For Citroen ZX 1991, 1992, 1993, 1994, 1995, 1996, 1997, 1998 model year.
Cigarette lighter fuse – fuse box in passenger compartment (pre 1994) – Fuse F8/20A Cigarette lighter fuse – fuse box in passenger compartment (since 1994) – Fuse F8/20A and fuse F10/20A |
MENU
Fuse box in passenger compartment.
- fuse box diagram (pre 1994)
- fuse box diagram (since 1994, type 1)
- fuse box diagram (since 1994, type 2)
Fuse box in engine compartment.
Fuse box in passenger compartment.
fuse box location.
Assignment of the fuses.
| Fuses | Amps | Cicuits Protected |
|---|---|---|
| 1 | 30A | Front window Sunroof Seat(s) |
| 2 | 25A | Wash/wipe system Radio Brake lights Lights on Automatic transmission |
| 3 | 10A | Direction indicators Cooling fan relay Heated rear windscreen switch Power window relay |
| 4 | 25A | Central locking |
| 5 | 25A | Heated rear windscreen and mirrors |
| 6 | 10A | Hazard warning lights Alarm system Coolant temperature control unit |
| 7 | 10A | Reversing light(s) Instrument panel Instrument lighting Coolant level ABS Alarm horn |
| 8 | 20A | Interior light(s) Radio Clock Luggage compartment light(s) Remote control Cigarette lighter |
| 9 | 30A | Power windows Interior lights |
| 10 | 20A | Horn |
| 11 | 5A | Rear fog light(s) |
| 12 | 5A | Right sidelight Right tail light Illumination, control switches Illumination, cigarette lighter Ashtray illumination Illumination, radio Lights on |
| 13 | 5A | Left sidelight Left tail light Number plate light(s) Dashboard illumination, sidelights |
Fuse box diagram (since 1994, type 1).
Fuse box diagram (since 1994, type 2).
legend (type 1 and type 2).
| Fuses | Amps | Circuits Protected |
|---|---|---|
| 1 | 30A | Front window Sunroof Seat(s) |
| 2a | 25A | Blower |
| 2b | 5A | Air conditioning |
| 3a | 5A | Cooling fan Timer relay, rear windows |
| 3b | 25A | Cut-off relay or timer relay for rear door windows Cooling fan Heated seats |
| 4 | 25A | Charge control light Radio Fuel level control light Lights on Wiper system Automatic transmission Sunroof Windows |
| 5 | 25A | Heated rear windscreen and mirrors |
| 6 | 10A | Hazard warning lights Alarm system Coolant temperature control unit Immobiliser |
| 7 | 10A | Reversing light(s) Instrument panel Instrument lighting Coolant level ABS Alarm horn |
| 8 | 20A | Interior light(s) Radio Clock Luggage compartment light(s) Remote control Cigarette lighter |
| 9a | 20A | Interior lights Direction indicators Brake lights Front intermittent wiper Hazard warning lights |
| 9b | 30A | Headlight washers Direction indicators Brake lights Intermittent wiper Hazard warning lights Mirrors |
| 10 | 20A | Horn Cigarette lighter |
| 11 | 5A | Rear fog light(s) |
| 12 | 5A | Right sidelight Right tail light Illumination, control switches Illumination, cigarette lighter Ashtray illumination Illumination, radio Lights on Fog lights |
| 13 | 5A | Left sidelight Left tail light Number plate light(s) Dashboard illumination, sidelights Alarm system |
Fuse box in engine compartment.
legend.
| Fuses | Amps | Circuits Protected |
|---|---|---|
| 1a | 15A | Fog lights Horn |
| 1b | 30A | Fog lights Horn Optional equipment |
| 2 | 30A | Air conditioning |
| 3a | 5A | Cooling fan |
| 3b | 30A | Cooling fan Optional equipment |
| 4 | 25A | Cooling fan |
| 5 | — | |
| 6 | — |
