
Cooling fan
Diesel preheating
Control unit (2.0 HDi)
Coolant level warning light
Injection system double relay
HDi coolant heater
5.0 A
Fuse 25
Fuel pump
15.0 A
Fuse 26
Injection system double relay
30.0 A
Fuse 27
Injection system double relay
20.0 A
Fuse 27a
Automatic transmission control unit
20.0 A
Fuse 28
Injection pump
EGR solenoid
Catalytic converter sensors
15.0 A
Fuse 29
Additional heater
Air pump
30.0 A
Fuse 30
Front fog lights
Fog light switch illumination
20.0 A
Fuse 31
Not used
Fuse 32
Diesel fuel heater
Submerged heater
Automatic transmission
Reversing light(s)
10.0 A
Fuse 33
Automatic transmission control unit
10.0 A
Fuse 34
Not used
Fuse MF01
No information is available
50.0 A
Fuse MF02
No information is available
40.0 A
Fuse MF03
No information is available
80.0 A
Fuse MF04
No information is available
80.0 A
Fuse MF08
No information is available
40.0 A
Fuse MF09
No information is available
20.0 A
Fuse MF10
No information is available
70.0 A
Fuse MF11
No information is available
30.0 A
Fuse MF12
No information is available
60.0 A
Fuse MF13
No information is available
80.0 A
Fuse MF15
No information is available
50.0 A
Relay box in engine compartment.
Relay R1
Front fog light relay
Relay R2
Compressor cut-off
Relay R3
Air-conditioning compressor relay
Or
Horn
Relay R4
Headlight washer timer
Relay R5
Diesel pre-post heating
Relay R6
Advance correction
Relay R7
Automatic transmission relay
Or
Power steering relay
Additional fuse box in engine compartment.
Fuse A
Coolant heater
40.0 A
Fuse B
Coolant heater
40.0 A
Relay R1
Coolant heater relay 1
Relay R2
Coolant heater relay 2
